Amaircare 3050 Instruction Manual

ABOUT FILTERS AND SERVICE LIFE
The life spans of the individual filters are:
STAGE 1 PREFILTER: 3 to 6 months
STAGE 2 HEPA FILTER: 2 to 5 years
STAGE 3 INNER BLANKET: 6 to 12 months
V.O.C. CARTRIDGE: 6 to 12 months (optional)
The useful service life of the filters is directly related to the volume of air
passed through the system and the amount of contaminants in the air.
If your indoor air contains abnormally high levels of airborne contami-
nants (such as cigarette smoke) the life of the filters may be shortened.
The HEPA filter's particulate removal efficiency actually improves with use
as it loads up with particulates. However, as it loads up it also becomes
more difficult to move air through the system. If you notice a significant
drop in air flow from the unit, inspect the HEPA filter. If the filter media is
darkened on the outer side, the HEPA filter should be replaced.
Specifications (all models)
CLASSIFICATION
• Portable HEPA (High Efficiency
Particulate Air) 100% Sealed Air
Cleaning Device
• U.L. and C.S.A. approved
MATERIALS: 24 gauge cold rolled steel
FINISH: Powder coated baked enamel
COLORS: Black, White & Sandstone
INTAKE (Lower Section)
Perforated steel enclosure surrounding
a three-stage filter assembly.
OUTFLOW (Upper Section)
Encloses motor/fan.
MOTOR/FAN
• Thermally protected Class "B"
insulated motor
• Designed for continuous operation
• Run tested for 50,000 hours
• Service: 120 Volt, 60 Hz or 230 Volt, 50/60 Hz
CONTROL: Variable speed
LIMITED WARRANTY
The motor/fan in this Amaircare product is warranted by Americair Corporation to the orig-
®
inal retail purchaser for FIVE (5) YEARS from the date of purchase. All other components
(except filters) are warranted for ONE (1) YEAR. Americair will repair or replace at its option
the component(s) which upon inspection by an authorized Amaircare
have failed in normal use, due to defects in material or workmanship, or, at its option, to
replace the unit. Operations other than those recommended in this manual or at voltages
other than that specified on the unit, or any attempts by unauthorized personnel to service
or modify the unit will void the warranty.
WARRANTY SERVICE IS AVAILABLE BY BRINGING YOUR UNIT, OR SENDING IT POSTAGE PREPAID,
WITH PROOF OF PURCHASE TO THE VENDOR WHO SOLD YOU THE UNIT.
AMERICAIR CORPORATION 770 Gana Court, Mississauga, Ontario, Canada L5S 1P1
Amaircare is a trade mark (registered in the U.S.) of Americair Corporation.
Americair Corporation reserves the right to change or modify any specifications without notice.
Printed in Canada 09/2001
Visit us on the Web at: www.amaircare.com
Model 2550
DIMENSIONS: 16" W 13.5"H
WEIGHT: 15 lbs.
AIR FLOW (C.F.M.): 50-175
POWER USAGE: 41-84 Watts
HEPA AREA: 50 sq.ft.
Model 3050
DIMENSIONS: 16" W 23"H
WEIGHT: 22 lbs.
AIR FLOW (C.F.M.): 50-225
POWER USAGE: 41-84 Watts
HEPA AREA: 100 sq.ft.
dealer proves to
®
Portable
Air Filtration
Systems
Instruction Manual
Models 2550 & 3050
Keep this manual for
reference purposes
