Frigidaire FRT18IB4A Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRT18IB4A
  6. Factory parts catalog
Frigidaire FRT18IB4A Factory Parts Catalog

Frigidaire FRT18IB4A Factory Parts Catalog

Top-mount refrigerator
Hide thumbs Also See for FRT18IB4A:

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FRT18IB4AQ8
FRT18IB4A
FRT18IB4AT8
FRT18IB4A
FRT18IB4AW8
FRT18IB4A
FRT18IB4AZ8
FRT18IB4A
MARKET
North America
ENERGY GUIDE - 218791459
OWNER'S GUIDE - 240400110
SERVICE DATA SHEET - 240379011
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque (RH)
R134a
bisque (LH)
R134a
white (RH)
R134a
white (LH)
Publication No.
5995398970
031119
-EN/SERVICE /DCS
390
FACTORY
PARTS CATALO
VOLTS
115
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18IB4A
©2003 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT18IB4A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRT18IB4A

Summary of Contents for Frigidaire FRT18IB4A

  • Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT18IB4AQ8 FRT18IB4A R134a bisque (RH) FRT18IB4AT8 FRT18IB4A R134a bisque (LH) FRT18IB4AW8 FRT18IB4A R134a white (RH) FRT18IB4AZ8 FRT18IB4A R134a white (LH) MARKET North America ENERGY GUIDE - 218791459 OWNER’S GUIDE - 240400110 SERVICE DATA SHEET - 240379011 TOP MOUNT REFRIGERATOR...
  • Page 2 Publication No. FRT18IB4A 5995398970 DOOR 11/03...
  • Page 3 FRT18IB4A Publication No. 5995398970 DOOR A = FRT18IB4A (FRT18IB4AQ8) B = FRT18IB4A (FRT18IB4AT8) C = FRT18IB4A (FRT18IB4AW8) D = FRT18IB4A (FRT18IB4AZ8) POS. NO PART NO DESCRIPTION 240542103 A B C D Gasket-frzr door,white ,magnetic 240542106 A B C D Gasket-refr door,white ,magnetic 240534901 A B C D Rack-door...
  • Page 4 Publication No. FRT18IB4A 5995398970 CABINET 11/03...
  • Page 5 FRT18IB4A Publication No. 5995398970 CABINET A = FRT18IB4A (FRT18IB4AQ8) B = FRT18IB4A (FRT18IB4AT8) C = FRT18IB4A (FRT18IB4AW8) D = FRT18IB4A (FRT18IB4AZ8) POS. NO PART NO DESCRIPTION 240355401 A B C D Cover-fan 240367001 A B C D Knob-damper control 5303001028 A B C D Nut,push-on 240367401...
  • Page 6 Publication No. FRT18IB4A 5995398970 SHELVES 11/03...
  • Page 7 FRT18IB4A Publication No. 5995398970 SHELVES A = FRT18IB4A (FRT18IB4AQ8) B = FRT18IB4A (FRT18IB4AT8) C = FRT18IB4A (FRT18IB4AW8) D = FRT18IB4A (FRT18IB4AZ8) POS. NO PART NO DESCRIPTION 5303282284 A B C D Shelf-freezer,"table type" 240545001 A B C D Diffuser,air ,top 240362601 A B C D Diffuser,air ,bottom...
  • Page 8 Publication No. FRT18IB4A 5995398970 SYSTEM N05CBBBAB0 11/03...
  • Page 9 FRT18IB4A Publication No. 5995398970 SYSTEM A = FRT18IB4A (FRT18IB4AQ8) B = FRT18IB4A (FRT18IB4AT8) C = FRT18IB4A (FRT18IB4AW8) D = FRT18IB4A (FRT18IB4AZ8) POS. NO PART NO DESCRIPTION 240406406 A B C D Condenser,static 240405201 A B C D Grommet,rubber ,black ,cond tube/wire 5303208866 A B C D Spacer,condenser tube ,black...

  • Page 10: Ice Maker

    Publication No. FRT18IB4A 5995398970 ICE MAKER 11/03...
  • Page 11 FRT18IB4A Publication No. 5995398970 ICE MAKER A = FRT18IB4A (FRT18IB4AQ8) B = FRT18IB4A (FRT18IB4AT8) C = FRT18IB4A (FRT18IB4AW8) D = FRT18IB4A (FRT18IB4AZ8) POS. NO PART NO DESCRIPTION 218976901 A B C D Tube-water inlet,inlet valve ,to ice maker 240561701 A B C D Seal-water inlet,inlet valve ,to ice maker 5304420650 A B C D...

  • Page 12: Wiring Schematic

    Publication No. FRT18IB4A 5995398970 WIRING SCHEMATIC 11/03...

  • Page 13: Wiring Diagram

    FRT18IB4A Publication No. 5995398970 WIRING DIAGRAM # = Fast-moving Parts 11/03 * = Non-Illustrated Parts...
