Electrolux 30366373P70S2 Factory Parts Catalog

30-inch free standing dual fuel range
Hide thumbs

Advertisement

Quick Links

E30DF74GPS1.eps CE30DF74GPS2.eps BRE30DF74GPS1.eps BE30DF74GPS1.eps
ME30DF74GPS1.eps DE30DF74GPS1.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
E30DF74GPS2
30366373P70S2
Series
30" dual fuel
Color
stainless
Market
North America
Wiring Diagram
318271962
Owner's Guide
318203954
Installation Instructions 318201773
Service Data Sheet
318204802
318271962.eps
Publication No.
5995502704
07/10/23
(EN/SERVICE/BJH)
377
30-INCH FREE
STANDING DUAL FUEL
RANGE
Model No.
E30DF74G
©
Copyright
2007 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading

  Related Manuals for Electrolux 30366373P70S2

  Summary of Contents for Electrolux 30366373P70S2

  • Page 1 North America Wiring Diagram 318271962 Owner's Guide 318203954 Installation Instructions 318201773 Service Data Sheet 318204802 30-INCH FREE STANDING DUAL FUEL 318271962.eps E30DF74G Publication No. 5995502704 07/10/23 (EN/SERVICE/BJH) © Copyright 2007 Electrolux Home Products, Inc. RANGE Model No. All rights reserved.
  • Page 2 Publication No: 5995502704 E30DF74GPS2 BACKGUARD CE30DF74GPS2 10/07...
  • Page 3 POS. NO PART NO. 318285722 318389500 24 # 5308015487 26 # 5304452799 318377000 318242225 318242226 318242230 318242231 318251911 318251912 318044501 318228310 54 # 5304452797 54A# 5304452798 5303300265 5304453707 318370352 318370353 318163602 # Functional Parts * Non-Illustrated Parts E30DF74GPS2 BACKGUARD DESCRIPTION Panel, control, stainless Retainer, lens Switch, oven light, rocker...
  • Page 4 Publication No: 5995502704 E30DF74GPS2 BURNER 10/07...
  • Page 5 POS. NO PART NO. 318357801 318305402 316520700 2A # 316412510 2B # 316520703 318232634 5303311306 10 # 316510800 10A# 316525400 10B# 316511200 11 # 316524800 11A# 316525100 11B# 316525000 12 # 318366727 12A# 318366731 12B# 318366732 12C# 318366729 12D# 318366730 12E# 318366728 318360600...
  • Page 6 Publication No: 5995502704 E30DF74GPS2 BODY 10/07...
  • Page 7 POS. NO PART NO. 318259222 318353100 318258922 318352702 318352703 318356002 318356003 318175506 318368800 318352404 318240103 318365800 318345404 318297302 318359500 318313601 318138801 318126401 318240014 318240015 316445501 318603913 318903401 318241002 318389400 318389000 318369301 318147411 37 # 316217002 318366601 318362600 318394600 318386100 318285079 318294912 318372001 318072577...
  • Page 8 Publication No: 5995502704 E30DF74GPS2 BODY 10/07...
  • Page 9 POS. NO PART NO. 318258715 08002868 318261428 318241406 5304461333 318111805 89 # 318261211 318370338 5303325978 318355001 316455704 318906601 108# 318073018 108A 318251300 316136400 316136600 125# 316415800 318357001 318272902 318003000 5304436875 318347800 318368400 318368401 161# 318255506 318352501 318335701 219# 318003631 3201861 316136500 318257723 318249403...
  • Page 10 Publication No: 5995502704 E30DF74GPS2 10/07...
  • Page 11 POS. NO PART NO. 316135701 318185218 318361403 316514800 316515100 316515000 316510902 316511502 316511302 316515200 316515203 316515202 318251600 318254200 318254300 316240600 318242910 318241706 318241707 318241810 318353011 318355101 318163602 318163601 5303211311 # Functional Parts * Non-Illustrated Parts E30DF74GPS2 DESCRIPTION Module, spark Main Top Assy, frame/glass, stainless/black Grate, top burner, black, (2), double Skirt, 5K burner, black Skirt, 18K burner, black...
  • Page 12 Publication No: 5995502704 E30DF74GPS2 DOOR 10/07...
  • Page 13 POS. NO PART NO. 318260523 318372000 318372002 316117500 318259633 5304400794 318053131 318344006 318264710 318353803 318244300 318057202 318392410 318242702 318370600 318382301 5304436875 318165800 316433603 318163602 5304415832 # Functional Parts * Non-Illustrated Parts E30DF74GPS2 DOOR DESCRIPTION Baffle, door Insulation, door, (2) Insulation, door, (2) Glass, oven door, heat barrier Liner, oven door Screw, handle mtg, 10-32 x 3/4...
  • Page 14: Wiring Diagram

    Publication No: 5995502704 E30DF74GPS2 WIRING DIAGRAM 10/07...
