Use and Care Manual
PRODUCT NO.
BASE MODEL NO.
FRS20ZRGD0
FRS20ZRG
FRS20ZRGW0
FRS20ZRG
WIRING DIAGRAM - # 218682800
OWNER'S GUIDE - # 218815300
SERVICE DATA SHEET - # 218789700
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a
almond
R134a
white
Publication No.
5995310579
980716
-EN/SERVICE /JLT
357
SIDE BY SIDE
REFRIGERATOR
VOLTS
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS20ZRGW0
FRS20ZRGD0
©1998 White Consolidated Industries, Inc.
All rights reserved
Advertisement
Table of Contents
Related Manuals for Frigidaire FRS20ZRGD0
Summary of Contents for Frigidaire FRS20ZRGD0
-
Page 1: Side By Side
FACTORY PARTS CATALOG SIDE BY SIDE REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRS20ZRGD0 FRS20ZRG R134a almond FRS20ZRGW0 FRS20ZRG R134a white WIRING DIAGRAM - # 218682800 OWNER’S GUIDE - # 218815300 SERVICE DATA SHEET - # 218789700 SIDE BY SIDE REFRIGERATOR 101 Masters Blvd. -
Page 2: Freezer Door
Publication No. FRS20ZRGW0, FRS20ZRGD0 5995310579 FREEZER DOOR 07/98... - Page 3 FRS20ZRGW0, FRS20ZRGD0 Publication No. 5995310579 FREEZER DOOR A = FRS20ZRG (FRS20ZRGD0) B = FRS20ZRG (FRS20ZRGW0) POS. NO PART NO DESCRIPTION 215734301 Gasket-frzr door,almond ,magnetic 215734311 Gasket-frzr door,white ,magnetic 5303288950 Support-door rack,RH/LH 5303323484 Support-door rack,white ,LH 5303323485 Support-door rack,white ,RH 218807014 Rack-door,w/end caps 215474049 Rack-door...
-
Page 4: Refrigerator Door
Publication No. FRS20ZRGW0, FRS20ZRGD0 5995310579 REFRIGERATOR DOOR 07/98... - Page 5 FRS20ZRGW0, FRS20ZRGD0 Publication No. 5995310579 REFRIGERATOR DOOR A = FRS20ZRG (FRS20ZRGD0) B = FRS20ZRG (FRS20ZRGW0) POS. NO PART NO DESCRIPTION 215734302 Gasket-refr door,almond ,magnetic 215734312 Gasket-refr door,white ,magnetic 218749301 Panel-inner door,refr 218807013 Rack-door,w/end caps 5303288950 Support-door rack,RH/LH 5303308341 Door-dairy,12.96" wide 5303289522 Door Stop 5303917894...
- Page 6 Publication No. FRS20ZRGW0, FRS20ZRGD0 5995310579 CABINET 07/98...
- Page 7 FRS20ZRGW0, FRS20ZRGD0 Publication No. 5995310579 CABINET A = FRS20ZRG (FRS20ZRGD0) B = FRS20ZRG (FRS20ZRGW0) POS. NO PART NO DESCRIPTION 218748901 Cover-air duct 5303209814 Nut,"U" type ,8-15(A) ,fan mtr mtg 5303208309 Plug-hole,factory test 215230400 Plug-harness hole 5303289043 Support-air duct cvr,2.55" long 5303289044 Support-air duct cvr,1.83"...
- Page 8 Publication No. FRS20ZRGW0, FRS20ZRGD0 5995310579 SHELVES 07/98...
- Page 9 FRS20ZRGW0, FRS20ZRGD0 Publication No. 5995310579 SHELVES A = FRS20ZRG (FRS20ZRGD0) B = FRS20ZRG (FRS20ZRGW0) POS. NO PART NO DESCRIPTION 5303300707 Trim-basket 218298005 Shelf-freezer,sliding ,wire 218159700 Spacer-shelf 5303288962 Shelf-freezer,fixed wire 218746202 Shelf-"Spill-Safe",fixed ,(3) 218015301 Trim-storage pan cvr,snap-on ,front 218015401 Trim-storage pan cvr,snap-on ,rear 5303288971 Pan-storage,upper 5303288968...
- Page 10 Publication No. FRS20ZRGW0, FRS20ZRGD0 5995310579 CONTROLS 07/98...
- Page 11 FRS20ZRGW0, FRS20ZRGD0 Publication No. 5995310579 CONTROLS A = FRS20ZRG (FRS20ZRGD0) B = FRS20ZRG (FRS20ZRGW0) POS. NO PART NO DESCRIPTION 215028605 Knob-damper control 5308000010 Fan Blade,red 5308000124 Ring-fan orifice 5300157666 Bushing-motor mtg,(2) 5303205118 Bracket-motor mtg,front 215809600 Diffuser-air 13 # 215426200 Motor-evap fan 215474201 Washer,"slinger"...
- Page 12 Publication No. FRS20ZRGW0, FRS20ZRGD0 5995310579 SYSTEM 07/98...
- Page 13 FRS20ZRGW0, FRS20ZRGD0 Publication No. 5995310579 SYSTEM A = FRS20ZRG (FRS20ZRGD0) B = FRS20ZRG (FRS20ZRGW0) POS. NO PART NO DESCRIPTION 218787700 Condenser 5303289026 Spacer-tube 5303289029 Clip-cond mtg,(4) 218679603 Block-evap coil,styrofoam ,(2) 218541000 Drier-filter 218646100 Harness-wiring,main 215005200 Harness-wiring,refr controls 218646000 Harness-wiring,filter heater 218815101 Harness-wiring,frzr controls 218741400...
- Page 14 Publication No. FRS20ZRGW0, FRS20ZRGD0 5995310579 DISPENSER 07/98...
- Page 15 FRS20ZRGW0, FRS20ZRGD0 Publication No. 5995310579 DISPENSER A = FRS20ZRG (FRS20ZRGD0) B = FRS20ZRG (FRS20ZRGW0) POS. NO PART NO DESCRIPTION 5308010366 Tube-water inlet,93" ,plastic ,cut-to-length 215294101 Tube-water inlet,formed ,plastic ,dispenser 218658301 Tube-water inlet,filter ,to filter valve,w/elbow 218770401 Tube-water inlet,inlet valve ,to filter 218505302 Deflector-ice disp,almond 218505301...
-
Page 16: Ice Container
Publication No. FRS20ZRGW0, FRS20ZRGD0 5995310579 ICE CONTAINER 07/98... - Page 17 FRS20ZRGW0, FRS20ZRGD0 Publication No. 5995310579 ICE CONTAINER A = FRS20ZRG (FRS20ZRGD0) B = FRS20ZRG (FRS20ZRGW0) POS. NO PART NO DESCRIPTION 5304404344 Auger-ice 5304404343 Cam-drive 218815300 Container-ice 5304404346 Drum-ice disp 218815400 Front-ice container 5304404337 Bar-drive 5304404359 Gate 5303001179 Light Bulb/Lamp,40 W 5303289050 Socket-light/lamp 5304404345...
-
Page 18: Ice Maker
Publication No. FRS20ZRGW0, FRS20ZRGD0 5995310579 ICE MAKER 07/98... - Page 19 FRS20ZRGW0, FRS20ZRGD0 Publication No. 5995310579 ICE MAKER A = FRS20ZRG (FRS20ZRGD0) B = FRS20ZRG (FRS20ZRGW0) POS. NO PART NO DESCRIPTION 5308010366 Tube-water inlet,93" ,plastic ut-to-length 218658301 Tube-water inlet,filter ,to filter valve,w/elbow 218703400 Tube-water inlet,inlet valve ,to filter 218770401 Tube-water inlet,inlet valve ,to filter 3206348 Spring,shut-off arm 3206299...
