Features
- USB Interface
- CDC-compliant and supported by Microsoft CDC modem drivers
- Supports data/fax/TAM operation with hardware-based modem controller, digital signal processing, and
DAA/telephone line interface functions
- ITU-T V.92 data/fax modem
- Quick connect, Modem-on-Hold and 48Kbps PCM upstream supported for ITU-T V.92
- Automatic detection between data/fax calls
- Line quality monitoring and re-train
Specifications
Standards
- V.92: 56Kbps
- V.90 : 56Kbps
- V.34bis : 33.6Kbps
- V.34 : 28.8Kbps
- V.32bis : 14.4Kbps
- V.32, V.23, V.22bis, V.22, V.21
- Bell 103 and Bell 212A
LED Indicators
- "Power On" Indicator
- "In Use" Indicator
Connector and Cable
- 1 x USB Series A Cable
- 1 x RJ11 Telephone socket for telephone line
Data Mode Features
- 56Kbps Internet connectivity via ITU/TIA V.92 standard
- DTE rate of up to 460,800 bps (via Virtual UART)
USB Features
- Compatible with both USB 1.1 and USB 2.0 host
controllers and hubs
- Supports Suspend/Resume
- Bus Powered, does not require external power supply
Data Compression
- V.44
- V.42bis, MNP 5

Error Correction

- V.42, LAPM, MNP 2-4
Specifications are subjected to change without prior notice.
Trademarks: All trademarks or registered trademarks are the property of their respective owners.
Fax Modulations
- V.17 : 14.4Kbps
- V.29 : 9,600 bps
- FAX CONTROL/ PROTOCOL
- Class 1, V.21 Channel 2
- Group 3 fax mode

Operating Systems

- Microsoft Windows® Vista®, XP®, 2000®, ME®, 98SE®
- Linux

System Requirements

- Pentium 233MHz MMX PCs using Intel or AMD CPUs
Regulatory Approval
- USA (FCC Part 68 & 15, UL1950)
- Canada (Canada IC)
- China (MII & CCIB)
- Japan (JATE)
- Malaysia (SIRIM)
- Singapore (IDA)
- TBR21

Physical Dimensions

- Weight: 45g
- Dimensions: 63.5(L) x 10(W) x 15(H) mm
Package Includes
- 1 UM3100
- 1 RJ11 Telephone Cable
- 1 USB Cable
- 1 User Manual
- 1 Resource CD
Connect to the Internet Via USB Connection
Telephone
Internet
Wall Socket
Notebook with USB Port
UM3100
Desktop with USB Port
Clear Indication of
Activity with LED
UM3100 in use
with a Notebook
OR
