PRODUCT NO.
BASE MODEL NO.
FRS20ZRGB7
FRS20ZRG
FRS20ZRGD7
FRS20ZRG
FRS20ZRGW7
FRS20ZRG
MARKET
North America
WIRING DIAGRAM - # 218903201
OWNER'S GUIDE - # 218955100
SERVICE DATA SHEET - # 218909400
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a
black
R134a
almond
R134a
white
Publication No.
5995338638
000601
-EN/SERVICE/KHB
357

SIDE BY SIDE

REFRIGERATOR
VOLTS
115
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS20ZRG
©2000 White Consolidated Industries, Inc.
All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS20ZRG and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRS20ZRG

Summary of Contents for Frigidaire FRS20ZRG

  • Page 1: Side By Side

    FACTORY PARTS CATALOG SIDE BY SIDE REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRS20ZRGB7 FRS20ZRG R134a black FRS20ZRGD7 FRS20ZRG R134a almond FRS20ZRGW7 FRS20ZRG R134a white MARKET North America WIRING DIAGRAM - # 218903201 OWNER’S GUIDE - # 218955100 SERVICE DATA SHEET - # 218909400 SIDE BY SIDE REFRIGERATOR...

  • Page 2: Freezer Door

    Publication No. FRS20ZRG 5995338638 FREEZER DOOR 05/00...
  • Page 3 FRS20ZRG Publication No. 5995338638 FREEZER DOOR A = FRS20ZRG (FRS20ZRGB7) B = FRS20ZRG (FRS20ZRGD7) C = FRS20ZRG (FRS20ZRGW7) POS. NO PART NO DESCRIPTION 215734321 A - - Gasket-frzr door,black ,magnetic 215734311 - B C Gasket-frzr door,white ,magnetic 5303288950 A B C Support-door rack,RH/LH 5303323484 A B C...

  • Page 4: Refrigerator Door

    Publication No. FRS20ZRG 5995338638 REFRIGERATOR DOOR 05/00...
  • Page 5 FRS20ZRG Publication No. 5995338638 REFRIGERATOR DOOR A = FRS20ZRG (FRS20ZRGB7) B = FRS20ZRG (FRS20ZRGD7) C = FRS20ZRG (FRS20ZRGW7) POS. NO PART NO DESCRIPTION 215734322 A - - Gasket-refr door,black ,magnetic 215734312 - B C Gasket-refr door,white ,magnetic 218749301 A B C Panel-inner door,refr 218807013 A B C...
  • Page 6 Publication No. FRS20ZRG 5995338638 CABINET 05/00...
  • Page 7 FRS20ZRG Publication No. 5995338638 CABINET A = FRS20ZRG (FRS20ZRGB7) B = FRS20ZRG (FRS20ZRGD7) C = FRS20ZRG (FRS20ZRGW7) POS. NO PART NO DESCRIPTION 218748901 A B C Cover-air duct 5303209814 A B C Nut,"U" type ,8-15A ,fan mtr mtg 218751301 A B C Cover-evap coil,lower 10A* 5308009617...
  • Page 8 Publication No. FRS20ZRG 5995338638 SHELVES 05/00...
  • Page 9 FRS20ZRG Publication No. 5995338638 SHELVES A = FRS20ZRG (FRS20ZRGB7) B = FRS20ZRG (FRS20ZRGD7) C = FRS20ZRG (FRS20ZRGW7) POS. NO PART NO DESCRIPTION 5303300707 A B C Trim-basket 218298005 A B C Shelf-freezer,sliding ,wire 5304405989 A B C Shelf-freezer 218746202 A B C Shelf-"Spill-Safe",fixed ,(3) 218015301 A B C...
  • Page 10 Publication No. FRS20ZRG 5995338638 CONTROLS 05/00...
  • Page 11 FRS20ZRG Publication No. 5995338638 CONTROLS A = FRS20ZRG (FRS20ZRGB7) B = FRS20ZRG (FRS20ZRGD7) C = FRS20ZRG (FRS20ZRGW7) POS. NO PART NO DESCRIPTION 215028605 A B C Knob-damper control 5308000010 A B C Fan Blade,red 5308000124 A B C Ring-fan orifice 5300157666 A B C Bushing-motor mtg,(2)
  • Page 12 Publication No. FRS20ZRG 5995338638 SYSTEM 05/00...
  • Page 13 FRS20ZRG Publication No. 5995338638 SYSTEM A = FRS20ZRG (FRS20ZRGB7) B = FRS20ZRG (FRS20ZRGD7) C = FRS20ZRG (FRS20ZRGW7) POS. NO PART NO DESCRIPTION 218787700 A B C Condenser 5303208866 A B C Spacer-cond tube,black 5303289026 A B C Spacer-tube 5304406721 A B C Spacer-cond tube,round ,5/8 OD x .81"lg 5303289029 A B C...
  • Page 14 Publication No. FRS20ZRG 5995338638 DISPENSER 05/00...
  • Page 15 FRS20ZRG Publication No. 5995338638 DISPENSER A = FRS20ZRG (FRS20ZRGB7) B = FRS20ZRG (FRS20ZRGD7) C = FRS20ZRG (FRS20ZRGW7) POS. NO PART NO DESCRIPTION 5308010366 A B C Tube-water inlet, 0.25 OD x 93", plastic 218832302 A B C Tube-water inlet, inlet valve, to filter 218859901 A B C Tube-water inlet, inlet valve, to filter...

  • Page 16: Ice Container

    Publication No. FRS20ZRG 5995338638 ICE CONTAINER 05/00...
  • Page 17 FRS20ZRG Publication No. 5995338638 ICE CONTAINER A = FRS20ZRG (FRS20ZRGB7) B = FRS20ZRG (FRS20ZRGD7) C = FRS20ZRG (FRS20ZRGW7) POS. NO PART NO DESCRIPTION 5304404344 A B C Auger-ice 5304404343 A B C Cam-drive 218815300 A B C Container-ice 5304404346 A B C Drum-ice disp 218815400 A B C...

  • Page 18: Ice Maker

    Publication No. FRS20ZRG 5995338638 ICE MAKER 05/00...
  • Page 19 FRS20ZRG Publication No. 5995338638 ICE MAKER A = FRS20ZRG (FRS20ZRGB7) B = FRS20ZRG (FRS20ZRGD7) C = FRS20ZRG (FRS20ZRGW7) POS. NO PART NO DESCRIPTION 5308010366 A B C Tube-water inlet, 0.25 OD x 93", plastic 218832302 A B C Tube-water inlet, inlet valve, to filter 218859901 A B C Tube-water inlet, inlet valve, to filter...

  • Page 20: Wiring Schematic

    Publication No. FRS20ZRG 5995338638 WIRING SCHEMATIC 05/00...

  • Page 21: Wiring Diagram

    FRS20ZRG Publication No. 5995338638 WIRING DIAGRAM # = Fast-moving Parts 05/00 * = Non-Illustrated Parts...
