Frigidaire FEB30S5GCD Parts Catalog

30” single electric wall oven
Hide thumbs


Advertisement

FEB30S5GC.tif CFEB30S7DCA.eps BFEB30S5DSH.eps DCFEB30S5GC2.eps
318046254.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FEB30S5GCD
38254333E70S4
Series
30" single
Color
stainless
Market
North America
Wiring Diagram
318046254
Owner's Guide
318205119
Installation Instructions 318201514
Service Data Sheet
318047413
Timer Guide
318200189
Publication No.
5995534715
09/03/06
(EN/SERVICE/ECL)
377
30" SINGLE ELECTRIC
WALL OVEN
Model No.
FEB30S5G
©
Copyright
2009 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

Table of Contents
loading

  Also See for Frigidaire FEB30S5GCD

  Related Manuals for Frigidaire FEB30S5GCD

  Summary of Contents for Frigidaire FEB30S5GCD

  • Page 1 Product No. FEB30S5GCD 38254333E70S4 Series 30" single Color stainless Market North America Wiring Diagram 318046254 Owner's Guide 318205119 Installation Instructions 318201514 Service Data Sheet 318047413 Timer Guide 318200189 30” SINGLE ELECTRIC FEB30S5GC.tif CFEB30S7DCA.eps BFEB30S5DSH.eps DCFEB30S5GC2.eps WALL OVEN 318046254.eps Electrolux Major Appliances Model No.
  • Page 2: Control Panel

    Publication No: 5995534715 FEB30S5GCD CONTROL PANEL 03/09...
  • Page 3 FEB30S5GCD Publication No: 5995534715 CONTROL PANEL POS. NO PART NO. DESCRIPTION 318257300 Shield, oven top 318260100 Cover, box 318271542 Control Panel Assembly, steel/glass, stainless/black, w/touch pad 20 # 316418527 Clock/Timer, electronic, ES350W1 5303211311 Screw, 8 x 0.500 5303311306 Screw, 8-18 x 0.375, (6) 03/09 # Functional Parts * Non-Illustrated Parts...
  • Page 4 Publication No: 5995534715 FEB30S5GCD BODY 03/09...
  • Page 5 FEB30S5GCD Publication No: 5995534715 BODY POS. NO PART NO. DESCRIPTION 318259220 Back, main 318258902 Shield, insulation, upper 318345207 Rack, oven 5303317977 Pan, broilerOPTIONAL ACCESS0RY 5303317976 Insert, broiler panOPTIONAL ACCESS0RY 316445501 Switch, oven light, door frame 318224000 Receptacle, oven light 318268099 Insulation, oven light 5303013071 Bulb/Lamp, light...
  • Page 6 Publication No: 5995534715 FEB30S5GCD DOOR DCFEB30S5GC2 03/09...
  • Page 7 FEB30S5GCD Publication No: 5995534715 DOOR POS. NO PART NO. DESCRIPTION 318260401 Trim, oven door, side, (2) 318262101 Cover, rear door, black, (2) 318260522 Baffle, door 318372000 Insulation, door, (2) 318372002 Insulation, door, (2) 316117500 Glass, oven door, heat barrier 318360108 Liner, oven door 5304452028 Screw, handle mtg, 10-14 x 1/2, (2)
  • Page 8: Wiring Diagram

    Publication No: 5995534715 FEB30S5GCD WIRING DIAGRAM 03/09...
