- Page 1 User Manual GETTING STARTED? EASY. ZGH76534XS EN User Manual...
-
Page 2: Safety Information
VISIT OUR WEBSITE TO: Get usage advice, brochures, trouble shooter, service and repair information: www.zanussi.com/support SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. - Page 3 This appliance may be used in, offices, hotel guest rooms, bed • & breakfast guest rooms, farm guest houses and other similar accommodation where such use does not exceed (average) domestic usage levels. WARNING: The appliance and its accessible parts become hot •...
-
Page 4: Safety Instructions
manufacturer of the appliance in the instructions for use as suitable or hob guards incorporated in the appliance. The use of inappropriate guards can cause accidents. SAFETY INSTRUCTIONS ELECTRICAL CONNECTION This appliance is suitable for the following markets: WARNING! Risk of fire and electric shock. -
Page 5: Gas Connection
from the mains at all poles. The isolation device • Set the cooking zone to “off” after each use. must have a contact opening width of minimum • Do not put cutlery or saucepan lids on the 3 mm. cooking zones. They can become hot. •... -
Page 6: Installation
CARE AND CLEANING SERVICE • To repair the appliance contact the Authorised WARNING! Do not remove the Service Centre. Use original spare parts only. buttons, knobs or gaskets from the control panel. Water may get inside DISPOSAL the appliance and cause damage. WARNING! Risk of injury or •... -
Page 7: Adjustment Of Minimum Level
3. With a socket spanner 7 remove the injectors instructions incorporated in this instruction booklet and replace them with the ones which are be ignored. necessary for the type of gas you use (see On the end of the shaft, which includes the G 1/2" table in "Technical Information"... - Page 8 6. Reassemble the gasketthe magnet holder and the knob. 1. Connect the green and yellow (earth) wire to the terminal which is marked with the letter 'E', or the earth symbol , or coloured green and yellow. 2. Connect the blue (neutral) wire to the terminal which is marked with the letter 'N' or coloured blue.
-
Page 9: Possibilities For Insertion
min. min. 650 mm 150 mm min. 55 mm 30 mm 480 mm 560 mm 400 mm 50 mm A. Supplied seal B. Supplied brackets If a furniture unit is installed at a distance of 400 mm above the hob, there must be a minimum safety distance of 50 mm to the left or right from the edge of the hob. -
Page 10: Product Description
Kitchen unit with door or drawer Kitchen unit with oven The electrical connection of the hob and the oven must be installed separately for safety reasons and to allow for easy removal of the oven from the unit. Kitchen unit with double oven min 6 mm min 30 mm min 5 mm... -
Page 11: Daily Use
DAILY USE WARNING! Refer to Safety chapters. WARNING! Be very careful when you use open fire in the kitchen environment. The manufacturer declines any responsibility in case of BURNER OVERVIEW the flame misuse. 1. Push the control knob down and turn it counterclockwise to the maximum gas supply position ( ). -
Page 12: Hints And Tips
TURNING THE BURNER OFF WARNING! Always turn the flame To put the flame out, turn the knob to the off down or switch it off before you position remove the pans from the burner. HINTS AND TIPS WARNING! Refer to Safety chapters. CAUTION! Make sure that the pots are placed centrally on the burner in order to get the maximum stability and... -
Page 13: Troubleshooting
CLEANING THE HOB Be very careful when you replace the pan supports to prevent the • Remove immediately: melted plastic, plastic hob top from damage. foil, sugar and food with sugar, otherwise, the dirt can cause damage to the hob. Take care to 2. -
Page 14: Labels Supplied With The Accessories Bag
Problem Possible cause Remedy The fuse is blown. Make sure that the fuse is the cause of the malfunction. If the fuse is blown again and again, contact a qualified electrician. Burner cap and crown are Place the burner cap and placed incorrectly. -
Page 15: Technical Data
TECHNICAL DATA HOB DIMENSIONS Width 745 mm Depth 510 mm BYPASS DIAMETERS BURNER Ø BYPASS 1/100 mm Multi Crown Rapid Semi-rapid Auxiliary OTHER TECHNICAL DATA Gas original: G20 (2H) 20 mbar 12,0 kW TOTAL POW- Gas replace- G30 (3+) 28-30 mbar 825 g/h ment: G31 (3+) 37 mbar... -
Page 16: Energy Efficiency
0,75 Semi-rapid 0,45 Auxiliary 0,33 ENERGY EFFICIENCY PRODUCT INFORMATION ACCORDING TO EU 66/2014 Model identification ZGH76534XS Type of hob Built-in hob Number of gas burners Centre rear - Semi-rapid 55.0% Right rear - Rapid 57.1% Energy efficiency per gas burner Left middle - Multi Crown 55.5%... - Page 20 WWW.ZANUSSI.COM/SHOP...
