Frigidaire FRS26HF7B Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRS26HF7B
  6. Factory parts catalog
Frigidaire FRS26HF7B Factory Parts Catalog

Frigidaire FRS26HF7B Factory Parts Catalog

Side by side refrigerator
Hide thumbs Also See for FRS26HF7B:
Table of Contents

Advertisement

Quick Links

Download this manual
PRODUCT NO.
BASE MODEL NO.
FRS26HF7BB3
FRS26HF7B
FRS26HF7BB4
FRS26HF7B
FRS26HF7BQ3
FRS26HF7B
FRS26HF7BQ4
FRS26HF7B
FRS26HF7BW3
FRS26HF7B
FRS26HF7BW4
FRS26HF7B
MARKET
North America
WIRING DIAGRAM - 240389609
OWNER'S GUIDE - 240389310
SERVICE DATA SHEET - 240389609
ELECTROLUX HOME PRODUCTS, INC
P.O. BOX 212378, Augusta, GA 30917
SERIES
COLOR
R134a
black
R134a
black
R134a
bisque
R134a
bisque
R134a
white
R134a
white
Publication No.
5995396891
031001
-EN/SERVICE/KHB
357
PARTS CATALO
VOLTS
115
115
115
115
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS26HF7B
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY
G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS26HF7B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRS26HF7B

Summary of Contents for Frigidaire FRS26HF7B

  • Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRS26HF7BB3 FRS26HF7B R134a black FRS26HF7BB4 FRS26HF7B R134a black FRS26HF7BQ3 FRS26HF7B R134a bisque FRS26HF7BQ4 FRS26HF7B R134a bisque FRS26HF7BW3 FRS26HF7B R134a white FRS26HF7BW4 FRS26HF7B R134a white MARKET North America WIRING DIAGRAM - 240389609 OWNER’S GUIDE - 240389310 SERVICE DATA SHEET - 240389609 SIDE BY SIDE...

  • Page 2: Freezer Door

    Publication number FRS26HF7B 5995396891 FREEZER DOOR 10/03...
  • Page 3 FRS26HF7B Publication No. 5995396891 FREEZER DOOR A = FRS26HF7B (FRS26HF7BB3) B = FRS26HF7B (FRS26HF7BB4) C = FRS26HF7B (FRS26HF7BQ3) D = FRS26HF7B (FRS26HF7BQ4) E = FRS26HF7B (FRS26HF7BW3) F = FRS26HF7B (FRS26HF7BW4) POS. NO PART NO DESCRIPTION 240390606 A B - - - - Gasket-frzr door,black ,magnetic 240390602 - - C D E F...

  • Page 4: Refrigerator Door

    Publication number FRS26HF7B 5995396891 REFRIGERATOR DOOR 10/03...
  • Page 5 FRS26HF7B Publication No. 5995396891 REFRIGERATOR DOOR A = FRS26HF7B (FRS26HF7BB3) B = FRS26HF7B (FRS26HF7BB4) C = FRS26HF7B (FRS26HF7BQ3) D = FRS26HF7B (FRS26HF7BQ4) E = FRS26HF7B (FRS26HF7BW3) F = FRS26HF7B (FRS26HF7BW4) POS. NO PART NO DESCRIPTION 240390605 A B - - - - Gasket-refr door,black ,magnetic 240390601 - - C D E F...
  • Page 6 Publication number FRS26HF7B 5995396891 CABINET 10/03...
  • Page 7 FRS26HF7B Publication No. 5995396891 CABINET A = FRS26HF7B (FRS26HF7BB3) B = FRS26HF7B (FRS26HF7BB4) C = FRS26HF7B (FRS26HF7BQ3) D = FRS26HF7B (FRS26HF7BQ4) E = FRS26HF7B (FRS26HF7BW3) F = FRS26HF7B (FRS26HF7BW4) POS. NO PART NO DESCRIPTION 240435902 A - C - E - Cover-air duct 240435904 - B - D - F...
  • Page 8 Publication number FRS26HF7B 5995396891 SHELVES 10/03...
  • Page 9 FRS26HF7B Publication No. 5995396891 SHELVES A = FRS26HF7B (FRS26HF7BB3) B = FRS26HF7B (FRS26HF7BB4) C = FRS26HF7B (FRS26HF7BQ3) D = FRS26HF7B (FRS26HF7BQ4) E = FRS26HF7B (FRS26HF7BW3) F = FRS26HF7B (FRS26HF7BW4) POS. NO PART NO DESCRIPTION 240434604 A B C D E F Trim-basket 240350668 A B C D E F...
  • Page 10 Publication number FRS26HF7B 5995396891 CONTROLS 10/03...
  • Page 11 FRS26HF7B Publication No. 5995396891 CONTROLS A = FRS26HF7B (FRS26HF7BB3) B = FRS26HF7B (FRS26HF7BB4) C = FRS26HF7B (FRS26HF7BQ3) D = FRS26HF7B (FRS26HF7BQ4) E = FRS26HF7B (FRS26HF7BW3) F = FRS26HF7B (FRS26HF7BW4) POS. NO PART NO DESCRIPTION 5308000010 A B C D E F Fan Blade,red ,evaporator fan 5300157666 A B C D E F...
  • Page 12 Publication number FRS26HF7B 5995396891 SYSTEM 10/03...
  • Page 13 FRS26HF7B Publication No. 5995396891 SYSTEM A = FRS26HF7B (FRS26HF7BB3) B = FRS26HF7B (FRS26HF7BB4) C = FRS26HF7B (FRS26HF7BQ3) D = FRS26HF7B (FRS26HF7BQ4) E = FRS26HF7B (FRS26HF7BW3) F = FRS26HF7B (FRS26HF7BW4) POS. NO PART NO DESCRIPTION 240333603 A B C D E F Condenser 218679607 A B C D E F...
  • Page 14 Publication number FRS26HF7B 5995396891 DISPENSER 10/03...
  • Page 15 FRS26HF7B Publication No. 5995396891 DISPENSER A = FRS26HF7B (FRS26HF7BB3) B = FRS26HF7B (FRS26HF7BB4) C = FRS26HF7B (FRS26HF7BQ3) D = FRS26HF7B (FRS26HF7BQ4) E = FRS26HF7B (FRS26HF7BW3) F = FRS26HF7B (FRS26HF7BW4) POS. NO PART NO DESCRIPTION 218976409 A B C D E F Tube-water 218976901 A B C D E F...

  • Page 16: Ice Container

    Publication number FRS26HF7B 5995396891 ICE CONTAINER 10/03...
  • Page 17 FRS26HF7B Publication No. 5995396891 ICE CONTAINER A = FRS26HF7B (FRS26HF7BB3) B = FRS26HF7B (FRS26HF7BB4) C = FRS26HF7B (FRS26HF7BQ3) D = FRS26HF7B (FRS26HF7BQ4) E = FRS26HF7B (FRS26HF7BW3) F = FRS26HF7B (FRS26HF7BW4) POS. NO PART NO DESCRIPTION 5304428402 A B C D E F Auger-ice 5304404343 A B C D E F...

  • Page 18: Ice Maker

    Publication number FRS26HF7B 5995396891 ICE MAKER 10/03...
  • Page 19 FRS26HF7B Publication No. 5995396891 ICE MAKER A = FRS26HF7B (FRS26HF7BB3) B = FRS26HF7B (FRS26HF7BB4) C = FRS26HF7B (FRS26HF7BQ3) D = FRS26HF7B (FRS26HF7BQ4) E = FRS26HF7B (FRS26HF7BW3) F = FRS26HF7B (FRS26HF7BW4) POS. NO PART NO DESCRIPTION 218976409 A B C D E F Tube-water 218976903 A B C D E F...

  • Page 20: Wiring Schematic

    Publication number FRS26HF7B 5995396891 WIRING SCHEMATIC 10/03...

  • Page 21: Wiring Diagram

    FRS26HF7B Publication No. 5995396891 WIRING DIAGRAM # = Fast-moving Parts 10/03 * = Non-Illustrated Parts...
