Bulova Chrono FS00 Settings Manual

BOOK NO. 561/598
FEATURES
1. Hours, minutes, seconds and date display.
2. 60 minute Chronograph (CHRONO) with minutes and
seconds display.
3. 24 hour hand, permanently synchronized with the normal
12 hour hand.
A. SETTING THE TIME
1. Pull the crown out to position "3" (See diagram). If the crown has
a "screw-down" lock, then unscrew the crown lock first by turning
the crown toward you, then pull it to position "3". Do not forget to
screw the crown back "IN" after all setting is completed.
2. Turn the crown towards you (hands moves clockwise) until the
date changes at approximately midnight.
3. Continue turning the hour and minute hands to the correct time.
If it is afternoon you must go past 12 o'clock again (noon) to set
the correct time.
4. When the correct time is set,push crown back to position "1".
B. SETTING THE DATE
1. Pull crown to position "2"(See proceeding diagram).The watch
will continue to run.
2. Turn the crown away from you until the
3. Once the date is set, push the crown back to position "1".
Note: Do NOT set the date between the hours of 8:00 PM and
3:00 AM.This would not damage the watch,but the date may need
to be reset later.
C. CHRONOGRAPH (CHRONO) ADJUSTMENT
If the chrongraph second hand is not positioned at the proper
starting position (12 o'clock or "zero" position), use the below
procedure.It does not need to be repeated unless the watch
receives an impact sufficient to move the hand out of position, or
the Battery has been changed.
Chrono FS00/01/10
1. Pull crown out to position "3".
2. Push button "A" to move the Chrono Second hand (long hand) to
3. Push crown back to position "1".
D. USING THE CHRONOGRAPH (CHRONO)
Note: The maximum chrono reading is 60 minutes, However the
chrono will continue running once 60 minutes has passed. The
resulting one hour periods may be added together mentally to keep
track of longer periods.
For example – If you know that approximately one hour has
passed since you started the chronograph, and the chrono reads
25 minutes, then you know that the chrono has been running 60
minutes plus 25 minutes, which is one hour and 25 minutes.
1. Push Button "A" to start the chronograph. Push button "A" again
2. Push button "B" to return the two chronograph hands to the
3. The Chronograph can be stopped and started again
correct date appears.
the "0" or 12 o'clock position. Each button push will move the
hand one step – BUT holding the button down will advance the
hand rapidly.
to stop the chronograph.
"Zero" or starting point.
(Button "A"), repeatedly, to "ADD" times together.
Watch Setting Guide
4/2007
