Headlight Aiming Device; Front Fog Light Adjustment; Headlight Adjustment Abroad - Alfa Romeo Brera Owner's Manual

fig. 83a

HEADLIGHT AIMING DEVICE

It works with the key fitted into the ig-
nition device and dipped beams on.
When the car is loaded, it slopes back-
wards. This means that the headlight
beam rises. In this case, it is necessary
to return it to the correct position.
In this event, to adjust the headlight
slant use control A-fig. 83a set on the
button control panel near the steering
wheel.
If the car is fitted with bixenon head-
lights, headlight aiming is electronic and
therefore control A is not present.
98
Control has four positions corresponding
to the loads given below:
❒ position 0 - load: driver / driver +
front passenger;
❒ position 1 - load: driver + 3 pas-
sengers / driver + 3 passengers +
load in the boot (65 kg for 2.2 ver-
sion / 50 kg for 3.2 version);
A0F0226m
❒ position 2 - load: driver + load in the
boot (290 kg for 2.2 version / 275
kg for 3.2 version);
❒ position 3 - not to be used.
IMPORTANT Check headlight slant
each time the transported load changes.
FRONT FOG LIGHT
ADJUSTMENT
Contact Alfa Romeo Authorized Services
to have the headlights correctly adjust-
ed.
fig. 84
HEADLIGHT ADJUSTMENT
ABROAD
The dipped beam headlights are adjust-
ed for circulation in the country in which
the car is marketed. In countries with
opposite circulation, to avoid glaring on-
coming vehicles, proceed as follows:
❒ remove headlight cover (see para-
graph "Dipped beam headlights" in
section "In an emergency");
❒ move lever A-fig. 84 aside.
A0F0050m
