Tested Ahri Combination Ratings - Carrier 24ANB1 Infinity Product Data

TESTED AHRI COMBINATION RATINGS*

NOTE: Ratings contained in this document are subject to change at any time.
For AHRI ratings certificates, please refer to the AHRI directory
Additional ratings and system combinations can be accessed via the Carrier database at:
For performance data at specific application &/or design conditions with various indoor unit combinations, the equipment
performance calculator can be accessed at :
Model Number
24ANB124A**31
24ANB136A**31
24ANB148A**31
24ANB160A**31
* AHRI = Air Conditioning, Heating & Refrigeration Institute
Energy Efficiency Ratio --- 80_F (26.6_C) indoor db/67_F (19.4_C) indoor wb & 95_F (35_C) outdoor wb.
EER
—
SEER — Seasonal Energy Efficiency Ratio
TDR — Time---Delay Relay. In most cases, only 1 method should be used to achieve TDR function. Using more than 1 method in a system may cause degradation in performance.
Use either the accessory Time---Delay Relay KAATD0101TDR or a furnace equipped with TDR. Most Carrier furnaces are equipped with TDR.
UI — User Interface
NOTES:
1. Ratings are net values reflecting the effects of circulating fan motor heat. Supplemental electric heat is not included.
2. Tested outdoor/indoor combinations have been tested in accordance with DOE test procedures for central air conditioners. Ratings for other combinations are determined under DOE
computer simulation procedures.
3. Determine actual CFM values obtainable for your system by referring to fan performance data in fan coil or furnace coil literature.
4. Do not apply with capillary tube coils as performance and reliability are affected.
www.ahridirectory.org
http://rpmob.wrightsoft.com/
CAPACITY
INDOOR MODEL
HIGH
FE5ANB004 26600
FE5ANB004 36000
FE4ANB006 48000
FE4ANB006 58000
www.MyCarrierRatings.com
AHRI STANDARD RATINGS --- COOLING
SEER
LOW
24000 21.0
33200 20.0
40000 18.0
46500 16.7
10
ID CFM
EER
HIGH LOW
15.0 800 800
14.7 1200 924
13.5 1400 1120
13.2 1625 1300
