Glovebox Light; Boot Light - Alfa Romeo Brera Owner's Manual

fig. 40

GLOVEBOX LIGHT

To change the bulb, proceed as follows:
❒ open the glovebox;
❒ remove the light unit A-fig. 40 lev-
ering in the point shown by the ar-
row;
❒ raise protection B-fig. 41 and re-
place the snap-fitted bulb;
192
A0F0172m
fig. 41
❒ close protection B-fig. 41 on light
unit A-fig. 40;
❒ refit the light unit inserting first one
side and then the other one until
hearing the locking click.
A0F0173m
fig. 42

BOOT LIGHT

To change the bulb, proceed as follows:
❒ open the tailgate;
❒ remove the light unit A-fig. 42 lev-
ering in the point shown by the ar-
row;
A0F0205m
