Frigidaire FRS20ZGJ Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRS20ZGJ
  6. Factory parts catalog
Frigidaire FRS20ZGJ Factory Parts Catalog

Frigidaire FRS20ZGJ Factory Parts Catalog

Side by side refrigerator
Hide thumbs Also See for FRS20ZGJ:
Table of Contents

Advertisement

Quick Links

PRODUCT NO.
BASE MODEL NO.
FRS20ZGJB1
FRS20ZGJ
FRS20ZGJD1
FRS20ZGJ
FRS20ZGJW1
FRS20ZGJ
MARKET
North America
WIRING DIAGRAM - # 218903201
OWNER'S GUIDE - # 218954000
SERVICE DATA SHEET - # 218909401
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a System
black
R134a
almond
R134a System
white
Publication No.
5995342564
000822
-EN/SERVICE /DJH
357

SIDE BY SIDE

REFRIGERATOR
VOLTS
115
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS20ZGJ
©2000 White Consolidated Industries, Inc.
All rights reserved

Advertisement

Table of Contents
loading

Related Manuals for Frigidaire FRS20ZGJ

Summary of Contents for Frigidaire FRS20ZGJ

  • Page 1: Side By Side

    PRODUCT NO. BASE MODEL NO. FRS20ZGJB1 FRS20ZGJ FRS20ZGJD1 FRS20ZGJ FRS20ZGJW1 FRS20ZGJ MARKET North America WIRING DIAGRAM - # 218903201 OWNER’S GUIDE - # 218954000 SERVICE DATA SHEET - # 218909401 101 Masters Blvd. Anderson, SC 29624 FACTORY PARTS CATALOG REFRIGERATOR...

  • Page 2: Freezer Door

    Publication No. FRS20ZGJ 5995342564 FREEZER DOOR 08/00...
  • Page 3 A = FRS20ZGJ (FRS20ZGJW1) B = FRS20ZGJ (FRS20ZGJD1) C = FRS20ZGJ (FRS20ZGJB1) POS. NO 37A* 37A* 37A* # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZGJ FREEZER DOOR PART NO DESCRIPTION 215734311 A B - Gasket-frzr door,white ,magnetic 215734321 - - C...

  • Page 4: Refrigerator Door

    Publication No. FRS20ZGJ 5995342564 REFRIGERATOR DOOR 08/00...
  • Page 5 A = FRS20ZGJ (FRS20ZGJW1) B = FRS20ZGJ (FRS20ZGJD1) C = FRS20ZGJ (FRS20ZGJB1) POS. NO 37A* 37A* 37A* # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZGJ REFRIGERATOR DOOR PART NO DESCRIPTION 215734312 A B - Gasket-refr door,white ,magnetic 215734322 - - C...
  • Page 6 Publication No. FRS20ZGJ 5995342564 CABINET 08/00...
  • Page 7 A = FRS20ZGJ (FRS20ZGJW1) B = FRS20ZGJ (FRS20ZGJD1) C = FRS20ZGJ (FRS20ZGJB1) POS. NO 30A* 101* 101* # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZGJ CABINET PART NO DESCRIPTION 218748901 A B C Cover-air duct 5303209814 A B C Nut,"U"...
  • Page 8 Publication No. FRS20ZGJ 5995342564 SHELVES 08/00...
  • Page 9 A = FRS20ZGJ (FRS20ZGJW1) B = FRS20ZGJ (FRS20ZGJD1) C = FRS20ZGJ (FRS20ZGJB1) POS. NO 100A 100B # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZGJ SHELVES PART NO DESCRIPTION 5303300707 A B C Trim-basket 218298005 A B C Shelf-freezer,sliding ,wire...
  • Page 10 Publication No. FRS20ZGJ 5995342564 CONTROLS 08/00...
  • Page 11 A = FRS20ZGJ (FRS20ZGJW1) B = FRS20ZGJ (FRS20ZGJD1) C = FRS20ZGJ (FRS20ZGJB1) POS. NO 13 # 21 # 23 # 114# 141# 141* 143* # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZGJ CONTROLS PART NO DESCRIPTION 5303307883 A B C...
  • Page 12 Publication No. FRS20ZGJ 5995342564 SYSTEM 08/00...
  • Page 13 A = FRS20ZGJ (FRS20ZGJW1) B = FRS20ZGJ (FRS20ZGJD1) C = FRS20ZGJ (FRS20ZGJB1) POS. NO 13 # 14 # 15 # 21 # 29 # 30 # 55 # 60 # # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZGJ SYSTEM...
  • Page 14 Publication No. FRS20ZGJ 5995342564 DISPENSER 08/00...
  • Page 15 A = FRS20ZGJ (FRS20ZGJW1) B = FRS20ZGJ (FRS20ZGJD1) C = FRS20ZGJ (FRS20ZGJB1) POS. NO 17A* 38 # # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZGJ DISPENSER PART NO DESCRIPTION 218832302 A B C Tube-water inlet,inlet valve ,to filter 218859901...

  • Page 16: Ice Container

    Publication No. FRS20ZGJ 5995342564 ICE CONTAINER 08/00...
  • Page 17 A = FRS20ZGJ (FRS20ZGJW1) B = FRS20ZGJ (FRS20ZGJD1) C = FRS20ZGJ (FRS20ZGJB1) POS. NO 18 # 45 # # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZGJ ICE CONTAINER PART NO DESCRIPTION 5304404344 A B C Auger-ice 5304404343 A B C...

  • Page 18: Ice Maker

    Publication No. FRS20ZGJ 5995342564 ICE MAKER 08/00...
  • Page 19 A = FRS20ZGJ (FRS20ZGJW1) B = FRS20ZGJ (FRS20ZGJD1) C = FRS20ZGJ (FRS20ZGJB1) POS. NO 11 # 12 # 13 # 15 # 17 # 55 # 141# 141* # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZGJ ICE MAKER PART NO...

  • Page 20: Wiring Schematic

    Publication No. FRS20ZGJ 5995342564 WIRING SCHEMATIC 08/00...

  • Page 21: Wiring Diagram

    FRS20ZGJ Publication No. 5995342564 WIRING DIAGRAM # = Fast-moving Parts 08/00 * = Non-Illustrated Parts...
