  • Page 1 USER MANUAL EFC70710...
  • Page 2 We were thinking of you when we made this product...

  • Page 3: Table Of Contents

    GUARANTEE CONDITIONS INSTALLATION INSTRUCTIONS ELECTRICAL CONNECTIONS INSTALLING THE COOKER HOOD Welcome to the world of Electrolux Thank you for choosing a fi rst class product from Electrolux, which hopefully will provide you with lots of pleasure in the future. The Electrolux...

  • Page 4: Important Safety Information

    • Under no circumstances should you attempt to repair the appliance yourself. Repairs carried out by inexperienced persons may cause injury or more serious malfunction. Refer to your local Electrolux Service Force Centre. Always insist on genuine spare parts.

  • Page 5: Your Appliance

    5 YOUR APPLIANCE AND OPERATING INSTRUCTIONS YOUR APPLIANCE...

  • Page 6: Operating Instructions

    6 electrolux YOUR APPLIANCE AND OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS The cooker hood is designed to extract unpleasant odours from the kitchen, it will not extract steam. Cooker Hood Controls The cooker hood functions are control- led by four push button switches locat- ed centrally in the control fascia.
  • Page 7 fi re. Do not leave naked fl ames under the cooker hood. Ensure heating areas on your hob are covered with pots and pans when using the hob and cooker hood simultaneously. mode electrolux 7...

  • Page 8: Maintenance And Cleaning

    8 electrolux MAINTENANCE AND CLEANING MAINTENANCE AND CLEANING Before carrying out any maintenance or cleaning isolate the cooker hood from the mains supply. The cooker hood must be kept clean, as a build up of grease or fat can be a fi...
  • Page 9 fi lters are not cleaned and replaced as recommended. This appliance can be a possible fi re hazard if the grease and charcoal fi l- ters are not cleaned and replaced as recommended. MAINTENANCE AND CLEANING activated electrolux 9...
  • Page 10 10 electrolux MAINTENANCE AND CLEANING Changing the Light Bulb 1. Remove the screw fi xing the lighting support, disconnect the cooker hood from the mains supply. 2. Pull the lighting support downwards. 3. Remove the light bulb by unscrewing it anticlockwise.

  • Page 11: Something Not Working

    • Tum off the hob and then wait for the device to reset. In-guarantee customers should ensure that the above checks have been made as the engineer will make a charge if the fault is not a mechanical or electri- cal breakdown. electrolux 11...

  • Page 12: Guarantee/Customer Service

    12 electrolux GUARANTEE/CUSTOMER SERVICE GUARANTEE/CUSTOMER SERVICE Standard guarantee conditions We, Electrolux, undertake that if within 12 months of the date of the purchase this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or...

  • Page 13: Guarantee Conditions

    • The appliance is installed and used accordance with issued by Electrolux and is only used within the home, i.e. is not used for commercial purposes. • The appliance accordance...
  • Page 14 +41 62 88 99 111 Industriestrasse 10, CH-5506 Mägenwil +38 61 24 25 731 Tržaška 132, 1000 Ljubljana Electrolux Slovakia s.r.o., Electrolux Domáce spotrebiče SK, +421 2 43 33 43 22 Seberíniho 1, 821 03 Bratislava +35 8 26 22 33 00 Konepajanranta 4, 28100 Pori Electrolux Service, S:t Göransgatan 143, S-105 45...

  • Page 15: Installation Instructions

    For more detailed information about recycling of this product, please contact your local council, your household waste disposal service or the shop where you purchased the product. INSTALLATION INSTRUCTIONS (LOWER SECTION) 220-240 V 50Hz (2 x 40 W) electrolux 15 54mm 280mm 540mm 598mm 520mm...

  • Page 16: Electrical Connections

    16 electrolux ELECTRICAL CONNECTIONS ELECTRICAL CONNECTIONS DOUBLE INSULATED DO NOT EARTH Electrical Requirements Any permanent electrical installation must comply with the latest I.E.E. Regulations and local Electricity Board regulations. For your own safety this should be undertaken by a qualifi ed electrician e.g.

  • Page 17: Installing The Cooker Hood

    Unpacking Before unpacking the cooker hood position the carton with the arrows pointing upwards as illustrated on the carton. INSTALLING THE COOKER HOOD electrolux 17...
  • Page 18 18 electrolux INSTALLING THE COOKER HOOD The cooker hood is made up of the following components: Ref Qty Product Components Hood body, complete with controls, lighting, fan and fi lters. Telescopic Chimney comprising: Upper section Lower section Extensions metal ø150-120 Ducting spigot ø120-125 Ducting fl...
  • Page 19 The hood is supplied suitable for recirculation with the charcoal fi lters fi tted. When used in the extraction mode (ducting) the charcoal fi lters are not required and must be removed and destroyed. 650mm clearance 650mm clearance 685mm clearance 787mm clearance electrolux 19...
  • Page 20 20 electrolux INSTALLING THE COOKER HOOD Fitting the Wall Brackets Wall marking: • Draw a vertical line on the supporting wall up to the ceiling, or as high as practical, at the centre of the area in which the hood will be installed.
  • Page 21 The ducting used must be manufactured from fi re retardent material conforming to the relevant British Standard or DIN 4102-B1. When the cooker hood is ducted to the outside the charcoal fi lter must be removed. INSTALLING THE COOKER HOOD electrolux 21...
  • Page 22 22 electrolux INSTALLING THE COOKER HOOD Recirculation The cooker hood is supplied specifi ed for use in the recirculation mode, with the charcoal fi lter fi tted. In the recirculation mode contaminated air is passed through the charcoal fi lter to be purifi...
  • Page 23 fi tted ensure that there is an adequa- te supply of air to the room. The cooker ducting (extraction mode) must never be connected to central heating fl ues, radiators or water heaters etc. INSTALLING THE COOKER HOOD electrolux 23...
  • Page 24 24 electrolux INSTALLING THE COOKER HOOD Electrical Connection and Working Test Before fi tting the chimney to the canopy make the electrical connection as described in the section titled “ELECTRICAL CONNECTION”. When the electrical connection has been made, test the three speed fan and worktop illumination.
  • Page 25 25...
  • Page 26 26...
  • Page 28 436003742_05 - 080707...
