Frigidaire FRT17B3A Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRT17B3A
  6. Factory parts catalog
Frigidaire FRT17B3A Factory Parts Catalog

Frigidaire FRT17B3A Factory Parts Catalog

Top-mount refrigerator
Hide thumbs Also See for FRT17B3A:

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FRT17B3AQ3
FRT17B3A
FRT17B3AT3
FRT17B3A
FRT17B3AW3
FRT17B3A
FRT17B3AZ3
FRT17B3A
MARKET
North America
ENERGY GUIDE - # 218791451
OWNER'S GUIDE - # 240400107
SERVICE DATA SHEET - # 240379010
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a, Static
bisque
R134a, Static
bisque
R134a, Static
white
R134a, Static
white
Publication No.
5995379806
021016
-EN/SERVICE /DCS
390
FACTORY
PARTS CATALO
VOLTS
115
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT17B3A
©2002 Electrolux Home Products, Inc.
All rights reserved
G
