PRODUCT NO.
BASE MODEL NO.
FRT17G5AQ1
FRT17G5A
FRT17G5AT1
FRT17G5A
FRT17G5AW1
FRT17G5A
FRT17G5AZ1
FRT17G5A
MARKET
North America
WIRING DIAGRAM - #240379007
OWNER'S GUIDE - #240400106
SERVICE DATA SHEET - #240379007
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a, Dynamic
bisque (right)
R134a, Dynamic
bisque (left)
R134a, Dynamic
white (right)
R134a, Dynamic
white (left)
Publication No.
5995373742
020607
-EN/SERVICE/DCS
390
FACTORY
PARTS CATALO
VOLTS
115
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT17G5A
©2001 White Consolidated Industries, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT17G5A
Summary of Contents for Frigidaire FRT17G5A
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT17G5AQ1 FRT17G5A R134a, Dynamic bisque (right) FRT17G5AT1 FRT17G5A R134a, Dynamic bisque (left) FRT17G5AW1 FRT17G5A R134a, Dynamic white (right) FRT17G5AZ1 FRT17G5A R134a, Dynamic white (left) MARKET North America WIRING DIAGRAM - #240379007 OWNER’S GUIDE - #240400106 TOP MOUNT SERVICE DATA SHEET - #240379007...
- Page 2 Publication No. FRT17G5A 5995373742 DOOR 06/02...
- Page 3 FRT17G5A Publication No. 5995373742 DOOR A = FRT17G5A (FRT17G5AQ1) B = FRT17G5A (FRT17G5AT1) C = FRT17G5A (FRT17G5AW1) D = FRT17G5A (FRT17G5AZ1) POS. NO PART NO DESCRIPTION 240514601 A B C D Gasket,frzr door seal ,white ,magnetic 240514604 A B C D Gasket,refr door seal ,white ,magnetic 240331404 A B C D...
- Page 4 Publication No. FRT17G5A 5995373742 CABINET 06/02...
- Page 5 FRT17G5A Publication No. 5995373742 CABINET A = FRT17G5A (FRT17G5AQ1) B = FRT17G5A (FRT17G5AT1) C = FRT17G5A (FRT17G5AW1) D = FRT17G5A (FRT17G5AZ1) POS. NO PART NO DESCRIPTION 240355401 A B C D Cover-fan 240367001 A B C D Knob-damper control 5303001028 A B C D Nut,push-on 240367401...
- Page 6 Publication No. FRT17G5A 5995373742 SHELVES 06/02...
- Page 7 FRT17G5A Publication No. 5995373742 SHELVES A = FRT17G5A (FRT17G5AQ1) B = FRT17G5A (FRT17G5AT1) C = FRT17G5A (FRT17G5AW1) D = FRT17G5A (FRT17G5AZ1) POS. NO PART NO DESCRIPTION 240358001 A B C D Shelf,freezer 5303299664 A B C D Spacer,shelf 240545001 A B C D Diffuser,air ,top 240362601 A B C D...
- Page 8 Publication No. FRT17G5A 5995373742 SYSTEM 06/02...
- Page 9 FRT17G5A Publication No. 5995373742 SYSTEM A = FRT17G5A (FRT17G5AQ1) B = FRT17G5A (FRT17G5AT1) C = FRT17G5A (FRT17G5AW1) D = FRT17G5A (FRT17G5AZ1) POS. NO PART NO DESCRIPTION 240444401 A B C D Condenser,dynamic 218944001 A B C D Drier-filter,R134a System 240496101 A B C D Wiring Harness,machine compt, w/electric cord 6* #...
-
Page 10: Wiring Schematic
Publication No. FRT17G5A 5995373742 WIRING SCHEMATIC 06/02... -
Page 11: Wiring Diagram
FRT17G5A Publication No. 5995373742 WIRING DIAGRAM # = Fast-moving Parts 06/02 * = Non-Illustrated Parts...
