Installation Instructions Over the Range Microwave Oven BEFORE YOU BEGIN Read these instructions completely and carefully. IMPORTANT – • Save these instructions for local inspector’s use. IMPORTANT – • Observe all governing codes and ordinances. • Note to Installer – Be sure to leave these instructions with the Consumer.
Outside Back Exhaust... 18–21 Preparing Rear Wall ... 18 Attach Mounting Plate to Wall ... 18, 19 Preparation of Top Cabinet ... 19 Adjust Blower ... 19, 20 Mount the Microwave Oven... 20, 21 Before You Use Your Microwave ...22...
20 ampere branch circuit single grounded outlet. The outlet box should be located in the cabinet above the microwave oven. The outlet box and supply circuit should be installed by a qualified electrician and conform to the National...
HOOD EXHAUST NOTE: Read these next two pages only if you plan to vent your exhaust to the outside. If you plan to recirculate the air back into the room, proceed to page 11. OUTSIDE TOP EXHAUST (EXAMPLE ONLY) The following chart describes an example of one possible ductwork installation. DUCT PIECES Roof Cap 12 Ft.
Page 5
NOTE: If you need to install ducts, note that the total duct length of 3¼" x 10" rectangular or 6" diameter round duct should not exceed 140 equivalent feet. Outside ventilation requires a HOOD EXHAUST DUCT. Read the following carefully. NOTE: It is important that venting be installed using the most direct route and with as few elbows as possible.
DAMAGE – SHIPMENT/ INSTALLATION • If the unit is damaged in shipment, return the unit to the store in which it was bought for repair or replacement. • If the unit is damaged by the customer, repair or replacement is the responsibility of the customer.
• The space between the cabinets must be Bottom edge of cabinet needs 30" wide and free of obstructions. to be 33" or • This microwave oven should be mounted more from the cooking minimum of 33" above cooking service. surface •...
1.PLACEMENT OF THE MOUNTING PLATE REMOVING THE MICROWAVE OVEN FROM THE CARTON/ REMOVING THE MOUNTING PLATE Remove the installation instructions, Exhaust adaptor, filters, glass tray and the small hardware bag. Do not remove the Styrofoam protecting the front of the oven. Fold back all 4 carton flaps fully against carton sides.
DETERMINING WALL PLATE LOCATION UNDER YOUR CABINET Plate position – beneath flat bottom cabinet 16-1/2 ² Draw a vertical line on the wall at the center of ″ the 30 Tape the Rear Wall Template onto the wall matching the centerline and touching the bottom of the cabinet.
ALIGNING THE WALL PLATE Hole A Horizontal Line Area E CAUTION: Wear gloves to avoid cutting fingers on sharp edges. Draw a Vertical line on the wall at the center of the 30" wide space. Draw a Horizontal line on the wall at the bottom of “Rear Wall Template”.
2. INSTALLATION TYPES This microwave oven is designed for adaptation to the following three types of ventilation: A. Recirculating (Non-Vented Ductless) B. Outside Top Exhaust (Vertical Duct) C. Outside Back Exhaust (Horizontal Duct) RECIRCULATING (NON-VENTED DUCTLESS) See page 12 OUTSIDE BACK EXHAUST...
(Non-Vented Ductless) INSTALLATION OVERVIEW A1. Attach Mounting Plate to Wall A2. Prepare Top Cabinet A3. Mount the Microwave Oven ATTACH THE MOUNTING PLATE TO THE WALL Attach the plate to the wall using toggle bolts. At least one wood screw must be used to attach the plate to a wall stud.
Tighten the outer two screws to the top of the microwave oven. (While tightening screws, hold the microwave oven in place against the wall and the top cabinet.) Install grease filters. See the Owner’s Manual packed with the microwave.
INSTALLATION OVERVIEW B1. Attach Mounting Plate to Wall B2. Prepare Top Cabinet B3. Adjust Blower B4. Check Damper Operation B5. Mount Microwave Oven B6. Adjust Exhaust Adaptor B7. Connect Ductwork ATTACH THE MOUNTING PLATE TO THE WALL Attach the plate to the wall using toggle bolts. At least one wood screw must be used to attach the plate to a wall stud.
USE TOP CABINET TEMPLATE FOR PREPARATION OF TOP CABINET You need to drill holes for the top support screws, a hole large enough for the power cord to fit through, and a cutout large enough for the exhaust adaptor. • Read the instructions on the TOP CABINET TEMPLATE.
IMPORTANT: If filler blocks are not used, case damage may occur from over tightening screws. NOTE: When mounting the microwave oven, thread power cord through hole in bottom of top cabinet. Keep it tight throughout Steps 1–3. Do not pinch cord or lift oven by pulling cord.
Tighten the outer two screws to the top of the microwave oven. (While tightening screws, hold the microwave oven in place against the wall and the top cabinet.) Install grease filters. See the Owner’s Manual packed with the microwave.
C1. Prepare Rear Wall C2. Attach Mounting Plate to Wall C3. Prepare Top Cabinet C4. Adjust Blower C5. Mount the Microwave Oven PREPARING THE REAR WALL FOR OUTSIDE BACK EXHAUST You need to cut an opening in the rear wall for outside exhaust.
ATTACH THE MOUNTING PLATE TO THE WALL (cont.) To use toggle bolts: Spacing for Toggles More Than Wall Thickness Toggle Wings Mounting Toggle Plate Bolt Wall Bolt End Place the mounting plate against the wall and insert the toggle wings into the holes in the wall to mount the plate.
IMPORTANT: If filler blocks are not used, case damage may occur from over tightening screws. NOTE: When mounting the microwave oven, thread power cord through hole in bottom of top cabinet. Keep it tight throughout Steps 1–3. Do not pinch cord or lift oven by pulling cord.
Tighten the outer two screws to the top of the microwave oven. (While tightening screws, hold the microwave oven in place against the wall and the top cabinet.) Install grease filters. See the Owner’s Manual packed with the microwave.
BEFORE YOU USE YOUR MICROWAVE Make sure the microwave oven has been installed according to instructions. Remove all packing material from the microwave oven. Install turntable and ring in cavity. Replace house fuse or turn breaker back on. Plug power cord into a dedicated 20 amp electrical outlet.
