Frigidaire FRS6LE5H Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRS6LE5H
  6. Parts catalog
Frigidaire FRS6LE5H Parts Catalog

Frigidaire FRS6LE5H Parts Catalog

R134a series
Hide thumbs Also See for FRS6LE5H:
Table of Contents

Advertisement

Quick Links

Download this manual
N58L00002.eps N58FFDBBB1.eps N58RFDAAB2.eps N58BAAAAA2.eps
N58SJCAAB15.eps N58TCAAAA1.eps N58CAAAAA10.eps N58XEDAAA1.eps
N58YBAAAA4.eps N58I1151.eps W241725001.eps S241725001.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FRS6LE5HSB0
Series
R134a
Color
stain/blk
Volts
115
Wiring Diagram
241725001
Owner's Guide
241812901
Market
North America
Energy Guide
241768177
Service Data Sheet 240389633
Publication No.
5995490470
07/05/09
(EN/SERVICE/KHB)
137
Copyright
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS6LE5H
©
2007 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS6LE5H and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRS6LE5H

Summary of Contents for Frigidaire FRS6LE5H

  • Page 1 Product No. FRS6LE5HSB0 Series R134a Color stain/blk Volts Wiring Diagram 241725001 Owner's Guide 241812901 Market North America Energy Guide 241768177 Service Data Sheet 240389633 SIDE-BY-SIDE N58L00002.eps N58FFDBBB1.eps N58RFDAAB2.eps N58BAAAAA2.eps REFRIGERATOR N58SJCAAB15.eps N58TCAAAA1.eps N58CAAAAA10.eps N58XEDAAA1.eps N58YBAAAA4.eps N58I1151.eps W241725001.eps S241725001.eps Electrolux Major Appliances Model No.

  • Page 2: Freezer Door

    Publication No: 5995490470 FRS6LE5HSB0 FREEZER DOOR N58FFDBBB1 05/07...
  • Page 3 FRS6LE5HSB0 Publication No: 5995490470 FREEZER DOOR POS. NO PART NO. DESCRIPTION 241674806 Gasket-frzr door, black, magnetic 240334201 Bin-door, frzr-upper 240351601 Bin-door 241668194 Door-frzr, stainless, complete assy 240581906 Door Stop, black, frzr 240536818 Handle-door, stainless steel, with insert, & set screw 241601001 Wrench, allen 240598402...

  • Page 4: Refrigerator Door

    Publication No: 5995490470 FRS6LE5HSB0 REFRIGERATOR DOOR N58RFDAAB2 05/07...
  • Page 5 FRS6LE5HSB0 Publication No: 5995490470 REFRIGERATOR DOOR POS. NO PART NO. DESCRIPTION 241674805 Gasket-refr door, black, magnetic 240323002 Bin-door, pseudo, bottom 240326203 Door-dairy 240581905 Door Stop, black, ref 241534540 Door-refr, stainless steel, complete assy 240536818 Handle-door, stainless steel, with insert, & set screw 241601001 Wrench, allen 240598402...
  • Page 6 Publication No: 5995490470 FRS6LE5HSB0 CABINET N58BAAAAA2 05/07...
  • Page 7 FRS6LE5HSB0 Publication No: 5995490470 CABINET POS. NO PART NO. DESCRIPTION 240435912 Cover-air duct 240475911 Cover-evap coil, lower 5303208309 Plug-hole, factory test 240505801 Switch, light/lamp 241547901 Switch-light/lamp, frzr door 218252201 Screw, #8 truss hd, 10-32CA x 0.500 240457702 Plate-door closer 240402702 Screw-#10-32 x 1/4 flat hd 240335502 Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special...
  • Page 8 Publication No: 5995490470 FRS6LE5HSB0 SHELVES N58SJCAAB15 05/07...
  • Page 9 FRS6LE5HSB0 Publication No: 5995490470 SHELVES POS. NO PART NO. DESCRIPTION 241657602 Shelf, flip up, wire 241657502 Shelf, fixed, freezer 241657504 Shelf, fixed, upper, freezer 5304455658 Screw, hx wshr hd sems, 8-15A x 0.625, 21 240355208 Shelf-"Spill-Safe", fixed 240350702 Cover-crisper pan, upper 240362101 Clip-slide, cover-crisper 240350902...
  • Page 10 Publication No: 5995490470 FRS6LE5HSB0 CONTROLS N58TCAAAA1 05/07...
  • Page 11 FRS6LE5HSB0 Publication No: 5995490470 CONTROLS POS. NO PART NO. DESCRIPTION 5308000010 Fan Blade, red, evaporator fan 215474201 Washer, "slinger", nylon, evap fan shaft 241563601 Bushing-motor mtg, (2) 13 # 240369702 Motor-evap fan 241517701 Clip, evap fan motor 241555401 Light Bulb 16 # 241513901 Socket-light...
  • Page 12 Publication No: 5995490470 FRS6LE5HSB0 SYSTEM N58CAAAAA10 05/07...
  • Page 13 FRS6LE5HSB0 Publication No: 5995490470 SYSTEM POS. NO PART NO. DESCRIPTION 240333603 Condenser 218679607 Block-evap coil, styrofoam, (2) 218944001 Drier-filter, R134a System 241586801 Harness-wiring, machine compt 6* # 241651601 Harness-wiring 6* # 241737801 Harness-wiring, control box 14 # 240316107 Heater-defrost 15 # 5303918284 Evaporator Kit 5308000110...

  • Page 14: Ice And Water Dispenser

    Publication No: 5995490470 FRS6LE5HSB0 ICE & WATER DISPENSER 05/07...
  • Page 15 FRS6LE5HSB0 Publication No: 5995490470 ICE & WATER DISPENSER POS. NO PART NO. DESCRIPTION 218976409 Tube, water, door 218976901 Tube, water inlet, valve to IM 218976904 Tube-water inlet, valve to filter 218976907 Tube-water inlet, valve to door 240561701 Seal-water inlet, inlet valve, to ice maker 241679003 Cover-module, black 241680507...

  • Page 16: Ice Container

    Publication No: 5995490470 FRS6LE5HSB0 ICE CONTAINER 37A 34 34 33 N58YBAAAA4 05/07...
  • Page 17 FRS6LE5HSB0 Publication No: 5995490470 ICE CONTAINER POS. NO PART NO. DESCRIPTION 241716101 Auger-ice 241685201 Cam-drive 241734001 Container-ice, bucket only 241685101 Drum-ice disp 241734201 Front-ice container 241624801 Bar-drive 241685301 Gate 241555401 Light Bulb 241559801 Socket-light 241684501 Drive Blade 18 # 241676202 Motor-auger, 115V 240352602 Harness-wiring, icmkr/container...

  • Page 18: Ice Maker

    Publication No: 5995490470 FRS6LE5HSB0 ICE MAKER 05/07...
  • Page 19 FRS6LE5HSB0 Publication No: 5995490470 ICE MAKER POS. NO PART NO. DESCRIPTION 218976409 Tube, water, door 218976901 Tube, water inlet, valve to IM 218976904 Tube-water inlet, valve to filter 218976907 Tube-water inlet, valve to door 240561701 Seal-water inlet, inlet valve, to ice maker 5304456650 Spring-shutoff arm, ICE MAKER 5304456657...
  • Page 20 Publication No: 5995490470 FRS6LE5HSB0 ICE MAKER 05/07...
  • Page 21 FRS6LE5HSB0 Publication No: 5995490470 ICE MAKER POS. NO PART NO. DESCRIPTION 240542901 Cap-water valve 5303207328 Screw, hex washer head, 8-15A x 1.000, (2) 5304456686 Bracket-leveling, ICE MAKER 5304456687 Screw-IM brkt mtg, special, 8-32D x 0.375 5303001549 Clamp, 0.31 ID, steel, copper wtr line 218515401 Clip 218888001...

  • Page 22: Wiring Schematic

    Publication No: 5995490470 FRS6LE5HSB0 WIRING SCHEMATIC AIR FILTER B E T A C O N T R O L FF THERMISTOR FRZ THERMISTOR 05/07...

  • Page 23: Wiring Diagram

    FRS6LE5HSB0 Publication No: 5995490470 WIRING DIAGRAM WHITE WHITE GRAY GRAY 05/07 # Functional Parts * Non-Illustrated Parts...
