Frigidaire FRT17IB3A Factory Parts Catalog

Frigidaire FRT17IB3A Factory Parts Catalog

Top-mount refrigerator with ice-maker
Hide thumbs Also See for FRT17IB3A:

Advertisement

Quick Links

Download this manual See also: Factory Parts Catalog
N05L00004.eps N05DBDCKA0.eps N05BBAAAA14.eps N05SACDCA2.eps
N05CBBBAC4.eps 115-1.eps
u
x Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FRT17IB3AQA FRT17IB3AQ9
Series
R134a, Static
Color
bisque
Volts
115
Wiring Diagram
240398801
Owner's Guide
240400113
Market
North America North America
Energy Guide
218791452
Service Data Sheet
240379017
Installation Instructions 240568301
240398801.eps 240398601.eps
Publication No.
5995457800
06/01/09
(EN/SERVICE/RF)
390
R134a, Static
bisque
115
240398801
240400112
218791452
240379017
240368300
TOP-MOUNT
REFRIGERATOR WITH
ICE-MAKER
Model No.
FRT17IB3A
©
Copyright
2006 Home Pr
All rights reserved.
oducts, Inc.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT17IB3A and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRT17IB3A

Summary of Contents for Frigidaire FRT17IB3A

  • Page 1 Product No. FRT17IB3AQA FRT17IB3AQ9 Series R134a, Static R134a, Static Color bisque bisque Volts Wiring Diagram 240398801 240398801 Owner's Guide 240400113 240400112 Market North America North America Energy Guide 218791452 218791452 Service Data Sheet 240379017 240379017 Installation Instructions 240568301 240368300 TOP-MOUNT N05L00004.eps N05DBDCKA0.eps N05BBAAAA14.eps N05SACDCA2.eps REFRIGERATOR WITH N05CBBBAC4.eps 115-1.eps...
  • Page 2 Publication No: 5995457800 FRT17IB3A DOOR N05DBDCKA0 01/06...
  • Page 3 FRT17IB3A Publication No: 5995457800 DOOR Model Index: A FRT17IB3A (FRT17IB3AQA) B FRT17IB3A (FRT17IB3AQ9) POS. NO PART NO. DESCRIPTION 240554113 Gasket-frzr door, white, magnetic 240542116 Gasket-refr door, white, magnetic 240535101 Rack-door 240535201 Rack-door 240337701 Door-dairy, w/o graphics, white 240535001 Rack-door 240381302 Plug-button, bisque, hinge brg hole, (2) 240420102 Door, frzr, bisque...
  • Page 4 Publication No: 5995457800 FRT17IB3A CABINET N05BBAAAA14 01/06...
  • Page 5 FRT17IB3A Publication No: 5995457800 CABINET Model Index: A FRT17IB3A (FRT17IB3AQA) B FRT17IB3A (FRT17IB3AQ9) POS. NO PART NO. DESCRIPTION 241652301 Cover-fan 240367001 Knob-damper control 5303001028 Nut, push-on 241523701 Damper-fan cover 5308000010 Fan Blade, red, evaporator fan 5300157666 Bushing-motor mtg, (2) 5303292396 Bracket-motor mtg, front 241652211 Cover-evap coil...
  • Page 6 Publication No: 5995457800 FRT17IB3A SHELVES 01/06...
  • Page 7 FRT17IB3A Publication No: 5995457800 SHELVES Model Index: A FRT17IB3A (FRT17IB3AQA) B FRT17IB3A (FRT17IB3AQ9) POS. NO PART NO. DESCRIPTION 5303282284 Shelf-freezer, "table type" 241542001 Diffuser, air, top 240362601 Diffuser, air, bottom 14 # 241554901 Switch-light/lamp 240436702 Light Bulb/Lamp, A-15, clear, 40 W, 120 V, miniature 241559801 Socket-light 240368001...
  • Page 8 Publication No: 5995457800 FRT17IB3A SYSTEM N05CBBBAC4 01/06...
  • Page 9 FRT17IB3A Publication No: 5995457800 SYSTEM Model Index: A FRT17IB3A (FRT17IB3AQA) B FRT17IB3A (FRT17IB3AQ9) POS. NO PART NO. DESCRIPTION 240406407 Condenser, static 240405201 Grommet, rubber, black, cond tube/wire 5303208866 Spacer, condenser tube, black 5308000296 Bracket, condenser mtg, (4) 5308009617 Washer, ext tooth lock, #10, grounding 218944001 Drier-filter, R134a System 241678801...

  • Page 10: Ice Maker

    Publication No: 5995457800 FRT17IB3A ICE MAKER 01/06...
  • Page 11 FRT17IB3A Publication No: 5995457800 ICE MAKER Model Index: A FRT17IB3A (FRT17IB3AQA) B FRT17IB3A (FRT17IB3AQ9) POS. NO PART NO. DESCRIPTION 218976901 Tube-water inlet, inlet valve, to ice maker 240561701 Seal-water inlet, inlet valve, to ice maker 5304420650 Spring, shut-off arm 3206299 Label, ID plate 3206301 Gear...

  • Page 12: Wiring Schematic

    Publication No: 5995457800 FRT17IB3A WIRING SCHEMATIC 01/06...

  • Page 13: Wiring Diagram

    FRT17IB3A Publication No: 5995457800 WIRING DIAGRAM 01/06 # Functional Parts * Non-Illustrated Parts...
