- Page 1 This product contains electrical or electronic materials. The presence of these materials may, if not disposed of properly, have potential adverse effects on the environment and human health. Presence of this label on the product means it should not be disposed of as unsorted waste and must be collected separately.
-
Page 2: Federal Communications Commission Statement
Federal Communications Commission Statement This equipment has been tested and found to comply with the limits of a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 3: Warnings And Precautions
Warnings and Precautions To prevent any injuries, the following safety precautions should be observed in the installation, use, servicing and maintenance of this equipment. Before operating this equipment, please read this manual completely, and keep it nearby for future reference. TO REDUCE THE RISK OF ELECTRIC SHOCK NO USER-SERVICEABLE PARTS INSIDE. - Page 4 ▪ If you can not fit the plug into the electrical outlet, contact an electrician to install a grounding outlet. ▪ Always operate this equipment from the type of power source indicated on the rear of the serial/model plate. ▪ Never overload wall outlets and extensions. ▪...
-
Page 5: Listening With Earphones
LISTENING WITH EARPHONES ▪ Listen at moderate Volumes to avoid hearing damage. ▪ If you hear no sound during playback, do not turn the Volume up as the music may suddenly begin at a high Volume. Excessive sound pressure from earphones and headphones can cause hearing loss. -
Page 6: Table Of Contents
TABLE OF CONTENTS Federal Communications Commission Statement Warnings and Precautions Important Safety Instructions ... 2 Antenna Safety Instructions ... 4 Chapter Introducing the TV Key Features ... 6 Package Contents ... 7 Setting Your TV ... 8 Your TV ...11 Your Remote Control ... -
Page 7: Chapter Introducing The Tv
Chapter Introducing the TV Chapter 1 Introducing the TV Key Features Multiple Audio/Video Inputs and Outputs for Easy, User-Friendly Connections ▪ 1 composite VIDEO input terminal ▪ 1 component Video input terminal ▪ 1 VGA and VGA Audio input terminal ▪... -
Page 8: Package Contents
Package Contents Make sure all of the following contents are included. TV AC-DC Adapter User’s Manual The photos of the accessories are for reference only, the color of the remote control, the type of power cord are variable based on the actual models. -
Page 9: Setting Up Your Tv
Chapter Introducing the TV Setting Up Your TV How to install the TV Stand Follow the instructions below to install the TV stand: Open the box, and make sure all necessary parts are in the box. The package contains: ... - Page 10 How to remove the TV Stand If you prefer to mount your new TV on a wall instead of attaching it to the stand, please reference the instructions included in the wall mounting kit (sold separately). To prevent damaging the surface of the TV, place the TV on a soft cloth. Remove the screw of the table stand and detach the table stand from the TV.
- Page 11 Chapter Introducing the TV How to setup the TV Use a supplied antenna cable to connect the VHF/UHF signal to the TV’s ANT. terminal (refer to page14-18). Connect the AC power cord to the back of the TV and connect the power cord to the wall outlet.
-
Page 12: Your Tv
Your TV Front/Left /Right Side View and Controls Right Side View VOL+- Adjusts the volume up and down. Selects the main menu item and change values for items when in the OSD mode. ▲▼ Scans up and down through channels. Selects sub-menu item when in the OSD mode. -
Page 13: Digital Coaxial
Chapter Introducing the TV Rear View and Jacks EARPHONE Connects to the external headphone for private listening. YPbPr IN //AUDIO(L/R) IN Connects to the DVD player, Digital Set-Top-Box, or other AV equipment with component(YPbPr) video and audio output jacks. HDMI IN Connects the all digital AV equipment with HDMI... -
Page 14: Remote Control Overview
Your Remote Control POWER S.MODE P.MODE CAPTION SLEEP P.SIZE JUMP MUTE VOL. INPUT GUIDE EXIT INFO MENU LIST FAV.CH TIMER FREEZE Turns the TV on and off. Cycles through the multi-channels TV sound (MTS) options: SAP/MONO/ STEREO S.MODE Selects sound effect options: Surround/ Live/Dance/Techno/Classic/Soft/Rock/ Pop/Off. - Page 15 Chapter Installing the TV POWER S.MODE P.MODE CAPTION SLEEP P.SIZE JUMP MUTE VOL. INPUT GUIDE EXIT INFO MENU LIST FAV.CH TIMER FREEZE Effective range: The remote can control the TV from up to inch away, if pointed directly at the receiver.
-
Page 16: Chapter Installing The Tv
Chapter 2 Installing the TV Refer to the owner’s manual of any external equipment to be connected. When connecting any external equipment, do not connect any AC power cords to wall outlets until all other connections are completed. Connecting a TV Cable or an Antenna Antenna Connection The antenna requirements for good color TV reception are more important than those for a black &... -
Page 17: Combination Vhf/Uhf Antenna
Chapter Installing the TV Use one of the following two diagrams when connecting an outdoor antenna. A: Shows how to use a VHF/UHF combination outdoor antenna. B: Shows how to use a separate VHF and/or UHF outdoor antenna. A. Combination VHF/UHF antenna B. - Page 18 Cable TV (CATV) Connection This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the National Electrical Code (NEC) that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building accurately, or as close to the point of cable entry as possible.
- Page 19 Chapter Installing the TV Use a supplied antenna cable to connect the TV signal to the TV’s TV CABLE terminal. Connect the DC plug of the AC-DC adapter to the DC 12V port at the back of the TV. ...
- Page 20 Press the MENU button on the remote control to display the Main menu, and use the ◄► buttons to select TV. Channel Scan Tuner Mode Cable Channel Skip Favorite List Time Zome Eastern Time Enter Press the ▼ button to select Channel Scan, and press the The Channel Scan automatically creates a list of receivable channels.
-
Page 21: Connecting An A/V Device With Composite Connector
Chapter Installing the TV Connecting an A/V Device with Composite Connector Rear of TV U se a composite cable to connect the external A/V device’s composite audio/video jacks to the TV’s VIDEO IN jacks. Connect all AC power sources, before turning on the power switch of the TV or other connected equipment. -
Page 22: Connecting An A/V Device With Component(Ypbpr) Connector
Connecting an A/V Device with Component(YPbPr) Connector Rear of TV COMPONENT Cable Not all A/V device have the ability to connect to a TV. Please check your A/V device user guide for compatibility. U se a component cable to connect the external A/V device’s component output jacks to the TV’s YPbPr IN input jacks. -
Page 23: Connecting An Av Equipment With Hdmi Connector
Chapter Installing the TV Connecting an AV Equipment with HDMI Connector Rear of TV HDMI Cable Use a HDMI cable to connect the AV equipment’s HDMI output jack to the TV’s HDMI IN jacks. Connect all AC power sources, before turning on the power switch of the TV or other connected equipment. -
Page 24: Connecting An Av Equipment With Dvi Connector
Connecting an AV Equipment with DVI Connector Rear of TV AUDIO Cable HDMI-to-DVI Cable Use a HDMI-to-DVI cable to connect the AV equipment’s DVI output jack to the TV’s HDMI IN jacks. Use an audio cable to connect the AUDIO jacks. -
Page 25: Connecting A Pc
Chapter Installing the TV Connecting a PC Rear of TV AUDIO Cable VGA Cable Use a VGA cable to connect the PC’s VGA output jack to the TV’s VGA input jack. Use an audio cable to connect the PC’s audio output jacks to the TV. ... -
Page 26: Connecting An Audio Receiver Or A Dolby Digital 5.1 Sound System
Connecting an Audio Receiver or a Dolby Digital 5.1 Sound System For better sound quality, you may want to play the TV audio through your stereo system. Rear of TV Use an audio cable to connect the audio receiver’s audio LINE IN jacks to TV’s COAXIAL OUT jacks. -
Page 27: Chapter Using The Features
Chapter Using the TV Chapter 3 USING THE FEATURES Wide Screen Viewing Wide Screen function allows viewing of 4:3/16:9 images in wide screen mode, cycling through the following wide screen settings. Press the P-Size button repeatedly to select the screen format you want. -
Page 28: Using The Program Guide
Using the Program Guide The Program Guide feature brings all sorts of information to your screen, such as program title, program duration, time remaining, rating information, closed caption, availability, etc. With the TV connected to a television programming source, press the INPUT button on the remote, then using the ▲... -
Page 29: Operating The Menu
Chapter Using the TV Operating the Menu Press the button to turn the TV on. Press the MENU button on the remote control, the on-screen menu will appear on the screen. Use the ◄► buttons to select your main menu option. VIDEO MENU: Allows you to make adjustments to your picture settings. - Page 30 TV MENU: Allows you to edit and label channels. Channel Scan Tuner Mode Cable Channel Skip Favorite List Time Zome Eastern Time Enter SETUP MENU: Allows you to set up a variety of features: Language, Closed Caption, factory reset, Parental Control, Time Setup.
-
Page 31: Customizing The Video Settings
Chapter Using the TV Customizing the VIDEO Settings Press the button to turn the TV on. Press the MENU button on the remote control to display the Main menu, and use the ◄► buttons to select VIDEO. Use the ▲▼buttons to highlight an individual VIDEO option, use the ◄► buttons to change the setting, and press the MENU button to exit the menu. - Page 32 Adjusts color components independently to achieve a warm or cool Color temperature effect: Cool/Natural/Warm/User ▪ Warm: ▪ Nature: Increases green tint ▪ Cool : ▪ User : Select to reduce the noise level of connected equipment: Off/Low/ Noise Reduction Medium/Strong.
-
Page 33: Customizing The Audio Settings
Chapter Using the TV Customizing the AUDIO Settings Press the button to turn the TV on. Press the MENU button on the remote control to display the Main menu, and use the ◄► buttons to select AUDIO. Use the ▲▼buttons to highlight an individual AUDIO option, use the ◄► buttons to change the setting, and press the MENU button to exit the menu ▪... - Page 34 Allows you to listen to high-fidelity stereo sound while watching TV ▪ Stereo: Use separate audio tracks for left and right speakers, if available ▪ SAP: You can enjoy a second audio program from the speakers while watching a scene in the original program ▪...
-
Page 35: Customizing The Tv Settings
Chapter Using the TV Customizing the TV Settings Press the button to turn the TV on. Press the MENU button on the remote control to display the Main menu, and use the ◄► buttons to select TV. Use the ▲▼buttons to highlight an individual TV option, use the ◄► buttons changes the setting, and press the MENU button to exit the menu. -
Page 36: Favorite List
Favorite List Allows selection of regional TV systems of USA: Eastern Time/ Time Zone Indiana/Central time/Mountain Time/Arizona/Pacific Time/Alaska/ Hawaii Press the ▼ button to select the desired channel, and press the OK button repeatedly to select show ( Select Favorite List from the TV options and press the OK button. -
Page 37: Customizing The Setup Settings
Chapter Using the TV Customizing the SETUP Settings Press the button to turn the TV on. Press the MENU button on the remote control to display the Main menu, and use the ◄► buttons to select SETUP. Use the ▲▼buttons to highlight an individual SETUP option, use the ◄► buttons to change the setting, and press the MENU button to exit the menu. -
Page 38: Closed Caption
Allows you to select from analog or digital closed caption modes and Closed Caption press the OK button. The Closed Caption list appears: Analog Cloaed Caption Digital Cloaed Caption Digital Caption Style A nalog Closed Caption: Press the ◄► buttons to select the basic analog closed caption options:Off/CC1/CC2/CC3/CC4/T1/T2/T3/T4 ... -
Page 39: Reset Default
Chapter Using the TV Gamma Back Light Input Edit Reset Default Allows for the adjustment of the display’s gamma correction, which fine tunes both brightness and red/green/blue ratios: Bright/Middle/Dark. Select to turn on or off the brightness of the screen. ▪... -
Page 40: Using The Program Block Settings
Using the Program Block Settings Press the MENU button on the remote control to display the Main menu, and use the ◄► buttons to select SETUP. Use the ▼ button to highlight Parental, and press the OK button. SETUP OSD Language English Time Setup Closed Caption... - Page 41 Chapter Using the TV The Parental block menu includes the following options: U.S. TV Ratings U.S. Movie Ratings Canadian English Ratings Select to activate the English Rating programs of Canada. Canadian French Ratings Select to activate the French Rating programs of Canada Block MPAA Unrated Block TV None Rating Select to activate the TV Rating programs.
- Page 42 U.S. TV Ratings The U.S.TV Rating has 2 rating methods: Content-Based Rating and Age-Based Rating. The U.S.TV Rating includes the following options: U.S. TV Ratings TV-Y TV-Y7 TV-G TV-PG TV-14 TV-MA Allowed Rating Blocked Rating Select AGE-BASED RATING DESCRIPTION All children TV-Y Directed to children age 7 and older TV-Y...
- Page 43 Chapter Using the TV Canadian English Ratings Canadian Englsh Ratings The Canadian English Ratings Allowed Rating RATING DESCRIPTION All children Children 8 years and older General programming Parental guidance Viewers 14 and older Adult programming ▲ ▼ Use the ◄► buttons to select the rating you want and press the OK button repeatedly to select BLOCK or UNBLOCK...
- Page 44 U.S. Movie Ratings The U.S. Movie Ratings is used for original movies rated by the Motion Picture Association of America(MPAA) as broadcasted on cable TV and not edited for television. U.S. Movie Ratings The includes the following options: U.S. Movie Ratings PG-13 NC-17 Allowed Rating...
-
Page 45: Troubleshooting
TROUBLESHOOTING Before consulting service personnel, check the following chart for a possible cause of the trouble and for a possible solution. TV will not turn on Make sure the power cord is plugged in, then press the The batteries in the remote control may have lost their charge. ... -
Page 46: Specifications
SPECIFICATIONS MODEL Panel Panel Size Brightness Contrast Ratio Max. Resolution Input Connector C-VIDEO YPbPr AUDIO IN(L/R) HDMI VGA LINE IN COAXIAL EARPHONE VHF/UHF IN Speakers AC power adapter TV Input Power Consumption Dimension Weight MODEL Panel Panel Size Brightness Contrast Ratio Max. -
Page 47: Display Mode
DISPLAY MODE The screen resolution has been optimized during manufacture for the display modes listed below. If the signal from the system equals the standard signal mode, the screen is adjusted automatically. If the signal from the system does not equal the standard signal mode, adjusting the screen resolution by referring to your video card user guide otherwise there may be no video, Video signal: (VGA Standard) Resolution (Dot X Line)
