- Page 3 Federal Communications Commission Statement This equipment has been tested and found to comply with the limits of a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
-
Page 4: Warnings And Precautions
Warnings and Precautions Warnings and Precautions CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safety Instructions... - Page 5 Warnings and Precautions...
- Page 6 Warnings and Precautions LISTENING WITH EARPHONES Outdoor Antenna Safety Instructions Ground clamps EXAMPLE OF OUTDOOR ANTENNA GROUNDING...
-
Page 7: Table Of Contents
TABLE OF CONTENTS Federal Communications Commission Statement Warnings and Precautions Chapter 1 Introducing the TV Chapter 2 Installing the TV Chapter 3 USING THE FEATURES ........................................................................................34 ..............................TroubleShooting Display Mode... -
Page 8: Chapter 1 Introducing The Tv
Chapter 1 Introducing the TV Chapter 1 Introducing the TV Key Features Multiple Audio/Video Inputs and Outputs for Easy, User-Friendly Connections Built-in TV tuner to receive HD ATSC High Definition Multimedia Interface (HDMI) HDTV Component Video Inputs 3D Digital Noise Reduction Film-Mode Detection (3:2 Reverse Pull Down) - Page 9 Chapter 1 Introducing the TV Package Contents POWER S.MODE P.MODE CAPTION SLEEP P.SIZE JUMP MUTE VOL. INPUT GUIDE EXIT INFO MENU LIST FAV.CH TIMER FREEZE...
- Page 10 Chapter 1 Introducing the TV Setting Up Your TV Stand...
- Page 11 Chapter 1 Introducing the TV 2.4 inch When installing the TV on the wall, allow some space between the TV and the wall (at least 2.4 inches). Verify your TV’s model and be sure to use the for assistance when installing the wall mounting kit.
- Page 12 Chapter 1 Introducing the TV Step1 Step2 Do not use caustic cleaners (porcelain, stainless steel, toilet, or oven cleaner etc.) on the remote, as it may cause damage.
- Page 13 Chapter 1 Introducing the TV Your TV VOL+- MENU INPUT...
- Page 14 Chapter 1 Introducing the TV ANTENNA EARPHONE VIDEO/AUDIO(L/R) IN HDMI IN ANTENNA IN DC IN VGA IN/AUDIO IN YPbPr IN //AUDIO IN COAXIAL ANTENNA IN...
- Page 15 Chapter 1 Introducing the TV Your Remote Control POWER S.MODE S.MODE P.MODE P.MODE CAPTION SLEEP P.SIZE P.SIZE CAPTION JUMP MUTE VOL. INPUT SLEEP GUIDE EXIT JUMP INFO MENU MUTE LIST FAV.CH TIMER FREEZE VOL.+- CH.+-...
- Page 16 Chapter 2 Installing the TV INPUT POWER Source Select S.MODE P.MODE CVBS CAPTION SLEEP P.SIZE HDMI GUIDE EXIT JUMP MUTE VOL. INPUT INFO GUIDE EXIT MENU LIST INFO MENU FAV.CH Pressing FAV.CH LIST FAV.CH TIMER FREEZE TIMER FREEZE In TV mode, pressing FREEZE to Effective range: The remote can control the TV from up to 197 inch away, if pointed directly at the...
-
Page 17: Chapter 2 Installing The Tv
Chapter 2 Installing the TV Chapter 2 Installing the TV Connecting a TV Cable or an Antenna & A 75-ohm system is generally a round cable (not included) with F- type connector that can easily be attached to a terminal without tools. - Page 18 Chapter 2 Installing the TV A. Combination VHF/UHF antenna ANTENNA B. Separate VHF and/or UHF antennas ANTENNA...
- Page 19 Chapter 2 Installing the TV A 75-ohm coaxial cable connector is built into the set for easy hookup. When connecting the 75-ohm coaxial cable to the set, connect the 75- ohm cable into the ANT. terminal. Some cable TV companies offer premium pay channels. Since the signals of these premium pay channels are scrambled, a cable TV converter/descrambler is generally provided to the subscriber by the cable TV company.
- Page 20 Chapter 2 Installing the TV ANTENNA IN ANTENNA ANTENNA Always disconnect the TV from the main voltage when the TV will not be used for a long period of time. The POWER button on the front panel is only used for switching the TV into standby, it does not disconnect the device from the main voltage.
- Page 21 Chapter 2 Installing the TV Press the MENU CHANNEL PICTURE SOUND CHANNEL PARENTAL SETUP OTHERS Signal Type Auto Channel Search CHANNEL Channel List Favorite List Channel Setting Execute Auto Channel Search :Go to Next Menu :Return :Select Menu MENU ENTER...
- Page 22 Chapter 2 Installing the TV Connecting an A/V Device with Composite Connector ANTENNA IN GAME CONSOLE VIDEO OUT DVD PLAYER press the INPUT CVBS and Not all A/V devices have the ability to connect to a TV. Please check your A/V devices user guide for compatibility.
- Page 23 Chapter 2 Installing the TV Connecting an A/V Device with Component(YPbPr) Connector ANTENNA IN GAME CONSOLE COMPONENT Pr/Cr Pb/Pb DVD PLAYER Not all A/V device have the ability to connect to a TV. Please check your A/V device user guide for compatibility. press the INPUT The component video jacks on your A/V device are sometimes labeled YPbPr, or YCbCr.
- Page 24 Chapter 2 Installing the TV Connecting an AV Equipment with HDMI Connector ANTENNA IN AV EQUIPMENT Press the Input HDMI The HDMI connector provides both video and audio signals, it’s not necessary to connect the audio cable.
- Page 25 Chapter 2 Installing the TV Connecting an AV Equipment with DVI Connector ANTENNA IN AUDIO DVI IN AV EQUIPMENT Press the Input HDMI If the TV is connected to AV equipment’s DVI connector, you will need an HDMI-to-DVI cable or an HDMI adapter(not supplied) and an audio cable.
- Page 26 Chapter 2 Installing the TV Connecting a PC ANTENNA IN Press the INPUT...
- Page 27 Chapter 2 Installing the TV Connecting an Audio Receiver or a Dolby Digital 5.1 Sound System ANTENNA IN Audio Receiver...
-
Page 28: Chapter 3 Using The Features
Chapter 3 Using the TV Chapter 3 USING THE FEATURES Wide Screen Viewing P-Size NORMAL FULL WIDE ZOOM WIDE and ZOOM are not available when you are watching 720p, 1080i, 1080p, VGA, or DVI source. - Page 29 Chapter 3 Using the TV Operating the Menu Press the MENU PICTURE MENU: SOUND MENU: PICTURE PICTURE SOUND Sound Settings Picture Settings Screen Settings Surround Mode PC Settings Analog Sound Stereo Color Temperature Normal Digital Sound English Advanced Picture Settings Other Settings Equalizer Settings :Return...
- Page 30 Chapter 3 Using the TV Customizing the PICTURE Settings Press the MENU PICTURE MENU PICTURE PICTURE Picture Settings Screen Settings PC Settings Color Temperature Normal Advanced Picture Settings :Go to Next Menu :Return :Select Menu MENU ENTER The available menu items are dependent on the input source being selected.All illustration is for reference only.
- Page 31 Chapter 3 Using the TV Screen settings SCREEN SETTINGS Screen Size Normal Auto Wide :Change Setting :Return :Select Menu MENU Screen size AutoWide PC Settings Auto Adjust Press the Horizontal Position: Vertical Position Clock Phase Reset Color Temperature Advanced Picture Settings ADVANCED PICTURE SETTINGS Dynamic Contrast Film Mode...
- Page 32 Chapter 3 Using the TV Customizing the SOUND Settings Press the MENU SOUND MENU SOUND Sound Settings Surround Mode Analog Sound Stereo Digital Sound English Other Settings Equalizer Settings :Return :Go to Next Menu MENU :Select Menu ENTER The available menu items are dependent on the input source being selected.All illustration is for reference only.
- Page 33 Chapter 3 Using the TV Others Settings OTHERS SETTINGS Speaker Digital Audio Output :Return :Enable/Disable MENU :Select Menu Speaker Digital Audio Output Equalizer Settings Equalizer SETTINGS User 500 1k :Change Setting :Return :Select Menu MENU...
- Page 34 Chapter 3 Using the TV Customizing the CHANNEL Settings Press the MENU CHANNEL CHANNEL MENU CHANNEL Channel List Favorite List Channel Setting Auto Channel Search Execute :Return :Go to Next Menu MENU :Select Menu ENTER The available menu items are dependent on the input source being selected.All illustration is for reference only.
- Page 35 Chapter 3 Using the TV Signal Type Auto Channel Search...
- Page 36 Chapter 3 Using the TV Customizing the PARENTAL Settings Press the MENU PARENTAL PARENTAL MENU PARENTAL CONTROL Lock Parental Control V-CHIP Change Password Front Panel Lock Source Lock :Return :Enter password MENU DIGITAL The available menu items are dependent on the input source being selected.All illustration is for reference only.
- Page 37 Chapter 3 Using the TV CANADA V-Chip ratings...
- Page 38 Chapter 3 Using the TV Block Unrated Show Downloadable Rating Clear Downloadable Date Change Password Front Panel Lock Source Lock...
- Page 39 Chapter 3 Using the TV Customizing the SETUP Settings Press the MENU SETUP SETUP MENU SETUP Closed Caption Menu Language English Clock :Go to Next Menu :Return :Select Menu MENU ENTER The available menu items are dependent on the input source being selected.All illustration is for reference only.
- Page 40 Chapter 3 Using the TV Digital CC Preset Digital CC Style Menu Language Clock CLOCK Time Zone Alaska Auto Clock Setup Time 2009-10-21 20:00:00 Week Of Date :Return :Change setting :Select Menu MENU Time Zone Auto Clock...
- Page 41 Chapter 3 Using the TV Using the Others Settings Press the MENU OTHERS Others MENU OTHERS Blue Back No Signal Power Off No Operation Power Off All Reset Execute Audio Only :On/Off :Return :Select Menu MENU ENTER The available menu items are dependent on the input source being selected.All illustration is for reference only.
-
Page 42: Troubleshooting
Specifications TROUBLESHOOTING Before consulting service personnel, check the following chart for a possible cause of the trouble and for a possible solution. TV will not turn on No picture, no sound INPUT Press the Poor picture, sound OK VIDEO Picture OK, poor sound MUTE Press the VOL+... - Page 43 Specifications SPECIFICATIONS...
-
Page 44: Display Mode
Specifications DISPLAY MODE Video signal: (VGA Standard) Horizontal Resolution (Dot X Line) Vertical Frequency(Hz) Frequency(kHz)
