WINDOW WASHING

RIGHT-HAND STALK

Right-hand stalk fig. 47 controls wind-
screen washer/wiper and rear window
washer/wiper operation.
With external lights on, activating the
windscreen washer will also activate the
headlight washer, if provided.

Windscreen washer/wiper

The stalk can be moved to five different
positions:
0: windscreen wiper off;
1: intermittent.
With the stalk in position 1, turning the
knurled ring A four possible intermittent
speeds are obtained:
■ = slow intermittent
■ = intermittent medium
■ = intermittent medium-fast
■ = fast intermittent
68
fig. 47
2: continuous slow
3: continuous fast
4: fast temporary (unstable position)
Operation in position 4 is limited to the
time the stalk is held in this position.
When the stalk is released, it returns
to position 0 automatically stopping the
wiper.
Never use the window
wiper to remove ice or
snow from the wind-
screen. In these conditions, the
wiper is submitted to excessive
effort that results in motor pro-
tection cutting in and wiper op-
eration inhibition for few seconds
as a consequence. If operation is
A0F0066m
not restored contact Alfa Romeo
Authorized Services.
