- Page 1 MC300 Motorcycle/UTV Amplified Speaker System User’s Manual...
- Page 2 Congratulations on your purchase of a BOSS Audio Systems Off-road amplified speaker system. It has been designed, engineered and manufactured to bring you the highest level of performance and quality, and will afford you years of listening pleasure. Thank you for making BOSS AUDIO SYSTEMS your choice for entertainment!
- Page 3 MC300 Motorcycle/UTV Amplified Speaker System Contents 2 x Weatherproof, High Power Speakers with Built-in Amp 4 x Speaker Grilles 1 x Mounting Hardware Features • Weatherproof, High Power Speakers with Built-in Amp • High-Impact, Hi-Temp ABS Exterior • Extra Replacement Grilles (Optional Color Scheme 2) •...
-
Page 4: Installation
Installation Changing the grilles (Optional) - Remove the screws in a criss-cross pattern. Be sure to install them the same way, do not overtighten. Screw the brackets to the bottom of the speakers. 2.5mm Hex Screws Find a safe, ideal mounting location and fit the brackets over the chosen mounting bars. - Page 5 MC300 Motorcycle/UTV Amplified Speaker System BLACK/BLUE BLUE Bracket To Chassis Ground Power Cable Note: Connect the 12V red wire to a fused (5A) switched power source. Wired Remote Volume Control...
-
Page 6: Specifications
MC300 Motorcycle/UTV Amplified Speaker System Specifications Operation Voltage......... 10-16V THD............<0.1% S/N............>50dB Channel Separation......>50dB Frequency Response......20Hz-20kHz Sensitivity..........150mv Max Power 400 Watts... - Page 8 MC300 Motorcycle/UTV Amplified Speaker System BOSS Audio Systems 3451 Lunar Court • Oxnard, CA 93030 www.bossaudio.com 800.999.1236...
