H.O.P.E.
Training Support Manual
LBP-3260

Advertisement

Table of Contents

   Also See for Canon LBP-3260

   Related Manuals for Canon LBP-3260

   Summary of Contents for Canon LBP-3260

  • Page 1 H.O.P.E. Training Support Manual LBP-3260...
  • Page 3 LBP-3260 Training Support Manual LBP-3260 Training Support Manual This LBP-3260 Training Support Manual describes the differences between the LBP- 3260 and the previous model LBP-2460. Due to the relatively minor number of differences between the LBP-3260 and the LBP-2460, only these differences will be handled in this manual and not the entire machine.
  • Page 4 The power of the heater was increased A cleaning roller was added. Toner: The capacity of the toner cartridge was increased to 20000 pages Cover: The cover material was changed to PC-ABS Accessories: New Accessories were designed copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 5 Flash ROM Module FR-5 Adobe PostScript3 Module A-72 Adobe PostScript Module A-4 Hard Disk Unit HD-72 Hard Disk Unit HD-4 Network Boards EB-52, 1300ETX, Network Boards LT-3, CIS 1000EX, 1000TX Boards, Emulex Boards copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 6 45 Scalable fonts, 45 Scalable fonts 8 Bitmap fonts 6 Bitmap fonts Scaler UFST UFST The LBP-3260 controller uses a new memory compression method. Therefore less memory is used and the max. memory was reduced. copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 7 LBP-3260 Training Support Manual copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 8 LBP-3260 Training Support Manual copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 9 LBP-3260 Training Support Manual Paper and Fixing Rollers Paper Cassette and Paper Guide Image Formation System copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 10 Feed roller / Separation roller 350,000 prints Power supply fan 25,000 hours Electrical unit fan 25,000 hours Fixing unit fan 25,000 hours Fixing / scanner fan 25,000 hours MP tray fan 25,000 hours copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 11 LBP-3260: 600W * 1 & 450W * 1 Employment of a constant voltage circuit in the fixing drive circuit to meet the safety standard Employment of the LVDS (Low Voltage Differential Signal) for the VIDEO signal to prevent noise copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 12 Therefore the LLCONT and PD signals are dropped and the DRVES signal was added. The DC controller CPU monitors the LASER FAILURE DETECTION signal (DRVES) to check whether the laser diode is generating laser normally or not. copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 13 Therefore, the APC of this printer has higher reliability of control over the conventional APC. copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 14 The CPU notifies the video controller of a scanner failure in the following cases: 1. When the /SCNRDY signal does not become “L” within 30 seconds after the scanner motor starts rotation. 2. When the /SCNRDY signal goes “H” for 1.5 continuous seconds after going “L”. copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 15 Safety circuit Detects “upper heater abnormal high temperature” by monitoring the FIXING ROLLER TEMPERATURE SENSE signal (FSRTH) Thermo switch Detects surface temperature of the upper fixing rollers (OFF when 200 C or more) copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 16 To avoid toner spots on the backside of the paper a new fixing unit cleaning mechanism was designed. The (aluminum) cleaning roller cleans the lower fixing roller by attracting the residual toner on the lower fixing roller copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 17 The connector of the fixing unit was new designed. The LBP-3260 fixing unit has only one connector instead of two like the LBP-2460 fixing unit. Therefore it is impossible to exchange the LBP-3260- and the LBP-2460 fixing units NEW LBP-3260 Fixing unit LBP-2460 Fixing unit copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 18 Cover material PC-ABS Delivery cover Cover material PC-ABS Front cover Cover material PC-ABS Right Cover Cover material PC-ABS Rear Right Cover Cover material PC-ABS Electrical Cover Cover material PC-ABS Open/Close Cover Cover material PC-ABS copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 19 LBP-3260 Training Support Manual Label Label color Blue Green Cover Lever Lever color Blue Green End Plate Plate color Blue Green Body Cassette Guide/Stopper mechanism copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 20 Thick Thin Feed Roller Roller thickness Thick Thin Paper Sensing Roller Flag color Gray Black Feed Clutch Clutch color Silver Black Pick-Up Motor Label color Blue White Pick-Up Solenoid Cable color Purple Gray copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 21 LBP-3260 Training Support Manual Face-Up Flapper Deflector shape Cushion Cushion Delivery Guide Guide color Gray Black Roller Roller material Black Silver copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 22 LBP-3260 Training Support Manual Thermistor Connector form Thermoswitch Connector form Lower Roller Roller diameter Large Small Upper Roller Roller diameter Large Small Heater Connector form copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 23 MP Pick-Up Roller Rubber thickness Thick Thin Separation Pad Pad color Gray Orange/Gray MP Pick-Up Fan Changes in the multi- MP Solenoid purpose tray pick-up unit MP Clutch due to the added fan copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 24 LBP-3260 Training Support Manual Guide Plate Plate color Black Silver Jam Holder Holder Clutch Clutch color Black Silver copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 25 LBP-3260 Training Support Manual Stopper Hinge Hinge color Silver Black Transfer Roller Sub roller Transfer Holder S mark Paper Feed Assy Bushing color Gray Black Printer Drive Assy Fixing drive gear color Black White copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 26 Main Motor Connector pin 6 pin 7 pin Power Supply Connector pin 14 pin (J217) 13 pin (J217) Connector pin 10 pin (J204) 6 pin (J204) DC Controller Connector pin J202, 204, 217 copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 27 (4): FIXING UNIT DELIVERY SENSE signal (/FPOUTS) (5): MAIN MOTOR DRIVE signal (/MMOTD) PS 1401: Face-down tray full sensor PS 1402: Face-down tray delivery sensor PS 1403 Fixing unit delivery sensor SL 3: Face-up solenoid MT 1: Main motor copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 28 (8): LIFTING PLATE SOLENOID DRIVE signal (/MPTSLD) MT 1: Main motor SMT1: Cassette pick-up motor SL1: Cassette pick-up solenoid SL2: Lifting plate solenoid SL3: Face-up solenoid CL1: Registration clutch CL2: Feed clutch CL3: Manual feed clutch copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 29 (11): UPPER CASSETTE PAPER LEVEL SENSE signal 2 (UPVS2) (12): UPPER CASSETTE SENSE signal (/UDECK) (13): UPPER CASSETTE PAPER OUT SENSE signal (/UDECKS) (14): REGISTRATION PAPER SENSE signal (/REGS) (15): MULTI-PURPOSE TRAY PAPER SENSE signal (/MPTPS) copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 30 Face-down tray delivery sensor PS1403: Fixing unit delivery sensor SW1601: Cassette paper size sensing switch SW1602: Cassette paper size sensing switch SW1603: Cassette paper size sensing switch SW1604: Cassette paper size sensing switch copyrights Canon Europa n.v. TSS Division 01-1999...
  • Page 31 LBP-3260 Training Support Manual copyrights Canon Europa n.v. TSS Division 01-1999...
