14 Ventilator Assy, Passenger
Brown BC1D-64-720-90
Gray BC1D-64-720-09
15 Louver, Ventilator (a) BC1D-64-71XA
(a) Included w/Passenger Ventilator Assy
16 Panel Assy, Glove Box
w/Air Bag
Brown BC1D-64-260B-90
Gray BC1D-64-260B-09
w/o Air Bag
1995
Brown BC5E-64-260A-90
Gray BC5E-64-260B-09
1996
Brown BC5E-64-260B-09
Gray BC5E-64-260B-09
17 Cushion, Rubber (a) (2) B092-64-046
(a) Included w/Glove Box Panel Assy
18 Glove Box Assy
w/Air Bag
Brown BC1D-64-030E-90
Gray BC1D-64-030E-09
w/o Air Bag
Brown
Gray B01A-64-030C-09
19 Lock, Glove Box¶
w/Air Bag
Brown BC5E-64-090E-90
Gray BC5E-64-090E-09
w/o Air Bag
Brown B01B-64-090C-91
Gray B01B-64-090C-09
20 Stopper, Rubber¶ BC1D-64-073
¶Included w/Glove Box Assy
21 Striker, Glove Box
w/Air Bag BC1D-64-101
w/o Air Bag B01B-64-101
22 Module, Pass Air Bag-See Air Bag System Section
23 Case, Air Bag BC1D-60-A61B
24 Panel Assy, Instrument Finish
Hatchback N.A.
Sedan 95 BC1D-55-420E
96 BE5M-55-420A
Clip, Finish Panel (c)
25 Upper (2) B092-55-257
26 Lower (9) BC1D-55-257
27 Plate, Cover (c)
Hatchback N.A.
Sedan BC1D-55-182
28 Ventilator Assy, Center (c) BC1D-64-920A
29 Louver, Vent (c) (d) R BC1D-64-91XA
L S09A-64-91X
(d) Included w/Center Ventilator Assy
30 Ventilator Assy, Driver (c)
Hatchback N.A.
Sedan BC1D-64-820
31 Louver, Vent (c) (e)
Hatchback N.A.
Sedan BC1D-64-81XA
(c) Included w/Instrument Finish Panel Assy
Included w/Driver Ventilator Assy
Radio¶ BC1B-79-020
¶Order by Application
1997-98
Illustration Located in Next Column
1 Panel, Instrument
w/Air Bag
Brown BG1N-60-401C-90
Gray BG1N-60-401C-09
w/o Air Bag
Brown BG1J-60-401A-90
Gray 5G1J-60-401A-09
2 Garnish, Inst Panel (2/Side) R/L B01A-60-725
3 Member, Inst Panel
w/Air Bag BG1N-60-420D
w/o Air Bag N.A.
4 Member, Ctr Panel BG1N-60-450A
5 Brkt, Inst Panel BG1N-60-642
6 End, Inst Panel
Brown R B21H-64-950A-90
L B21H-64-960A-90
Gray R B21H-64-950A-09
L B21H-64-960A-09
7 Cover, Hole
Brown B21H-55-574-90
Gray B21H-55-574-09
madpl1_g02_
Comments or suggestions? Need assistance? Call 1-800-854-7030 or 858-578-6550. Ext. 8220. Fax 1-888-256-7969 or 858-549-0629.
Page 309—April 22, 2004—15:28:35—Version
8 Panel, Lower
Brown
Gray
9 Panel Assy, Center
10 Spring, Upper¶ (6)
¶Included w/Center Panel Assy
11 Pocket, Inst Panel
12 Ashtray Assy
13 Ashtray¶
¶Included w/Ashtray Assy
14 Bracket, Meter
15 Ventilator Assy, Side
Black
Brown
16 Louver, Ventilator¶
Black
Brown
¶Included w/Side Ventilator Assy
17 Louver, Center
Black
Brown
Panel, Glove Box
18 w/Air Bag
Brown
Gray
19 w/o Air Bag
Brown
Gray
20 Glove Box
Brown
Gray
21 Latch, Glove Box
Brown
Gray
22 Striker, Glove Box
23 Module, Air Bag-See Air Bag System Section
24 Panel Assy, Instrument Finish
25 Seal, Rubber¶ (5)
26 Cover, Panel¶
¶Included w/Instrument Finish Panel Assy
Stereo
w/Cassette
w/o Cassette

CENTER CONSOLE

Illustration Located in Next Column
1 Console Assy, Front
Procedure Explanation Pages Must Be Used with the Above Text for an Accurate Damage Report.
MAZDA 323/PROTEGE 1995-98
B21H-64-260-90
B21H-64-260-09
BG1N-55-210B
J001-64-345
BG1N-64-181A
B21H-64-610A
B21H-64-630
B21H-60-641
R BG1N-64-720A-00
L BG1N-64-820A-00
R BG1N-64-720A-90
L BG1N-64-820A-90
R/L BG1N-64-91X-00
R/L BG1N-64-91X-90
R/L BG1N-64-91X-00
R/L BG1N-64-91X-90
BG1N-64-260D-90
BG1N-64-260D-09
N.A.
N.A.
BG1N-64-030-90
BG1N-64-030-09
BC5E-64-090E-90
BC5E-64-090E-09
BG1N-64-10XA
BG1N-55-420
B21H-55-181
BG1N-55-423
LB83-79-9C0
GD7C-66-9R0
1995-96
Hatchback
Man Trans
Brown N.A.
Gray N.A.
Auto Trans
Brown N.A.
Gray N.A.
Sedan
Man Trans
1995
Brown BC4D-64-320G-90
Gray BC4D-64-320H-09
1996
Brown BE5R-64-320C-92
Gray BE5R-64-320C-09
Auto Trans
1995
Brown BC4C-64-320F-90
Gray BC4C-64-320E-09
1996
Brown BE5P-64-320C-92
Gray BE5P-64-320C-09
2 Panel Assy, Center¶
Hatchback
Brown N.A.
Gray N.A.
Sedan
Black BC1D-55-21XB-00
Gray BC1D-55-21XB-09
3 Clip, Ctr Panel¶ (a) (4) BC1D-55-257
(a) Included w/Center Panel Assy
4 Boot, Shift¶ 95 BC1D-64-330
96 BC1D-64-330C
5 Ashtray Assy¶ BC1D-64-610A
6 Ashtray¶ (b) BC1D-64-630
(b) Included w/Ashtray Assy
7 Lighter Assy¶ 95 BC1B-66-250
96 G13H-66-250
8 Element, Lighter¶ (c) C001-66-252
(c) Included w/Lighter Assy
9 Filler, Shift Opening¶ B01A-64-349A
10 Filler, Front Console¶ B01B-64-349
¶Included w/Front Console Assy
11 Console Assy, Rear
DX, GS, LS Model
1995
Brown BC1D-64-420A-90
Gray BC1D-64-420A-09
1996
Brown B16A-64-420A-90
Gray B16A-64-420A-09
LX, ES Model
1995
Brown BC1G-64-420D-90
Gray BC1G-64-420D-09
1996
Brown B16M-64-420-90
Gray B16M-64-420-09
12 Lid, Rear Console¶
LX, ES Model
Brown BC1G-64-450B-90
Gray BC1G-64-450B-09
13 Lock, Lid¶ (a) BC1G-64-45YA
14 Hinge, Lid¶ (a) BC1G-64-45XB
(a) Included w/Rear Console Lid Assy
15 Ashtray Assy¶ BC1D-64-660
16 Ashtray¶ (b) BC1D-64-680
(b) Included w/Ashtray Assy
Cover, Hole¶
Brown B16A-64-424-90
Gray B16A-64-424-09
