Frigidaire FRS3R4E Factory Parts Catalog

Frigidaire FRS3R4E Factory Parts Catalog

Side by side refrigerator
Hide thumbs Also See for FRS3R4E:
Table of Contents

Advertisement

Quick Links

Download this manual
N58L00001.eps N58FCCBBB2.eps N58RCCBBB5.eps N58BAAAAA0.eps
N58SJCAAB15.eps N58TAAAAA7.eps N58CAAAAA10.eps N58XDAAAA1.eps
N58YBAAAA5.eps N58I1151.eps W241708401.eps S241708401.eps
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FRS3R4EBC FRS3R4EQC FRS3R4EWC
Series
R134a
Color
black
Volts
115
Wiring Diagram
241708401
Owner's Guide
241856000
Market
North America North America North America
Energy Guide
241585997
Service Data Sheet 240389629
Publication No.
5995494688
07/07/06
(EN/SERVICE/DCS)
137
R134a
R134a
bisque
white
115
115
241708401
241708401
241856000
241856000
241585997
241585997
240389629
240389629
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS3R4E
©
Copyright
All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS3R4E and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRS3R4E

Summary of Contents for Frigidaire FRS3R4E

  • Page 1 Product No. FRS3R4EBC FRS3R4EQC FRS3R4EWC Series R134a R134a R134a Color black bisque white Volts Wiring Diagram 241708401 241708401 241708401 Owner's Guide 241856000 241856000 241856000 Market North America North America North America Energy Guide 241585997 241585997 241585997 Service Data Sheet 240389629 240389629 240389629 SIDE-BY-SIDE...

  • Page 2: Freezer Door

    Publication No: 5995494688 FRS3R4E FREEZER DOOR N58FCCBBB2 07/07...
  • Page 3 FRS3R4E Publication No: 5995494688 FREEZER DOOR Model Index: A FRS3R4E (FRS3R4EBC) B FRS3R4E (FRS3R4EQC) C FRS3R4E (FRS3R4EWC) POS. NO PART NO. DESCRIPTION 241674808 A - - Gasket-frzr door, black, magnetic 241674804 - B C Gasket-frzr door, white, magnetic 240367301 A B C Bin-door, frzr-upper 240359001 A B C...

  • Page 4: Refrigerator Door

    Publication No: 5995494688 FRS3R4E REFRIGERATOR DOOR N58RCCBBB5 07/07...
  • Page 5 FRS3R4E Publication No: 5995494688 REFRIGERATOR DOOR Model Index: A FRS3R4E (FRS3R4EBC) B FRS3R4E (FRS3R4EQC) C FRS3R4E (FRS3R4EWC) POS. NO PART NO. DESCRIPTION 241674807 A - - Gasket-refr door, black, magnetic 241674803 - B C Gasket-refr door, white, magnetic 240363701 A B C Bin-door, 2-liter 240338303 A B C...
  • Page 6 Publication No: 5995494688 FRS3R4E CABINET 07/07...
  • Page 7 FRS3R4E Publication No: 5995494688 CABINET Model Index: A FRS3R4E (FRS3R4EBC) B FRS3R4E (FRS3R4EQC) C FRS3R4E (FRS3R4EWC) POS. NO PART NO. DESCRIPTION 240435911 A B C Cover-air duct 240475910 A B C Cover-evap coil, lower 5303208309 A B C Plug-hole, factory test 14 # 240505801 A B C...
  • Page 8 Publication No: 5995494688 FRS3R4E SHELVES N58SJCAAB15 07/07...
  • Page 9 FRS3R4E Publication No: 5995494688 SHELVES Model Index: A FRS3R4E (FRS3R4EBC) B FRS3R4E (FRS3R4EQC) C FRS3R4E (FRS3R4EWC) POS. NO PART NO. DESCRIPTION 241657601 A B C Shelf, flip up, wire 241657501 A B C Shelf, fixed, freezer 241657503 A B C Shelf, fixed upper, freezer 5304455658 A B C...
  • Page 10 Publication No: 5995494688 FRS3R4E CONTROLS N58TAAAAA7 07/07...
  • Page 11 FRS3R4E Publication No: 5995494688 CONTROLS Model Index: A FRS3R4E (FRS3R4EBC) B FRS3R4E (FRS3R4EQC) C FRS3R4E (FRS3R4EWC) POS. NO PART NO. DESCRIPTION 5308000010 A B C Fan Blade, red, evaporator fan 215474201 A B C Washer, "slinger", nylon, evap fan shaft 241563601 A B C Bushing-motor mtg, (2)
  • Page 12 Publication No: 5995494688 FRS3R4E SYSTEM N58CAAAAA10 07/07...
  • Page 13 FRS3R4E Publication No: 5995494688 SYSTEM Model Index: A FRS3R4E (FRS3R4EBC) B FRS3R4E (FRS3R4EQC) C FRS3R4E (FRS3R4EWC) POS. NO PART NO. DESCRIPTION 240333602 A B C Condenser 218679606 A B C Block-evap coil, styrofoam, (2) 218944001 A B C Drier-filter, R134a System 241586801 A B C Harness-wiring, machine compt...

  • Page 14: Ice And Water Dispenser

    Publication No: 5995494688 FRS3R4E ICE & WATER DISPENSER 07/07...
  • Page 15 FRS3R4E Publication No: 5995494688 ICE & WATER DISPENSER Model Index: A FRS3R4E (FRS3R4EBC) B FRS3R4E (FRS3R4EQC) C FRS3R4E (FRS3R4EWC) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube, water, door 218976915 A B C Tube-water inlet, inlet valve, to filter 218976419 A B C Tube-water inlet, valve to door...

  • Page 16: Ice Container

    Publication No: 5995494688 FRS3R4E ICE CONTAINER 37A 34 34 33 N58YBAAAA5 07/07...
  • Page 17 FRS3R4E Publication No: 5995494688 ICE CONTAINER Model Index: A FRS3R4E (FRS3R4EBC) B FRS3R4E (FRS3R4EQC) C FRS3R4E (FRS3R4EWC) POS. NO PART NO. DESCRIPTION 241716101 A B C Auger-ice 241685201 A B C Cam-drive 241734001 A B C Container-ice, bucket only 241685101 A B C Drum-ice disp 241734201...

  • Page 18: Ice Maker

    Publication No: 5995494688 FRS3R4E ICE MAKER 07/07...
  • Page 19 FRS3R4E Publication No: 5995494688 ICE MAKER Model Index: A FRS3R4E (FRS3R4EBC) B FRS3R4E (FRS3R4EQC) C FRS3R4E (FRS3R4EWC) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube, water, door 218976419 A B C Tube-water inlet, valve to door 218976420 A B C Tube-water inlet, inlet valve, to filter 218976915 A B C...
  • Page 20 Publication No: 5995494688 FRS3R4E ICE MAKER 07/07...
  • Page 21 FRS3R4E Publication No: 5995494688 ICE MAKER Model Index: A FRS3R4E (FRS3R4EBC) B FRS3R4E (FRS3R4EQC) C FRS3R4E (FRS3R4EWC) POS. NO PART NO. DESCRIPTION 240363602 A B C Screw-shoulder 240542901 A B C Cap-water valve 5303207328 A B C Screw, hex washer head, 8-15A x 1.000, (2) 5304456686 A B C Bracket-leveling, ICE MAKER...

  • Page 22: Wiring Schematic

    Publication No: 5995494688 FRS3R4E WIRING SCHEMATIC 07/07...

  • Page 23: Wiring Diagram

    FRS3R4E Publication No: 5995494688 WIRING DIAGRAM 07/07 # Functional Parts * Non-Illustrated Parts...
