Installation; Connection Diagram - Danfoss REP24CO Installation Instructions Manual

Installation

GB
First remove the wallplate from the back of the unit.
Fix at a height of approximately 1.5m from the fl oor, away
from draughts or heat sources such as fan-coil outlets,
sunlight or offi ce equipment.
Wiring

Connection Diagram

4
Electronics
A
Cool Heat
0V
0-10V outputs
Heating
Cooling
B
0V/
return
24V
24 Vac
or
COM
