- Page 1 P/N 218931200 (9903)
-
Page 2: Product Registration
Register Your Product The self-addressed PRODUCT REGISTRATION CARD should be filled in completely, signed and returned to Frigidaire, or in Canada, Frigidaire Canada. For Your Safety Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this, or any other appliance. -
Page 3: Important Safety
• out of direct sunlight and away from range, dishwasher, or other heat sources, i f p o s s i b l e . • on a floor that is level and strong enough to support a fully loaded refrigerator. • where a water supply is available for automatic ice maker. -
Page 4: Connecting Ice Maker To Water Supply
The ice maker requires a 1/4 inch (6.4 mm) copper water supply line (with shut off) from your household water system. Allow enough tubing behind your refrigerator to permit moving out to clean floor. Water line kit 5308950117 is available through your Dealer at extra charge. This kit includes 25 ft (7.6 meters) of 1/4 inch diameter copper tubing plus parts to connect... -
Page 5: Energy Saving Ideas
Refrigerator midpoint Freezer midpoint • Install the refrigerator in the most cool part of the room, out of direct sunlight and away from heating ducts or registers. Do not place the refrigerator next to heat- producing appliances such as a range, oven or dishwasher. If this is not possible, a section of cabinetry or an added layer of insulation between the two appliances will help the refrigerator operate more efficiently. -
Page 6: Fresh Food Storage
Meat Keeper The Meat Keeper is located at the bottom of the refrigerator. The temperature in this compartment can be made colder than the rest of the refrigerator compart- ment by sliding the Chilled Air Control knob within the COLDEST or COLD range. -
Page 7: Automatic Ice And Water Dispenser
Replace light bulb with an appliance bulb of the same wattage. How the Water Dispenser Works The water tank is located behind the drawers in the refrigerator compartment. As the water is dispensed, the tank is automatically refilled. For proper operation of the dispenser, the supply water pressure must fall between 30 psi and 120 psi. -
Page 8: Water Dispenser
PureSource Plus ™ Ice and Water Filter NOTE: If you purchased a refrigerator with a PureSource Plus Water filter, please read the following use and care information. This ice and water filter system filters water to your ice maker and water dispenser. It is located... - Page 9 6 months, or 200 gallons. Also, if filter has been in a refrigerator that has not been in use for awhile (during moving for example), change filter before reinstalling refrigerator. Note dispenser system will also operate without filtration (with filter cartridge removed).
-
Page 10: Care And Cleaning
Periodically clean the condenser (black tubes and wires beneath the refrigerator, behind the toe grill). Do not allow lint or dust to accumulate on the coils. Insert a long handled brush or vacuum attachment between the two coils to bring the lint forward. - Page 11 If the refrigerator is going to be stored in an environment that will fall below freezing, or will see freezing temperatures during a move, the water in the Ice and Water system must be drained completely.
-
Page 12: Removing The Handles And Doors
3 . Carefully lift the door up and off the loosened lower hinge screw. Store the doors in a safe place until the refrigerator is moved to the desired location. Keep all hardware for reinstallation. -
Page 13: Avoid Service Checklist
Power outage. Check house lights. Call local electric company. Room or outside weather is hot. It is normal for the refrigerator to work longer under these conditions. Refrigerator has recently been disconnected for a period of time. It takes about 8-12 hours for the refrigerator to cool down completely. - Page 14 Allow 24 hours for the temperature to stabilize. Then, if refrigerator temperature is not right, set refrigerator control to a warmer setting. Refrigerator control is set too warm. Set refrigerator control to a colder setting. Allow 24 hours for the temperature to stabilize.
- Page 15 Door was closed too hard, causing other door to open slightly. Close both doors gently. Refrigerator is not level. It rocks on the floor when it is moved slightly. Be sure floor is level and solid, and can adequately support refrigerator. Adjust rollers as needed.
-
Page 16: Normal Operating Sounds
Light bulb is burned out. Replace bulb. Light switch is stuck. Light switch is located on interior door frame next to the temperature control in each compartment. Push in plunger to release. No electric current is reaching refrigerator. See Occurrence section RUNNING OF REFRIGERATOR... - Page 17 Your appliance is warranted by White Consolidated Industries, Inc. We authorize no person to change or add to any of our obligations under this warranty. Our obligations for service and parts under this warranty must be performed by Frigidaire or an authorized Frigidaire servicer.
-
Page 18: Service Information (Canada)
FRIGIDAIRE PARTS AND SERVICE depot. FRIGIDAIRE PARTS AND SERVICE All Frigidaire appliances are backed by FRIGIDAIRE PARTS AND SERVICE, one of Canada's largest parts and service networks. The Frigidaire reputation means you can enjoy complete professional service from one of our hundreds of trained technicians across the country. -
Page 19: Warranty In Canada
) Transportation damage. b ) Supply and replacement of porcelain, fuses, glass and light bulbs. Parts and service supplied or obtained from other than FRIGIDAIRE PARTS AND SERVICE or FRIGIDAIRE PARTS SERVICE authorized depots. d ) Proper installation, control setting and care of finish.
