Frigidaire FEB27S5D Factory Parts Catalog

Frigidaire FEB27S5D Factory Parts Catalog

Single electric wall oven
Hide thumbs Also See for FEB27S5D:

Advertisement

Quick Links

Download this manual
FEB27S5DC.tif CFEB30S5DSA.eps BFEB27S5DSA.eps DFEB30S5DCA.eps
318046237.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FEB27S5DCB
38254731F40S2
Series
27" single
Color
stainless
Market
North America
Wiring Diagram
318046237
Owner's Guide
318200924
Installation Instructions 318201514
Service Data Sheet
318047413
Timer Guide
318200189
Publication No.
5995442646
05/07/25
(EN/SERVICE/BJH)
377
SINGLE ELECTRIC

WALL OVEN

Model No.
FEB27S5D
©
Copyright
2005 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the FEB27S5D and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FEB27S5D

Summary of Contents for Frigidaire FEB27S5D

  • Page 1: Wall Oven

    Product No. FEB27S5DCB 38254731F40S2 Series 27" single Color stainless Market North America Wiring Diagram 318046237 Owner's Guide 318200924 Installation Instructions 318201514 Service Data Sheet 318047413 Timer Guide 318200189 SINGLE ELECTRIC FEB27S5DC.tif CFEB30S5DSA.eps BFEB27S5DSA.eps DFEB30S5DCA.eps WALL OVEN 318046237.eps Electrolux Major Appliances Model No.

  • Page 2: Control Panel

    Publication No: 5995442646 FEB27S5DCB CONTROL PANEL 07/05...
  • Page 3 FEB27S5DCB Publication No: 5995442646 CONTROL PANEL POS. NO PART NO. DESCRIPTION 318257301 Shield, oven top 318260101 Cover, box 318274401 Control Panel Assembly, glass, black, w/touch pad 20 # 316418520 Clock/Timer, electronic, ES350W1 316021107 Screw, hex head, 8-32, silver 5303211311 Screw, 8 x 0.500 07/05 # Functional Parts * Non-Illustrated Parts...
  • Page 4 Publication No: 5995442646 FEB27S5DCB BODY 07/05...
  • Page 5 FEB27S5DCB Publication No: 5995442646 BODY POS. NO PART NO. DESCRIPTION 318259210 Back, main 318258910 Shield, insulation, upper 318262602 Rack, oven, (2) 5303317977 Pan, broiler 5303317976 Insert, broiler pan 12 # 318089917 Switch, light 318224000 Receptacle, oven light 318268099 Insulation, oven light 5303013071 Bulb/Lamp, oven light 3201911...
  • Page 6 Publication No: 5995442646 FEB27S5DCB BODY 07/05...
  • Page 7 FEB27S5DCB Publication No: 5995442646 BODY POS. NO PART NO. DESCRIPTION 219# 318003614 Thermostat, safety 219A 318003613 Thermostat, safety 318257711 Trim, oven, black, front 5304440067 Cabinet Mounting Kit 318246010 Bracket, cabinet mtg, (2) 311* 5304438005 Screw, 6 x 1, black 318246702 Tool, cabinet bracket, RH 318246703 Tool, cabinet bracket, LH...
  • Page 8 Publication No: 5995442646 FEB27S5DCB DOOR 07/05...
  • Page 9 FEB27S5DCB Publication No: 5995442646 DOOR POS. NO PART NO. DESCRIPTION 318260401 Trim, oven door, side, (2) 318262101 Cover, rear door, black, (2) 318260510 Baffle, door 318285057 Insulation, oven door 318285061 Insulation, (2) 318212200 Glass, oven door, heat barrier 318259615 Liner, upper door 5303311174 Screw, 10-24 x 3/8 318053125...

  • Page 10: Wiring Diagram

    Publication No: 5995442646 FEB27S5DCB WIRING DIAGRAM 07/05...
