  • Page 1 FRS20ZSHB4 FRS20ZSH FRS20ZSHB5 FRS20ZSH North America ELECTROLUX HOME PRODUCTS NORTH AMERICA PO Box 212378, Augusta, GA 30917 PRO-GALLERY black/stainless PRO-GALLERY black/stainless Publication No. 5995347969 010102 -EN/SERVICE/KHB ©2001 White Consolidated Industries, Inc. All rights reserved...

  • Page 2: Freezer Door

    Publication No. FRS20ZSH 5995347969 FREEZER DOOR 01/01...
  • Page 3 A = FRS20ZSH (FRS20ZSHB4) B = FRS20ZSH (FRS20ZSHB5) # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZSH FREEZER DOOR 215734321 Gasket-frzr door,black ,magnetic 5303288950 Support-door rack,RH/LH 5303323484 Support-door rack,white ,LH 5303323485 Support-door rack,white ,RH 218807017 Rack-door,w/end caps 215474047 Rack-door 218748601...

  • Page 4: Refrigerator Door

    Publication No. FRS20ZSH 5995347969 REFRIGERATOR DOOR 01/01...
  • Page 5 A = FRS20ZSH (FRS20ZSHB4) B = FRS20ZSH (FRS20ZSHB5) # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZSH REFRIGERATOR DOOR 215734322 Gasket-refr door,black ,magnetic 218749301 Panel-inner door,refr 218807016 Rack-door,(2) 5303288950 Support-door rack,RH/LH 5303308347 Door-dairy,12.96" wide 218395401 Nameplate,black 5303289522 Door Stop 218618962...
  • Page 6 Publication No. FRS20ZSH 5995347969 CABINET 01/01...
  • Page 7 A = FRS20ZSH (FRS20ZSHB4) B = FRS20ZSH (FRS20ZSHB5) 10A* 30A* 101* # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZSH CABINET 218748901 Cover-air duct 5303209814 Nut,"U" type ,8-15A ,fan mtr mtg 218751303 Cover-evap coil,lower 5308009617 Washer,ext tooth lock ,#10 ,grounding...
  • Page 8 Publication No. FRS20ZSH 5995347969 SHELVES 01/01...
  • Page 9 A = FRS20ZSH (FRS20ZSHB4) B = FRS20ZSH (FRS20ZSHB5) 100A 100B # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZSH SHELVES 5303300707 Trim-basket 218298005 Shelf-freezer,sliding ,wire 218159700 Spacer-shelf 5304405990 Shelf-freezer, fixed wire 218746001 Shelf-"Spill-Safe", sliding ,(3) 218015301 Trim-storage pan cvr, snap-on ,front...
  • Page 10 Publication No. FRS20ZSH 5995347969 CONTROLS 01/01...
  • Page 11 A = FRS20ZSH (FRS20ZSHB4) B = FRS20ZSH (FRS20ZSHB5) 13 # 17A* 21 # 23 # 114# 141* # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZSH CONTROLS 5303307883 Knob-damper control,white/teal line 5308000010 Fan Blade,red ,evaporator fan 5308000124 Ring-fan orifice 5300157666...
  • Page 12 Publication No. FRS20ZSH 5995347969 SYSTEM 01/01...
  • Page 13 A = FRS20ZSH (FRS20ZSHB4) B = FRS20ZSH (FRS20ZSHB5) 13 # 14 # 15 # 21 # 29 # 30 # 55 # 60 # # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZSH SYSTEM 218787700 Condenser 5303208866 Spacer-cond tube,black 5303289026...
  • Page 14 Publication No. FRS20ZSH 5995347969 DISPENSER 01/01...
  • Page 15 A = FRS20ZSH (FRS20ZSHB4) B = FRS20ZSH (FRS20ZSHB5) 17A* 38 # # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZSH DISPENSER 218832302 Tube-water inlet,inlet valve to filter 218976910 Tube-water inlet,inlet valve to filter 218949201 Tube-water inlet,formed , plastic, dispenser 5308010366 Tube-water inlet,0.25 OD x 93"...

  • Page 16: Ice Container

    Publication No. FRS20ZSH 5995347969 ICE CONTAINER 01/01...
  • Page 17 A = FRS20ZSH (FRS20ZSHB4) B = FRS20ZSH (FRS20ZSHB5) 18 # 45 # # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZSH ICE CONTAINER 5304404344 Auger-ice 5304404343 Cam-drive 218815300 Container-ice,bucket only 5304404346 Drum-ice disp 218815400 Front-ice container 5304404337 Bar-drive 5304404359 Gate...

  • Page 18: Ice Maker

    Publication No. FRS20ZSH 5995347969 ICE MAKER 01/01...
  • Page 19 A = FRS20ZSH (FRS20ZSHB4) B = FRS20ZSH (FRS20ZSHB5) 11 # 12 # 13 # 15 # 17 # 141* # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZSH ICE MAKER 218832302 Tube-water inlet, inlet valve, to filter 218976910 Tube-water inlet, inlet valve, to filter...

  • Page 20: Wiring Schematic

    Publication No. FRS20ZSH 5995347969 WIRING SCHEMATIC 01/01...

  • Page 21: Wiring Diagram

    FRS20ZSH Publication No. 5995347969 WIRING DIAGRAM # = Fast-moving Parts 01/01 * = Non-Illustrated Parts...
