  • Page 2 Dear customer, Please read carefully right through this instruction booklet before installing or operating your dishwasher. The following instructions should prevent the risk of personal injury and/or damage to the appliance. Please keep these documents in a safe place for later reference. This operating manual has been written for several different dishwashers, and some of the features mentioned here may not apply to your particular model.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1 Getting To Know Your 6 Troubleshooting: Machine What to do if the dishwasher will View of the Machine not run The cleaning results are 2 Safety Instructions unsatisfactory Service Before Installation Before First Use Child Safety Technical Specifications For daily operation Problems...

  • Page 4: Getting To Know Your Machine

    Getting To Know Your Machine View of the Machine �� � � �� � � � � � � � Upper dish basket with shelf �� Guide rail for the upper dish basket Cutlery basket Detergent dispenser Door Control panel Filters Lower sprayer arm Lower basket...

  • Page 5: Safety Instructions

    Technical Specifications our specifications and designs without prior notice. Permitted water pressure: 0,3 –10 bar (= 3 – 100 N/cm² = 0,01-1,0Mpa) Note for Testing Institutes Electrical connection: 220-240 Volts, The necessary information for 10 Amps (see type plate) performance testing will be provided Output: 1900-2200 W upon request.

  • Page 6: For Daily Operation

    • The water in the dishwasher is not out by qualified customer service drinking water. Danger of caustic personel. • injuries. In the event of a problem, or • Always place long and sharp/ before performing a repair, pointed objects (e.g. serving forks, disconnect the appliance from the bread knives) into the cutlery mains supply:...

  • Page 7: Directions For Assembly

    Directions for Assembly Safety notes for installation Installing Your Dishwasher • Prior to installing and using your Choose a suitable location for your appliance, please check it for possible dishwasher. Take care to ensure transit damage. that the appliance is stable on a If the appliance is damaged, please level surface.

  • Page 8: Water Connection

    Water connection Use a screw-on hose connector to connect the water inlet hose to a water Not recommended to run with hot tap with a ¾ inch external thread. If water. • required, use a filter insert to filter There are two different types of deposits from the pipes.

  • Page 9: Water Drainage

    Water drainage Extension hoses If a hose extension is required, a Connecting the drainage hose. drainage hose of equal quality must be used. Take care to ensure that the drainage hose is not bent or squeezed. The maximum length must not exceed 4m.
  • Page 10 Packaging materials may be dangerous to children. Reusable substances may be dropped off at your local disposal facilities. You may obtain further information from your local authorities and disposal facilities. Used appliances – Environmental notice This product must not be disposed of with your regular household waste.

  • Page 11: Using Your Dishwasher

    Using Your Dishwasher Filling the Rinse Aid Dispenser Rinse aids allow washing water to rinse off cleaner and prevent watermarks or streaks on the dishes. Only use rinse aid designed for use in dishwashers. 1013 If you use “2 in 1” or “3 in 1“ detergents / tablets, you do not need �...

  • Page 12: Filling The Detergent Dispenser

    Filling the Detergent Dispenser Only use detergents formulated for � use in dishwashers. Do not put solvents into the washing compartment; there is the risk of explosion! Open the detergent container by pushing the locking lever to the right (A). The lines on the inside of the detergent container will help you measure the correct amount of detergent.

  • Page 13: Multipurpose Tablets

    Please contact the manufacturer to get 3in1: Those contain detergent, rinse aid detailed information about the detergent and water softening salt. you are using. 4in1: Those containing glass protectors in addition to detergent, rinse aid and Always use powder detergents in water softening salt.

  • Page 14: Suggestions For Loading The Dishwasher

    • 4 folding plate support rods The movement of the spray arms must not be hindered (depending on the model) • Place all large and very dirty items There are four separate “folding plate in the lower basket. support rods” in the lower basket of •...
  • Page 15 2 folding plate support rods Bottle holder (depending on the model) (depends on some models) There are two separate “folding plate For cleaning your bottles. To remove, support rods” in the lower basket of pull the holders apart in opposite your dishwasher designed to allow directions (H).
  • Page 16 Variable cutlery basket (depending on the model) The variable cutlery basket can be separated into 3 parts depending on the amount of cutlery and the degree 1030 of dirtiness. Small cutlery basket sections also fit into the upper basket. � To do this, turn the lock on the handle to the right (A).
  • Page 17 Basket insert with variable height settings (depending on some models) You can also use this insert in the lower basket for glasses and long- handled cutlery / utensils. If you do not need the insert, fold the rack upwards at the angle shown (A). Push the entire insert upwards (B).

  • Page 18: Loading Suggestions

    Loading suggestions Load the upper basket with dessert 1027 plates, cups, glasses etc. Upper basket with variable height setting (depends on some models) The upper basket is equipped with a lifting mechanism which enables you to change the height of the basket without having to remove it from the 1021 dishwasher, even if it is fully loaded.
  • Page 19 Height setting with empty basket (depends on the model) In this model, the height setting of the upper basket may be changed using the wheels which are mounted at two different heights. Release the latches on both the right � and left tracks of the upper basket by 1022 pushing them outwards (C).
  • Page 20 Glass Support (depends on the model) When placing the glasses or goblets with a long grip, lean them against the glass support, the edge of the basket or the shelf but not against the other pieces. Do not lean the long glasses against each other, otherwise they do not remain stable during washing cycle 1025...

  • Page 21: How To Clean Your Dishwasher

    How to clean your dishwasher Cleaning your machine at regular intervals ensures longer product life and reduces the risk of recurring problems. Always unplug the machine and � turn off the water supply before � cleaning. Use a gentle household cleaner for the outside and the door seals.

  • Page 22: Cleaning The Spray Arms

    Cleaning the spray arms Cleaning the filter inset in the water inlet hose (depends on the model) Dirt or calcium residue may block the Dirt from deposits in the water pipes is nozzles on the spray arms. For this prevented by a filter in the water inlet reason, regularly check the spray hose.

  • Page 23: Troubleshooting

    Troubleshooting: What to do if the dishwasher will not run • Check that the mains plug is properly connected. • Are all fuses working? • Is the water supply fully turned on? • Is the dishwasher door closed firmly? • Have you pressed the On/Off button? •...
  • Page 24 Inadequate rinse aid   Increase rinse aid setting or add rinse aid into rinse aid compartment. Unsealed detergent dispenser lid   Always ensure that the detergent compartment lid is closed tightly after every detergent filling process. Drying Disorderly placement ...
  • Page 25 1035 Lime Stains, Hazy Look Inadequate rinse aid   Increase rinse aid setting or add rinse aid into rinse aid compartment. Insufficient water softening   In products equipped with water softening setting, water softening should be properly set in accordance with the hardness of the supply water. Add salt into the salt container, if necessary.
  • Page 26 1041 Scratch / Break In Glassware Kitchenware containing Aluminum   Kitchenware that contains aluminum should not be washed in dishwashers. Salt leakage*   Use the supplied salt funnel while filling in softening salt. Make sure that the salt box cover is tightly closed after finishing the filling process. Run a washing program to clean up the salts spilled in the machine.
  • Page 27 1038 Detergent Remains In The Detergent Dispenser Damp detergent compartment   Make sure that the detergent dispenser is well dried prior to filling it with detergent. Putting detergent in the detergent dispenser long before washing   Take care that detergent is put shortly before startup of washing. Blocking the opening of detergent dispenser lid dwing washing ...
  • Page 28 Leaving the dishes in the dishwasher for a long time   If you are not going to run your dishwasher immediately, load the dishes into your machine after scraping the excessive soil on them and do not tightly close the door of the machine. Every other day, perform washing without detergent in the shortest program for products with program selecting feature.

  • Page 29: Service

    Service If your appliance ever malfunctions, check the notes and advice given in the operating manual. If this does not fix the problem, our customer service staff are available to assist you. 28 GB...
  • Page 30 92611_DW245_IAG_17 xxxx 0100_AA...

  • Page 31: How To Use Your Dishwasher

    QUICK REFERENCE GUIDE ! Attention:Please read the operating manual prior to operating the machine for the first time. � � � � On/Off button Rinse aid level indicator light Start/Cancel button Programme selection button LED progress indicator lights � � Half Load (1/2) How to use your dishwasher: •...
  • Page 32 QUICK REFERENCE GUIDE � � � � On/Off button Rinse aid level indicator light Start/Cancel button Programme selection button LED progress indicator lights � � Half Load (1/2) On/off button Improper Loading Of Dishware Push in the on/off button and check that the indicator light comes Rinse aid level indicator light Visual Indicator If the indicator light comes on, you have to refill...
