Dear music lover,
thank you for purchasing a PRO-JECT AUDIO USB Box.
In order to achieve maximum performance and reliability you should study these instructions for use carefully.
Warning of a hazard for the user, the unit or possible misuse.
Important notice.
Copyright, trademarks
PRO-JECT is a Registered Trademark of H. Lichtenegger.
This guide was produced by: Audio Trade GmbH
Copyright © 2008. All rights reserved.
®
Windows XP , Windows Vista
Mac and Mac OS are trademarks of Apple Inc., registered in the U.S. and other countries.
Service
Should you encounter a problem which you are not able to alleviate or identify despite the above information,
please contact your dealer for further advice. Only when the problem cannot be resolved there should the
unit be sent to the responsible distributor in your country.
Warranty
The manufacturer accepts no responsibility for damage caused by not adhering to these instructions
for use. Modification or change to any part of the product by unauthorized persons release the
manufacturer from any liability over and above the lawful rights of the customer.
Technical specifications Pro-Ject USB Box
Line-level output:
Output voltage:
A/D converter:
Sampling rate:
USB-input:
Operating systems:
Dimensions W x H x D (D with sockets):
Weight:

Connection to the amplifier

Connect the Out socket to a line input (such as AUX) on your amplifier.
Make all connections whilst the USB Box is disconnected from the amplifier.
Take care to connect the left and right channels correctly. The right channel is usually marked red,
the left channel black or white.
2
© Audio Trade GmbH · Pro-Ject USB Box · Revision 15.10.10/15.12.10
® ®
and Windows 7 are trademarks of the Microsoft group of companies.
1 pair RCA/Phono sockets
0,775Vrms
Burr Brown PCM2702E 16-Bit Delta Sigma, 8-times oversampling
44,1kHz
digital serial data protocol USB 1.1
Windows XP
103 x 36 x 103 (109)mm
540g
The information was correct at the time of going to
press. The manufacturer reserves the right to make
changes to the technical specification without prior
notice as deemed necessary to uphold the ongoing
process of technical development.
® , Windows VISTA ® , Windows 7 ® and Mac OS
