● Under no circumstances should you attempt to repair the machine yourself. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning. Contact your local Service Force Centre. Always insist on genuine Electrolux spare parts.
Contents For the User Important Safety Information Your New Washing Machine Description of the Appliance Detergent dispenser drawer Child Safety Feature The Control Panel Operating sequence Washing 5 kg of white cotton at 95°C Load the laundry Measure out the detergent Measure out the fabric softener Select the required option Select the required programme...
Your New Washing Machine Your new washing machine meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption. ● Automatic cooling of the wash water to 60°C before draining, with the 95°C programme. This reduces thermal shock to fabrics, helping to prevent creasing.
The Control Panel 1 Detergent dispenser drawer The programme chart is in the interior part of the drawer. light AINS This light illuminates when the machine starts working and goes out when the “ ” 3 “ ” button By depressing this button the machine starts operating. When depressed again, the machine stops.
Operating Sequence Before the first wash, we recommend that you run a cotton cycle at 95°C, without any laundry in the machine, to remove any manufacturing residue from the drum and tub. Pour 1/2 a measure of detergent into the dispenser drawer and start the machine.
6. Start the programme Before starting up the machine check that: ● the appliance is plugged in ● the water supply tap is turned on ● the drain hose is correctly and securely positioned ● the door and the detergent dispenser drawer are closed.
WASHING 2 KG OF MIXED FABRICS AT 50°C Suppose you have 2 kg of lightly soiled mixed fabrics to wash. They are rather delicate fabrics and should not be washed at a high temperature. 1. Load the laundry Open the door by pulling the door handle outwards. Place the laundry in the drum, one item at a time, shaking them out as much as possible.
7. At the end of the programme The machine stops automatically. If the option has been selected, the RINSE HOLD machine will stop with the water left in the tub, to prevent the fabric from creasing. To drain only, select the drain programme “P”. To drain and spin, depress the RINSE HOLD again.
Washing Hints Do NOT overload the machine. Weigh the laundry the first few times you use the appliance. The average weights of the most common items are listed below as a guide: 1000g = 1 kg Sheet Pillow case Tablecloth Serviette Tea towel Linen hand towel...
Wash Care Symbols Wash care labels inside garments recommend how to launder your clothes with the best results. The care labelling code is in line with care labelling used in the rest of Europe. The symbols used make it easy to select the correct programme on your washing machine.
Washing Programmes Programmes for Cottons - Linens Wash programme/ Degree of soil Washing symbol and type of laundry Whites For heavy soiled cotton with prewash items. White cotton, for example very soiled Whites work garments, sheets, household linen, underwear, towels. White cotton or linen Whites for example normally...
Washing Programmes Programmes for Synthetics, Mixed fabrics, Wool and Delicates Degree of soil Wash programme/ and type of laundry Washing symbol Synthetic or mixed fabrics, underwear, Mixed fabrics coloured garments, non-shrink shirts, blouses. Lightly soiled Worn once synthetic or mixed fabrics Separate spin for hand Short spin...
Maintenance and Cleaning Before any maintenance or cleaning is carried out you must DISCONNECT the appliance from the electricity supply. Descaling The water we use normally contains lime. It is a good idea to periodically use a water softening powder in the machine.
Unscrew and remove the filter. Clean carefully under a fast running tap. Warning When the appliance is in use and depending on the programme selected there can be hot water in the filter. Never remove the filter during a wash cycle, always wait until the appliance has finished the cycle, and is empty.
Something Not Working Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your local Service Force Centre, please carry out the checks listed below. IMPORTANT: if you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee.
Service & Spare Parts In the event of your appliance requiring service, or if you wish to purchase spare parts, please contact your local Electrolux Service Force Centre by telephoning: 0870 5 929929 Your telephone call will be automatically routed to the Service Force Centre covering your post code area.
Standard guarantee conditions We, Electrolux undertake that if, within 12 months of the date of the purchase, this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option,...
Installation Instructions It is dangerous to alter the specifications or attempt to modify this product in any way. Care must be taken to ensure that the appliance does not stand on the electrical supply cable. Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person.
Unpacking All transit bolts and packing must be removed before using the appliance. You are advised to keep all the packaging for re-use in case the machine is to be transported again. Using a spanner unscrew and remove the rear right bolt. Lay the machine gently on its back, making sure that the hoses are not squashed.
Water inlet Connect the hose to a tap with a 3/4” thread. Do not use previously used hoses for water connection. Installation should comply with local water authority and building regulations’ requirements. The appliance must be connected to a cold water supply.
2. Onto a sink outlet spigot. If the outlet spigot has not been used before, remove any blanking plug that may be in place. Push the drain hose onto the spigot and secure with a clip if required, ensure a loop is formed in the drain hose (see diagram) to prevent waste from the sink entering the washing machine.
If you require any further advice please contact your local water authority. Electrical connection Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. WARNING: THIS APPLIANCE MUST BE EARTHED. The manufacturer declines any liability should this safety measure not be observed.
Building-in This appliance has been designed to be built into the kitchen furniture. The recess should have the dimensions shown in picture When installing the appliance into the kitchen furniture ensure, if possible, the hoses are placed in either of the two recesses on the back of the appliance.
Page 27
If the door has to be opened from left to right, invert the position of the plates (7), the magnet (4) and the plate (5) (Fig. B and E). Mount the countermagnet (6) and the hinges (1) as previously described. Recommendations regarding the construction and fitting of a base when the installation requires an...
