N58L00002.eps N58FAAAAB4.eps N58RAAABB5.eps N58BAAAAA0.eps
N58SJCACA24.eps N58TAAAAA7.eps N58CAAAAA10.eps N58XCAAAA2.eps
N58YCAAAA4.eps N58I1151.eps W241708401.eps S241708401.eps
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FRS3R2FW0
Series
R134a
Color
white
Volts
115
Wiring Diagram
241708401
Owner's Guide
241856000
Market
North America
Energy Guide
241615442
Service Data Sheet 240389629
Publication No.
5995503496
07/11/01
(EN/SERVICE/DCS)
137
Copyright
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS3R2F
©
All rights reserved.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRS3R2F
Summary of Contents for Frigidaire FRS3R2F
- Page 1 Product No. FRS3R2FW0 Series R134a Color white Volts Wiring Diagram 241708401 Owner's Guide 241856000 Market North America Energy Guide 241615442 Service Data Sheet 240389629 SIDE-BY-SIDE N58L00002.eps N58FAAAAB4.eps N58RAAABB5.eps N58BAAAAA0.eps REFRIGERATOR N58SJCACA24.eps N58TAAAAA7.eps N58CAAAAA10.eps N58XCAAAA2.eps N58YCAAAA4.eps N58I1151.eps W241708401.eps S241708401.eps Model No. North &...
-
Page 2: Freezer Door
Publication No: 5995503496 FRS3R2FW0 FREEZER DOOR 11/07... - Page 3 FRS3R2FW0 Publication No: 5995503496 FREEZER DOOR POS. NO PART NO. DESCRIPTION 241786004 Gasket-frzr door, white, magnetic 240367301 Bin-door, frzr-upper 240359001 Bin-door 241668103 Door-frzr, white, complete assy 240581902 Door Stop, white, frzr 218762701 Handle-door, white 240598402 Screw, 10-32 x 1/2 218781101 Screw, pan head, 8-18 x 0.625 240328202 Bearing-hinge(frz), closer...
-
Page 4: Refrigerator Door
Publication No: 5995503496 FRS3R2FW0 REFRIGERATOR DOOR N58RAAABB5 11/07... - Page 5 FRS3R2FW0 Publication No: 5995503496 REFRIGERATOR DOOR POS. NO PART NO. DESCRIPTION 241786003 Gasket-refr door, white, magnetic 240363701 Bin-door, 2-liter 240581901 Door Stop, white, refr 240451911 Door-refr, white, complete assy 218762701 Handle-door, white 240598402 Screw, 10-32 x 1/2 218781101 Screw, pan head, 8-18 x 0.625 240328201 Bearing-hinge(ref), closer 240328402...
- Page 6 Publication No: 5995503496 FRS3R2FW0 CABINET 11/07...
- Page 7 FRS3R2FW0 Publication No: 5995503496 CABINET POS. NO PART NO. DESCRIPTION 240435911 Cover-air duct 240475910 Cover-evap coil, lower 5303208309 Plug-hole, factory test 14 # 240505801 Switch, light/lamp 241547901 Switch-light/lamp, frzr door 218252201 Screw, #8 truss hd, 10-32CA x 0.500 240457701 Plate-door closer 240402702 Screw-#10-32 x 1/4 flat hd 241708801...
- Page 8 Publication No: 5995503496 FRS3R2FW0 SHELVES N58SJCACA24 11/07...
- Page 9 FRS3R2FW0 Publication No: 5995503496 SHELVES POS. NO PART NO. DESCRIPTION 241657601 Shelf, flip up, wire 241657501 Shelf, fixed, freezer 241657503 Shelf, fixed upper, freezer 5304455658 Screw, hx wshr hd sems, 8-15A x 0.625 240373107 Frame-refr shelf, cantilever 240354502 Cover-crisper pan, upper 240354602 Cover-crisper pan, lower 240354703...
- Page 10 Publication No: 5995503496 FRS3R2FW0 CONTROLS N58TAAAAA7 11/07...
- Page 11 FRS3R2FW0 Publication No: 5995503496 CONTROLS POS. NO PART NO. DESCRIPTION 5308000010 Fan Blade, red, evaporator fan 215474201 Washer, "slinger", nylon, evap fan shaft 241563601 Bushing-motor mtg, (2) 240369702 Motor-evap fan 241517701 Clip, evap fan motor 241555401 Light Bulb 16 # 241513901 Socket-light 240374006...
- Page 12 Publication No: 5995503496 FRS3R2FW0 SYSTEM N58CAAAAA10 11/07...
- Page 13 FRS3R2FW0 Publication No: 5995503496 SYSTEM POS. NO PART NO. DESCRIPTION 240333602 Condenser 218679606 Block-evap coil, styrofoam, (2) 218944001 Drier-filter, R134a System 241586801 Harness-wiring, machine compt 6* # 241651601 Harness-wiring 6* # 241735702 Harness-wiring, control box 14 # 240316107 Heater-defrost 15 # 5303918286 Evaporator Kit 5308000110...
-
Page 14: Ice And Water Dispenser
Publication No: 5995503496 FRS3R2FW0 ICE & WATER DISPENSER N58XCAAAA2 11/07... - Page 15 FRS3R2FW0 Publication No: 5995503496 ICE & WATER DISPENSER POS. NO PART NO. DESCRIPTION 218976409 Tube, water, door 218976419 Tube-water inlet, valve to door 218976420 Tube-water inlet, inlet valve, to filter 218976915 Tube-water inlet, inlet valve, to filter 240561701 Seal-water inlet, inlet valve, to ice maker 241678705 Cover-module, white 241680501...
-
Page 16: Ice Container
Publication No: 5995503496 FRS3R2FW0 ICE CONTAINER N58YCAAAA4 11/07... - Page 17 FRS3R2FW0 Publication No: 5995503496 ICE CONTAINER POS. NO PART NO. DESCRIPTION 241716101 Auger-ice 241685201 Cam-drive 241734001 Container-ice, bucket only 241685101 Drum-ice disp 241734201 Front-ice container 241726501 Bar-drive 241685301 Gate 15 # 240436702 Light Bulb/Lamp, A-15, clear, 40 W, 120 V, miniature 241559801 Socket-light 241684501...
-
Page 18: Ice Maker
Publication No: 5995503496 FRS3R2FW0 ICE MAKER 11/07... - Page 19 FRS3R2FW0 Publication No: 5995503496 ICE MAKER POS. NO PART NO. DESCRIPTION 218976409 Tube, water, door 218976419 Tube-water inlet, valve to door 218976420 Tube-water inlet, inlet valve, to filter 218976915 Tube-water inlet, inlet valve, to filter 240561701 Seal-water inlet, inlet valve, to ice maker 5304456650 Spring-shutoff arm, ICE MAKER 5304456657...
- Page 20 Publication No: 5995503496 FRS3R2FW0 ICE MAKER 11/07...
- Page 21 FRS3R2FW0 Publication No: 5995503496 ICE MAKER POS. NO PART NO. DESCRIPTION 5303207328 Screw, hex washer head, 8-15A x 1.000, (2) 5304456686 Bracket-leveling, ICE MAKER 5304456687 Screw-IM brkt mtg, special, 8-32D x 0.375 5303001549 Clamp, 0.31 ID, steel, copper wtr line 241642501 Ice Maker, radius cube, 115 V, Svce 241642601...
-
Page 22: Wiring Schematic
Publication No: 5995503496 FRS3R2FW0 WIRING SCHEMATIC 11/07... -
Page 23: Wiring Diagram
FRS3R2FW0 Publication No: 5995503496 WIRING DIAGRAM 11/07 # Functional Parts * Non-Illustrated Parts...
