Supplementary
Information for
REFERENCE MANUAL
About the Functions Added
in Dock&Done 2.0 Update
Digital Camera
IR-500

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IR 500 - 4MP Digital Solutions Camera and is the answer not in the manual?

Questions and answers

Related Manuals for Olympus IR 500 - 4MP Digital Solutions Camera

Summary of Contents for Olympus IR 500 - 4MP Digital Solutions Camera

  • Page 1 Supplementary Information for REFERENCE MANUAL About the Functions Added in Dock&Done 2.0 Update Digital Camera IR-500...

  • Page 2: About This Manual

    Reference Manual supplied with the camera. Trademarks and OLYMPUS Master are trademarks of OLYMPUS CORPORATION. Main functions added or changed in Dock&Done 2.0 Playing back image files stored in...
  • Page 3 Main functions added or changed in Dock&Done 2.0 Print reservation Canceling all of the current print reservations and making new reservations gP.5 Dock&Done Support for the optional Dock&Done-compatible DVD Storage gP.6 function Playing back images stored on a storage unit gP.10 Saving images on the camera to a CD or DVD gP.14 Printing images played back gP.16 Resetting print reservations automatically after printing is...

  • Page 4: Table Of Contents

    Table of contents Table of contents About this manual ............. . 2 Main functions added or changed in Dock&Done 2.0 .

  • Page 5: Making Print Reservations

    Canceling all of the current print reservations and making new reservations Making print reservations Canceling all of the current print reservations and making new reservations Turn the mode dial to q, then press p. The playback menu appears. Mode dial QU IC K VI EW p button...

  • Page 6: Using The Q Functions

    Using the Dock&Done-compatible storage unit Using the Q functions Using the Dock&Done-compatible storage unit You can use the optional Dock&Done-compatible DVD Storage as well as the optional Dock&Done-compatible HD Storage. The DVD storage unit allows you to save camera images to a CD or DVD.
  • Page 7 Using the Dock&Done-compatible storage unit Connect the AC adapter to the storage unit and the power cord to a wall outlet. Set the Dock&Done mode/PC mode switch on the storage unit to “QDOCK,” and turn on the storage unit. Wait until the ACCESS indicator on the storage unit goes off. ACCESS indicator DOCK...
  • Page 8 Using the Dock&Done-compatible storage unit Set the camera on the cradle with the multi-swing display opened. • The camera turns on, and the “QDOCK MODE” screen appears. • The camera is powered by the AC adapter of the storage unit. •...
  • Page 9 Using the Dock&Done-compatible storage unit “QDOCK MODE” screen menu The available menu varies depending on the camera settings and whether print reservations have been made or not. STORE:PRINT: Stores new images on the storage unit, and then prints images with print reservations.

  • Page 10: Playing Back Images On The Storage Unit (Storage Playback)

    Using the Dock&Done-compatible storage unit Playing back images on the storage unit (Storage Playback) You can use the camera’s monitor to view images stored on the Dock&Done-compatible storage unit (hard disk/DVD). Before operating the menus, make sure the camera, cradle and storage unit are set up. If the “QDOCK MODE”...
  • Page 11 Using the Dock&Done-compatible storage unit Press a, b, c, d to select the image you want to play back, then press 9. The image is displayed in the single-frame display. To return to the index display, turn the zoom lever to W. Displayed during storage playback.
  • Page 12 Using the Dock&Done-compatible storage unit To play back movies on the storage unit Select the movie you want to play back in the index display, then press 9. Operations during movie playback a: Volume up c: Volume down Hold down this button for double speed playback. Press this button for reverse playback.
  • Page 13 • To use a Dock&Done-compatible HD Storage for storage playback, it is required that it supports the storage playback function. If your model does not support the function, you need to update the firmware of the storage unit. For details, see the Olympus web site.

  • Page 14: Creating A Disk For Storing Images (Create Share Disk)

    Using the Dock&Done-compatible storage unit Creating a disk for storing images (CREATE SHARE DISK) You can use the Dock&Done-compatible DVD Storage to easily burn a CD or DVD of all images stored on the camera. The disks created using this function are readable on the CD/DVD drive of PCs, so you can use them for distribution purposes.
  • Page 15 Using the Dock&Done-compatible storage unit Set an unused disk in the DVD storage unit. Wait until the ACCESS indicator on the DVD storage unit goes off. Set the camera on the cradle with the multi- DOCK MODE swing display opened. •...

  • Page 16: Printing Images Being Played Back

    Printing images being played back Printing images being played back You can use your camera and a Dock&Done-compatible storage unit (hard disk/DVD) with a Dock&Done-compatible printer to play and print images stored on your camera or storage unit. For details about the operation of the Dock&Done-compatible storage unit or printer, refer to the instruction manual of the storage unit or printer.
  • Page 17 Printing images being played back Set the Dock&Done mode/PC mode switch on the storage unit to “QDOCK,” and turn on the storage unit. Wait until the ACCESS indicator on the storage unit goes off. ACCESS indicator DOCK Set the camera on the cradle with the multi-swing display opened. •...
  • Page 18 Printing images being played back Press p to display the storage playback menu. Press a, c to select “PRINT,” then press d to enter the settings. CLOSE STORAGE PRINT START Press 9. 10 10 PRINT SELECT SINGLE PRINT MORE Follow the screen instructions to select the images to be printed, number of prints, and paper size, etc.

  • Page 19: Configuring Camera Settings

    Configuring camera settings Configuring camera settings Resetting the print reservation automatically after printing is complete You can set whether to keep or cancel print reservations after printing images by selecting “PRINT,” etc., on the “QDOCK MODE” screen. This prevents you from repeatedly printing the same image by mistake.

  • Page 20: Using The Remote Control For Playback

    Setting up the camera Using the remote control for playback You can use the optional remote control (RM-100) to play back and print images. For details about the remote control, refer to the instruction manual of the remote control. Setting up the camera Follow the procedure below to set up your camera to use the remote control.

  • Page 21: Operating The Camera

    Operating the camera Operating the camera You can use the remote control to play back images on the camera monitor or TV screen. The same operations (such as selecting or deleting images, etc.) can be performed in the same manner as the camera buttons.

  • Page 22: Using The Direct Buttons On The Remote Control

    Operating the camera Press the 9 button on the remote control. • The screen of the selected mode appears. Operate the camera using the remote control buttons in the same manner as the camera buttons. • To select any of the available modes, press the MODE button on the remote control. Tips •...

  • Page 23: Others

    Error message list Others Error message list Error message Corrective action The image cannot be played back on the camera because its format is not compatible with the camera or the image data is damaged. This message is also displayed when sound data recorded to a still image using the postrecording PICTURE ERROR function is selected in storage playback mode.

  • Page 24: If A Problem Arises

    If a problem arises If a problem arises Dock&Done-compatible storage unit (hard disk/DVD) Possible cause Corrective action Ref. page ( Storage playback function does not work. The HD Storage (S-HD-100) does not Update the HD Storage to the version support Dock&Done 2.0. which supports Dock&Done 2.0.

  • Page 25: Remote Control

    If a problem arises Remote control Possible cause Corrective action Ref. page ( The camera cannot be turned on with the remote control. The AC adapter is not connected. Connect the AC adapter to the cradle. The multi-swing display is closed. Set the camera on the cradle with the multi-swing display raised.

  • Page 26: List Of Added Or Changed Menu Items

    List of added or changed menu items List of added or changed menu items The following is the list of menu items added or changed in Dock&Done 2.0. The items in boldface type are default settings. For information about menu items other than those changed, see “Menu list” (P.236) in the Reference Manual supplied with the camera.
  • Page 27 List of added or changed menu items Playback menu (movie) Ref. page In the Reference Item Settings In this Manual supplied manual with the camera INFO NO INFO/STANDARD/DETAIL — NORMAL/SCROLL/FADER/ZOOM DOWN/ZOOM UP/ — CHECKERBOARD/BLINDS/ SWIVEL/RANDOM STOP — — INDEX PLAY —...

  • Page 28: Setup Menu

    VIDEO OUT NTSC/PAL — REMOTE OFF/ON — CONTROL STORE AND ERASE/KEEP — PRINT AND CANCEL/KEEP — MODE RESET YES/NO — Items added or changed You can switch the selected language using OLYMPUS Master. For details, see the OLYMPUS Master Help.
  • Page 29 List of added or changed menu items Storage playback menu Ref. page In the Reference Item Settings In this Manual supplied manual with the camera CLOSE — — STORAGE PRINT START — NORMAL/SCROLL/FADER/ZOOM DOWN/ZOOM UP/ — CHECKERBOARD/BLINDS/ SWIVEL/RANDOM STOP — —...
  • Page 30 Our phone customer support is available from 8 am to 10 pm (Monday to Friday) ET E-Mail: distec@olympus.com Olympus software updates can be obtained at: http://www.olympus.com/digital Premises: Wendenstrasse 14-18, 20097 Hamburg, Germany Tel: +49 40-23 77 3-0 / Fax: +49 40-23 07 61...
