  • Page 1 CDA-7892E FM/AM CD Receiver • OWNER'S MANUAL Please read before using this equipment. ALPINE ELECTRONICS, INC. ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. Tokyo office: 1-1-8 Nishi Gotanda, Shinagawa-ku, Tokyo 141-8501, Japan Tel.: (03) 3494-1101 ALPINE ELECTRONICS OF AMERICA, INC. 19145 Gramercy Place, Torrance, California 90501, U.S.A.
  • Page 2 CHA-S634 CHA-1214 • CD changer for CDA-7892E. • CD changer for CDA-7892E. • CDA-7892E 用 CD 換碟機。 • CDA-7892E 用 CD 換碟機。 Alpine CD Changers Give You More! More musical selections, more versatility, more convenience. The CHA-S634 is a high-performance 6-disc changer with a new M DAC, CD-R/RW PLAY BACK, MP3 PLAY BACK and CD TEXT.

  • Page 3: Table Of Contents

    Contents Operating Instructions WARNING WARNING ... 2 CAUTION ... 2 PRECAUTIONS ... 2 Basic Operation Detaching the Front Panel ... 4 Attaching the Front Panel ... 4 Initial System Start-Up ... 4 Turning Power On and Off ... 4 Display Angle Adjustment ... 5 Adjusting Volume/Balance (Between Left and Right)/Fader (Between Front and Rear)/ Defeat ...

  • Page 4: Warning

    HALT USE IMMEDIATELY IF A PROBLEM APPEARS. Failure to do so may cause personal injury or damage to the product. Return it to your authorized Alpine dealer or the nearest Alpine Service Center for repairing. KEEP FINGERS AWAY WHILE THE MOTORIZED FRONT PANEL OR MOVING MONITOR IS IN MOTION.
  • Page 5 Use of special shape discs may cause damage to the mechanism. Installation Location Make sure the CDA-7892E will not be installed in a location subjected to: • Direct sun and heat • High humidity and water •...

  • Page 6: Basic Operation

    • Attaching the front panel carefully, holding the sides of the front panel to avoid pushing buttons by mistake. • Controllable with Remote Control This unit can be controlled with an optional Alpine remote control. For details, consult your Alpine dealer. • Point the optional remote control transmitter at the remote control sensor.

  • Page 7: Display Angle Adjustment

    Display Angle Adjustment Movable display The movable display may be adjusted to 3 different angles depending upon user preference. Press the ANGLE 89 button to adjust the angle of the movable display. NOTES • The display will close a half minute after the ignition key is turned to the OFF position.

  • Page 8: Setting The Bass Control

    Basic Operation g DN BAND f UP X-OVER CENTER f Setting the Bass Control You can change the Bass Frequency emphasis to create your own tonal preference. Press the CENTER f button to select the BASS (bass Center frequency) control mode. →...

  • Page 9: About The Time Correction

    To correct this, the CDA-7892E is able to delay the audio signal to the speakers closest to the listener. This effectively creates a perception of increased distance for those speakers.

  • Page 10: Bass Focus

    Basic Operation Rotary encoder SOURCE BAND T. CORR Bass Focus The time difference between the front-rear/left-right speakers, can be adjusted at the same time. With an initial delay of 0.1 ms for each of the 0 to 99 steps, audible time correction can be done. Press the T.CORR button to select the Bass Focus mode.

  • Page 11: Time Correction

    Time Difference Table Time Time Number of Number of Difference Difference Steps Steps (ms) (ms) Time Correction Before performing the following procedures, refer to "About the Time Correction" (page 7). Select the time correction mode by pressing the T.CORR button. Each press changes the modes as follows: →...

  • Page 12: Quick Searching Function

    Basic Operation SOURCE DISP Rotary encoder/Q.S. g DN TITLE f UP Quick Searching Function You can easily select the tracks and files. Press the SOURCE button to set the desired source mode. ( CD mode is explained here as an example) When setting the CD mode, press and hold the Q.S.

  • Page 13: Titling Discs/Stations

    ∗1 The display is shown with a CD-TEXT compatible changer is connected. Displayed during playback of a disc with CD Text. “NO TEXT” will be displayed when the CD contains no Text data. ∗2 If an MP3 file contains ID3 tag information, all the ID3 tag information is displayed (e.g., track name, artist name, and album name).

  • Page 14: Setup Operation

    SETUP g DN f UP Switching the Tuner Mode The CDA-7892E incorporates the MAX TUNE SQ for the highest quality tuner audio. Moreover, you can choose between two settings to suit your own personal sound preferences and usage. Press and hold the SETUP button for at least 3 seconds.

  • Page 15: Turning Mute Mode On/Off

    Turning Mute Mode On/Off If a device having the interrupt feature is connected, audio will be automatically muted whenever the interrupt signal is received from the device. This function can be turned ON or OFF from the head unit by following procedure below.

  • Page 16: Connecting To An External Amplifier

    SETUP Operation BAND SETUP g DN f UP Connecting to an External Amplifier When an external amplifier is connected, sound quality can be improved by stopping the power supply of the buit-in amplifier. The power output is set to OFF by the following procedure.

  • Page 17: Setting The Defeat Of The External Input

    Setting the Defeat of the External Input When auxiliary devices such as a TV or video game etc. are used with this unit, you can use the audio function to set the mode between BASS, TREBLE and MX Defeat ON/OFF. Press and hold the SETUP button for at least 3 seconds.

  • Page 18: Radio Operation

    Radio Operation BAND TUNE/A.ME SOURCE f UP Preset buttons (1 through 6) g DN Manual Tuning Press the SOURCE button until a radio frequency appears in the display. Press the BAND button repeatedly until the desired radio band is displayed. Each press changes the band: →...

  • Page 19: Manual Storing Of Station Presets

    Manual Storing of Station Presets Select the radio band and tune in a desired radio station you wish to store in the preset memory. Press and hold any one of the Preset buttons (1 through 6) that you want to store the station on for at least 2 seconds.

  • Page 20: Cd Player Operation

    CD Player Operation SOURCE REPEAT M.I.X. f UP g DN Opening and Closing the Movable display Press the c button. The movable display will open. To close the movable display, press the c button again. The movable display will close. NOTES •...

  • Page 21: M.i.x. (Random Play)

    Music Sensor (Skip) Momentarily press the g DN button once during CD play to return to the beginning of the current track. If you wish to access the beginning of a track further back, repeatedly press until you reach the desired track.

  • Page 22: Controlling Cd Changer (Optional)

    See the Multi-Changer Selection section on this page for selecting the CD Changers. NOTES • The controls on the CDA-7892E for CD Changer operation are operative only when a CD Changer is connected. • The “Changer” indicator illuminates when a CD Changer is connected.

  • Page 23: Mp3 Changer Operation (Optional)

    Playing MP3 Files If you connect a changer compatible with MP3, you can play CD-ROMs, CD-Rs, and CD-RWs containing MP3 files on the CDA-7892E. Press the SOURCE button to switch to the MP3 Changer mode. The display shows the disc number and file number.

  • Page 24: M.i.x. (Random Play)

    MP3 Changer Operation (Optional) BAND f UP g DN SETUP M.I.X. (Random Play) Perform the following operation within 5 seconds after the F button has been pressed and the FUNC indicator has lit. Press the M.I.X. button in the play or pause mode. The files on the disc will be played back in a random sequence.

  • Page 25: Information

    • Mechanical error - Press the c button. After the error indication disappears, insert the disc again. If the above-mentioned solution does not solve the problem, consult your nearest ALPINE dealer. MP3 (When a CD changer compatible with MP3 is connected) MP3 is not played back.

  • Page 26: Indication For Cd Changer

    2) When the error indication remains after ejecting, press the c button again. If the error indication still does not turn off after pressing the c button for a few times, consult your Alpine dealer. NOTE When the “ERROR” is displayed:...

  • Page 27: Specifications

    Specifications FM TUNER SECTION Tuning Range 87.5 – 108.0 MHz Mono Usable Sensitivity 9.3 dBf (0.8 µV/75 ohms) 50 dB Quieting Sensitivity 13.5 dBf (1.3 µV/75 ohms) Alternate Channel Selectivity 80 dB Signal-to-Noise Ratio 80 dB Stereo Separation 45 dB Capture Ratio 2.0 dB AM TUNER SECTION...

  • Page 28: Installation And Connections

    (e.g. on-board computer). Do not tap into these leads to provide power for this unit. When connecting the CDA-7892E to the fuse box, make sure the fuse for the intended circuit of the CDA-7892E has the appropriate amperage.

  • Page 29: Installation

    Connect each input lead coming from an amplifier or equalizer to the corresponding output lead coming from the left rear of the CDA-7892E. Connect all other leads of the CDA-7892E according to details described in the CONNECTlONS section.

  • Page 30: Connections

    Installation and Connections Connections Blue/White Pink/Black Choke coil Ai-NET NORM EQ/DIV Blue POWER ANT REMOTE TURN-ON AUDIO INTERRUPT IN IGNITION BATTERY Ignition Key Yellow Black Gray SPEAKER Gray/ RIGHT FRONT " Black Violet/ Black SPEAKER RIGHT REAR Violet Green SPEAKER Green/ &...

  • Page 31: System Switch

    • Connect the ground lead securely to a bare metal spot (remove any paint, dirt or grease if necessary) of the car chassis. • If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries various noise suppressors, contact them for further information.
