- Page 1 Instruction booklet Gas hob ZGS 322 ZGS 322 ZGS 322 ZGS 322 ZGS 322...
- Page 2 Thank you for selecting our appliance Thank you for selecting our appliance Thank you for selecting our appliance Thank you for selecting our appliance Thank you for selecting our appliance We wish you lots of enjoyment with your new appliance and we hope that you will consider our brand again when purchasing household appliances.
-
Page 3: Table Of Contents
Contents Important Safety Information Important Safety Information ............Important Safety Information ................................... 4 4 4 4 4 Important Safety Information Important Safety Information ............Description of the Hob ................6 Instructions for the User Instructions for the User .............. -
Page 4: Important Safety Information
Important Safety Information Y Y Y Y Y ou MUST r ou MUST r ou MUST read these war ou MUST r ead these war ead these war nings car ead these war nings car nings carefully befor nings car efully befor efully befor efully before installing or... - Page 5 When using the hob for a long period time, the ventilation should be improved, by opening a window or increasing the extractor speed. Do not use this hob if it is in contact with water. Do not operate the hob with wet hands.
-
Page 6: Description Of The Hob
Description of the Hob Rapid Burner Auxiliary Burner Burners Control knobs... -
Page 7: Instructions For The User
Instructions for the User INSTALLATION Any gas installation must be carried out by a registered Any gas installation must be carried out by a registered Any gas installation must be carried out by a registered Any gas installation must be carried out by a registered Any gas installation must be carried out by a registered competent person, and in accordance with existing rules competent person, and in accordance with existing rules... -
Page 8: Operation
Operation Lighting the burners Lighting the burners Lighting the burners Lighting the burners Lighting the burners For easier lighting, For easier lighting, For easier lighting, proceed before proceed before proceed before For easier lighting, For easier lighting, proceed before proceed before putting a pan on the pan support. - Page 9 Using the hob correctly Using the hob correctly Using the hob correctly Using the hob correctly Using the hob correctly To ensure maximum burner efficiency, it is strongly recommended that you use only pots and pans with a flat flat flat bottom fitting the size of the burner used, flat flat...
-
Page 10: Maintenance And Cleaning
Maintenance and Cleaning Before any maintenance or cleaning can be carried out, you Before any maintenance or cleaning can be carried out, you Before any maintenance or cleaning can be carried out, you Before any maintenance or cleaning can be carried out, you Before any maintenance or cleaning can be carried out, you must DISCONNECT the hob fr must DISCONNECT the hob fr... - Page 11 The Ignition electrode The Ignition electrode The Ignition electrode The Ignition electrode The Ignition electrode The electric ignition is obtained through a ceramic electrode which contains a metal electrode. Keep these components very clean, to avoid difficult lighting, and check that the burner crown holes are not obstructed.
-
Page 12: Something Not Working
Something Not Working? If the hob is not working correctly, please carry out the following checks before contacting your local Service Force Centre. SYMPTOM SYMPTOM SYMPTOM SYMPTOM SYMPTOM SOLUTION SOLUTION SOLUTION SOLUTION SOLUTION There is no spark when Check that the unit is plugged lighting the gas. -
Page 13: Instructions For The Installer Instructions For The Installer
Instructions for the Installer Engineer technical data Engineer technical data Engineer technical data Engineer technical data Engineer technical data OVERALL DIMENSIONS OVERALL DIMENSIONS OVERALL DIMENSIONS OVERALL DIMENSIONS OVERALL DIMENSIONS Width: 290 mm Depth: 510 mm CUT OUT DIMENSIONS CUT OUT DIMENSIONS CUT OUT DIMENSIONS CUT OUT DIMENSIONS CUT OUT DIMENSIONS... - Page 14 BURNER RAPID A U X I L I A R Y TYPE OF GAS POSITION M A X MIN M A X MIN NOMINAL THERMAL POWER 0.75 0.33 NATURAL GAS 20 mbar NOMINAL FLOW VALUE = RATE 0.286 0.071 0.095 0.031 37.78 MJ/m NOZZLE REFERENCE...
-
Page 15: Important Safety Requirements
Important safety requirements This hob must be installed in accordance with the Gas Safety (Installation and Use) Regulations (Current Edition) and the IEE Wiring Regulations (Current Edition). For appliances installed in the Republic of Ireland please refer to NSAI- Domestic Gas Installation I.S. -
Page 16: Installation
The minimum distance combustible material or a cooker hood can be fitted above the hob is 650 mm. For appliances installed in the Republic of Ireland please refer to NSAI- Domestic Gas Installation I.S 813 Current Edition Section 7- Permitted Locations of Appliance. Installation IMPOR IMPOR T T T T T ANT... -
Page 17: Gas Connection
On the end of the shaft, which includes the G 1/2" threaded elbow, adjustment is fixed so that the washer is fitted between the components as shown in the diagram. Screw the parts together without using excessive force. A) End of shaft with nut B) Washer C) Elbow Gas Connection... -
Page 18: Building In
Building In B B B B B uilding over a cupboard or drawer uilding over a cupboard or drawer uilding over a cupboard or drawer uilding over a cupboard or drawer uilding over a cupboard or drawer If the hob is to be installed above a cupboard or drawer it will be necessary to fit a heat resistant board below the base of the hob on the underside of the work surface. -
Page 19: Fitting The Hob Into The Worktop
Fitting the Hob into the Worktop Carry out the building in of the hob as follows: 1. place the seals supplied with the hob on the side edges of the cut out, taking care that the seals meet without overlapping; 2. -
Page 20: Electrical Connections
Electrical Connections Any electrical work required to install this hob should be Any electrical work required to install this hob should be Any electrical work required to install this hob should be Any electrical work required to install this hob should be Any electrical work required to install this hob should be carried out by a qualified electrician or competent person, carried out by a qualified electrician or competent person,... -
Page 21: Wiring Diagram
— Connect the blue (neutral) wire to the terminal in the plug which is marked with the letter 'N' or coloured black. — Connect the brown (live) wire to the terminal in the plug which is marked with the letter 'L' or coloured red. Upon completion there must be no cut, or stray strands of wire present and the cable clamp must be secure over the outer sheath. -
Page 22: Fault Finding
Fault Finding Preliminary Electrical Systems Check Preliminary Electrical Systems Check Preliminary Electrical Systems Check Preliminary Electrical Systems Check Preliminary Electrical Systems Check Blue Brown S T A R T S T A R T S T A R T S T A R T S T A R T Isolate appliance and carry out:... - Page 23 A. EARTH CONTINUITY CHECK A. EARTH CONTINUITY CHECK A. EARTH CONTINUITY CHECK A. EARTH CONTINUITY CHECK A. EARTH CONTINUITY CHECK Appliance must be electrically disconnected - meter set on W (Ohms) x 1 scale and adjust zero if necessary. — Test leads from any appliance earth point to earth pin on plug. Resistance should be less than 0.1 W (Ohm), check all earth wires for continuity and all contacts clean and tight.
- Page 24 Ignition System / Gas Ignition Ignition System / Gas Ignition Ignition System / Gas Ignition Ignition System / Gas Ignition Ignition System / Gas Ignition Check gas supply at Ignitor does not spark burner Check plug top fuse and Light burner manually replace if necessary Check polarity and Check by pass simmer...
-
Page 25: Commissioning
Commissioning When the hob has been fully installed it will be necessary to check the minimum flame setting. To do this, follow the procedure below. 1) Turn the gas tap to the MAX position and ignite. 2) Set the gas tap to the MIN flame position then turn the control knob from MIN to MAX several times. -
Page 26: Conversion From Natural Gas To Lpg
Conversion from Natural Gas to LPG IMPOR IMPOR IMPOR IMPOR IMPORT T T T T ANT The replacement/conversion from natural gas to LPG should only The replacement/conversion from natural gas to LPG should only The replacement/conversion from natural gas to LPG should only The replacement/conversion from natural gas to LPG should only The replacement/conversion from natural gas to LPG should only be undertaken by a competent person. -
Page 27: Guarantee/Customer Service
Standard guarantee conditions Standard guarantee conditions We, Zanussi-Electrolux, undertake that if within 12 months of the date of the purchase this Zanussi-Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: ·... - Page 28 Service and Spare Parts Service and Spare Parts Service and Spare Parts Service and Spare Parts Service and Spare Parts In the event of your appliance requiring service, or if you wish to purchase spare parts, please contact your local Service Force Centre by telephoning 0870 5 929 929 0870 5 929 929 0870 5 929 929...
-
Page 29: European Guarantee
European Guarantee This appliance is guaranteed by Electrolux in each of the countries listed at the back of this user manual, for the period specified in the appliance guarantee or otherwise by law. If you move from one of these countries to another of the countries listed below the appliance guarantee will move with you subject to the following qualifications: •... - Page 32 35690-8303 01/08...
