Frigidaire FRS3R4E Factory Parts Catalog
Side by side refrigerator
Hide thumbs
Also See for FRS3R4E:
- Factory parts catalog (24 pages) ,
- Factory parts catalog (22 pages) ,
- Factory parts catalog (24 pages)
Table of Contents
Advertisement
Quick Links
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet 240389616
N58L00001.eps N58FCCBBB2.eps N58RCCBBB5.eps N58BAAAAA0.eps
N58SJCAAB12.eps N58TAAAAA6.eps N58CAAAAA5.eps N58XDAAAA1.eps
N58YBAAAA0.eps N58I115.eps W241526901A.eps S241526901A.eps
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
FRS3R4EB1 FRS3R4EB3 FRS3R4EQ1 FRS3R4EQ3 FRS3R4EW1 FRS3R4EW3
R134a
R134a
R134a
black
black
bisque
115
115
115
241526901
241526901
241526901
241661500
241661500
241661500
North America North America North America North America North America North America
241585997
241585997
241585997
240389616
240389616
Publication No.
5995444493
05/08/11
(EN/SERVICE/DCS)
357
R134a
R134a
R134a
bisque
white
white
115
115
115
241526901
241526901
241526901
241661500
241661500
241661500
241585997
241585997
241585997
240389616
240389616
240389616
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS3R4E
©
Copyright
All rights reserved.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FRS3R4E
Summary of Contents for Frigidaire FRS3R4E
- Page 1 Product No. FRS3R4EB1 FRS3R4EB3 FRS3R4EQ1 FRS3R4EQ3 FRS3R4EW1 FRS3R4EW3 Series R134a R134a R134a R134a R134a R134a Color black black bisque bisque white white Volts Wiring Diagram 241526901 241526901 241526901 241526901 241526901 241526901 Owner's Guide 241661500 241661500 241661500 241661500 241661500 241661500 Market North America North America North America North America North America North America Energy Guide 241585997...
-
Page 2: Freezer Door
Publication No: 5995444493 FRS3R4EB FREEZER DOOR N58FCCBBB2 08/05... - Page 3 FRS3R4EB Publication No: 5995444493 FREEZER DOOR Model Index: A FRS3R4E (FRS3R4EB1) B FRS3R4E (FRS3R4EB3) C FRS3R4E (FRS3R4EQ1) D FRS3R4E (FRS3R4EQ3) E FRS3R4E (FRS3R4EW1) F FRS3R4E (FRS3R4EW3) POS. NO PART NO. DESCRIPTION 241569808 A B - - - - Gasket-frzr door, black, magnetic 241569804 - - C D E F Gasket-frzr door, white, magnetic...
-
Page 4: Refrigerator Door
Publication No: 5995444493 FRS3R4EB REFRIGERATOR DOOR N58RCCBBB5 08/05... - Page 5 FRS3R4EB Publication No: 5995444493 REFRIGERATOR DOOR Model Index: A FRS3R4E (FRS3R4EB1) B FRS3R4E (FRS3R4EB3) C FRS3R4E (FRS3R4EQ1) D FRS3R4E (FRS3R4EQ3) E FRS3R4E (FRS3R4EW1) F FRS3R4E (FRS3R4EW3) POS. NO PART NO. DESCRIPTION 241569807 A B - - - - Gasket, refr door seal, black, magnetic 241569803 - - C D E F Gasket-refr door, white, magnetic...
- Page 6 Publication No: 5995444493 FRS3R4EB CABINET 08/05...
- Page 7 FRS3R4EB Publication No: 5995444493 CABINET Model Index: A FRS3R4E (FRS3R4EB1) B FRS3R4E (FRS3R4EB3) C FRS3R4E (FRS3R4EQ1) D FRS3R4E (FRS3R4EQ3) E FRS3R4E (FRS3R4EW1) F FRS3R4E (FRS3R4EW3) POS. NO PART NO. DESCRIPTION 240435905 A B C D E F Cover-air duct 240475906 A B C D E F Cover-evap coil, lower 5303208309...
- Page 8 Publication No: 5995444493 FRS3R4EB SHELVES N58SJCAAB12 08/05...
- Page 9 FRS3R4EB Publication No: 5995444493 SHELVES Model Index: A FRS3R4E (FRS3R4EB1) B FRS3R4E (FRS3R4EB3) C FRS3R4E (FRS3R4EQ1) D FRS3R4E (FRS3R4EQ3) E FRS3R4E (FRS3R4EW1) F FRS3R4E (FRS3R4EW3) POS. NO PART NO. DESCRIPTION 240338801 A - C - E - Shelf-freezer, flip-up 241657601 - B - D - F Shelf, flip up, wire 240338701...
- Page 10 Publication No: 5995444493 FRS3R4EB CONTROLS N58TAAAAA6 08/05...
- Page 11 FRS3R4EB Publication No: 5995444493 CONTROLS Model Index: A FRS3R4E (FRS3R4EB1) B FRS3R4E (FRS3R4EB3) C FRS3R4E (FRS3R4EQ1) D FRS3R4E (FRS3R4EQ3) E FRS3R4E (FRS3R4EW1) F FRS3R4E (FRS3R4EW3) POS. NO PART NO. DESCRIPTION 5308000010 A B C D E F Fan Blade, red, evaporator fan 215474201 A B C D E F Washer, "slinger", nylon, evap fan shaft...
- Page 12 Publication No: 5995444493 FRS3R4EB SYSTEM N58CAAAAA5 08/05...
- Page 13 FRS3R4EB Publication No: 5995444493 SYSTEM Model Index: A FRS3R4E (FRS3R4EB1) B FRS3R4E (FRS3R4EB3) C FRS3R4E (FRS3R4EQ1) D FRS3R4E (FRS3R4EQ3) E FRS3R4E (FRS3R4EW1) F FRS3R4E (FRS3R4EW3) POS. NO PART NO. DESCRIPTION 240333602 A B C D E F Condenser 218679606 A B C D E F Block-evap coil, styrofoam, (2) 218944001 A B C D E F...
-
Page 14: Ice And Water Dispenser
Publication No: 5995444493 FRS3R4EB ICE & WATER DISPENSER 08/05... - Page 15 FRS3R4EB Publication No: 5995444493 ICE & WATER DISPENSER Model Index: A FRS3R4E (FRS3R4EB1) B FRS3R4E (FRS3R4EB3) C FRS3R4E (FRS3R4EQ1) D FRS3R4E (FRS3R4EQ3) E FRS3R4E (FRS3R4EW1) F FRS3R4E (FRS3R4EW3) POS. NO PART NO. DESCRIPTION 218976409 A B C D E F Tube-water-DOOR 218976901 A B C D E F...
-
Page 16: Ice Container
Publication No: 5995444493 FRS3R4EB ICE CONTAINER 08/05... - Page 17 FRS3R4EB Publication No: 5995444493 ICE CONTAINER Model Index: A FRS3R4E (FRS3R4EB1) B FRS3R4E (FRS3R4EB3) C FRS3R4E (FRS3R4EQ1) D FRS3R4E (FRS3R4EQ3) E FRS3R4E (FRS3R4EW1) F FRS3R4E (FRS3R4EW3) POS. NO PART NO. DESCRIPTION 5304428402 A B C D E F Auger-ice 5304404343 A B C D E F Cam-drive 218815300...
-
Page 18: Ice Maker
Publication No: 5995444493 FRS3R4EB ICE MAKER 08/05... - Page 19 FRS3R4EB Publication No: 5995444493 ICE MAKER Model Index: A FRS3R4E (FRS3R4EB1) B FRS3R4E (FRS3R4EB3) C FRS3R4E (FRS3R4EQ1) D FRS3R4E (FRS3R4EQ3) E FRS3R4E (FRS3R4EW1) F FRS3R4E (FRS3R4EW3) POS. NO PART NO. DESCRIPTION 218976409 A B C D E F Tube-water-DOOR 218976901 A B C D E F Tube-water inlet, inlet valve, to ice maker 218976904...
- Page 20 Publication No: 5995444493 FRS3R4EB ICE MAKER 08/05...
- Page 21 FRS3R4EB Publication No: 5995444493 ICE MAKER Model Index: A FRS3R4E (FRS3R4EB1) B FRS3R4E (FRS3R4EB3) C FRS3R4E (FRS3R4EQ1) D FRS3R4E (FRS3R4EQ3) E FRS3R4E (FRS3R4EW1) F FRS3R4E (FRS3R4EW3) POS. NO PART NO. DESCRIPTION 5308000133 A B C D E F Clamp, nylon, .625 ID 240387101 A B C D E F Tube-water, ice mold fill, extension...
-
Page 22: Wiring Schematic
Publication No: 5995444493 FRS3R4EB WIRING SCHEMATIC 08/05... -
Page 23: Wiring Diagram
FRS3R4EB Publication No: 5995444493 WIRING DIAGRAM 08/05 # Functional Parts * Non-Illustrated Parts...
