Page 1 Hardware Manual...
Page 2 Hewlett-Packard makes no warranty of any kind with regard to this material, including but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
Page 3: What's New
What’s New? What’s New? Visit this page to find out what new information has been released since the last web site publish (August, 2001) and CD-ROM on August, 2001. The additions and modifications to the web site listed here are effective as of March, 2010.
Page 4 What’s New?
Page 5: System Overview
System Overview The following sections provide or point to an overview of the rp7400 server hardware and software. Hardware overview For an overview of the Enterprise Server Family hardware go to http://www.hp.com/go/hp9000_servers-docs For an overview of the HP-9000 or HP e3000 rp7400 Server hardware go to http://www.hp.com/go/hp9000_servers-docs Software Overview The HP-9000 rp7400 server is designed to operate using HP-UX version 11.0 or newer.
Page 6 System Overview...
Page 7: Product Information
Korean RFI Statement Taiwan RFI Statement Japan Safety and Regulatory Statements Acoustics (Germany) Australian C-Tick Label Laser Safety Product Information For detailed information on the rp7400 Enterprise Server product, see the following web site: http://www.hp.com/go/hp9000_servers-docs (in the Systems Hardware selection).
Page 8: Regulatory Information
Enterprise Server System Safety and Regulatory Information Regulatory Information For your protection, this product has been tested for conformance to various national and international regulations and standards. The scope of this regulatory testing includes electrical and mechanical safety, electromagnetic emissions, immunity, acoustics and hazardous materials.
Page 9: Cabinet Safety Precautions
Enterprise Server System Safety and Regulatory Information Cabinet Safety Precautions WARNING Cabinets are heavy even when empty. Exercise caution when moving cabinets whether equipment is installed in the cabinet or not. Avoid rolling cabinets on rough or uneven surfaces or inclines greater than 10 degrees. Unloading cabinets from the pallet and movement of cabinets should be performed by at least two people.
Page 10 Enterprise Server System Safety and Regulatory Information Consignes de sécurité relatives aux armoires WARNING Une armoire est lourde même lorsqu’elle est vide. Faites preuve de prudence lorsque vous en déplacer une, peu importe si des éléments y sont installés ou non. Évitez de faire rouler l’armoire sur un sol irrégulier ou incliné...
Page 11 Enterprise Server System Safety and Regulatory Information Procedimentos de Segurança - Armários WARNING Os armários são pesados, mesmo quando vazios. Tenha cuidado ao movimentar os armários, quer haja equipamentos instalados quer não. Evite deslizar os armários sobre superficies acidentadas, irregulares ou com inclinação superior a 10 graus. A retirada dos armários do palete e sua movimentação deverão ser feitas por, no...
Page 12 Enterprise Server System Safety and Regulatory Information Säkerhetsföreskrifter för kabinett WARNING Kabinetten är tunga även när de är tomma. Var försiktig när du flyttar ett kabinett, oavsett om det är tomt eller innehåller utrustning. Undvik att rulla kabinett på ett underlag som är ojämnt eller lutar mer än 10 grader.
Page 13 Enterprise Server System Safety and Regulatory Information Sikkerhedsforanstaltninger for skabe WARNING Skabene er tunge, selv når de er tomme. Vær forsigtig når De flytter skabe, hvad enten der er installeret udstyr i skabet eller ej. Undgå at rulle skabe på ru eller ujævne overflader eller skråninger der hælder mere end 10 grader.
Page 14 Enterprise Server System Safety and Regulatory Information Laitekaappia koskeva turvavaroitus WARNING Kaapit ovat tyhjinäkin painavia. Ole varovainen siirtäessäsi kaappia siitä riippumatta, onko siihen asennettu laitteistoa. Älä rullaa kaappeja karkeilla tai epätasaisilla pinnoilla tai jos pinnan kaltevuus ylittää 10 astetta. Kaappien ottamiseen alas lastausalustalta ja niiden siirtämiseen tarvitaan ainakin kaksi...
Page 15 Enterprise Server System Safety and Regulatory Information...
Page 16 Enterprise Server System Safety and Regulatory Information...
Page 17 Enterprise Server System Safety and Regulatory Information...
Page 18: Declaration Of Conformity
Enterprise Server System Safety and Regulatory Information Declaration of Conformity...
Page 19 Changes or modifications not expressly approved by Hewlett-Packard could void the user's authority to operate the equipment. Cables used with this device must be properly shielded to comply with the requirements of the FCC.
Page 20 Enterprise Server System Safety and Regulatory Information Korean RFI Statement Taiwan RFI Statement Japan Safety and Regulatory Statements...
Page 21: Acoustics (Germany)
Enterprise Server System Safety and Regulatory Information Acoustics (Germany) Acoustic noise level per ISO 9296 (25° C): <60dB (operators position) Geräuschemission (Deuschland) Geräuschemission nach ISO 9296 (25° C): <60dB (Arbeitsplatz) Australian C-Tick Label Laser Safety This product contains a laser internal to the Optical Link Module (OLM) for connection to the Fibre communications port.
Page 22 Enterprise Server System Safety and Regulatory Information...
Page 23 Review the Sales Order Review the Sales Order Customer sales order information is available through the Support Connect system and through the WWOMS (World-Wide Order Management System). Carefully review the sales order information to assess: • the number of integrated systems ordered •...
Page 24 Review the Sales Order...
Page 25 Traffic coordinator: Phone No.: Hewlett-Packard information Sales representative Order No: Representative making survey Date: Scheduled delivery date The Hewlett-Packard Site Preparation Specialist and the customer contact should discuss and agree as to any other participants included in the Site Planning Team.
Page 26 Plan the Site Visit...
Page 27 Visit the Site Visit the Site During the preliminary site visit, it is important that the Hewlett-Packard Site Preparation Specialist and the customer representative accomplish the following major tasks:...
Page 28 Visit the Site...
Page 29: Local Codes
Carefully read the Site Planning and Warranty Information provided with your system. The HP rp7400 Enterprise Servers are primarily designed to be installed and operated in computer room environments. DO NOT INSTALL HP rp7400 ENTERPRISE SERVERS IN AN OFFICE ENVIRONMENT.
Page 30: Selection Of Site Personnel
Members of the Site Planning Team should include the Site Coordinator, Principal Operator, and the Hewlett-Packard Site Preparation Specialist. When possible, the electrical contractor, a site construction coordinator (familiar with local electrical codes), and an air conditioning specialist should be included.
Page 31 If required, a Hewlett-Packard Site Preparation Specialist will be available for consultation. As a result of this visit, a site layout plan agreeable to you and Hewlett-Packard will be created. Site Verification Visit A Hewlett-Packard Site Preparation Specialist will verify that your site meets or exceeds your computer system’s requirements and specifications prior to and during system installation.
Page 32 Review HP Responsibilities...
Page 33 Verify system complicity with regulatory standards Verify system complicity with regulatory standards The following checklist should be filled out during the preliminary site visit to ensure regulatory standards are met and that any site deficiencies are identified: Table 3 Computer room Area or condition Is there a copy of the completed floor plan? Is there adequate space for maintenance needs?
Page 34 Verify system complicity with regulatory standards Table 3 (Continued) Are the input circuit breakers adequate for equipment loads? Safety Area or condition Is there an emergency power shut-off switch? Is there a telephone available for emergency purposes? Is there a fire protection system in the computer room? Is antistatic flooring installed? Are there any equipment servicing hazards? Are the proper tools and installation equipment available?
Page 35 — Site inspection and predelivery coordination meeting arranged with a Hewlett-Packard Site Preparation Specialist to review the inspection checklist and arrange a solution delivery schedule. • Solution delivery date — Final check made with an Hewlett-Packard Site Preparation Specialist to resolve any last minute problems...
Page 36 Develop the Schedule...
Page 37 Specify the Space for Unpacking Specify the Space for Unpacking Specify Uncrating Space rp7400 Systems are shipped in integrated cabinets on a 40in. x 48in. pallet. The combined height of the packaged container and the pallets are as follows: •...
Page 38 Specify the Space for Unpacking...
Page 39 Specify Raised Floor Requirements Specify Raised Floor Requirements If a raised floor system is used, a complete grounding grid for maintaining equal potential over a broad band of frequencies should be installed. The grounding grid should be connected to the equipment cabinet and electrical service entrance ground at multiple connection points via minimum #6 AWG (16mm2) wire ground connector.
Page 40 • Adequate — If the preceding systems are impossible to implement, contact a local Hewlett-Packard site preparation specialist. Arrangements can be made to provide custom lengths of ground braid to interconnect system cabinets.
Page 41: Air Plenum
Specify Raised Floor Requirements In a raised floor environment, the power drops and interface cables from the equipment are routed down through the panel pull section, through a grommet-protected opening (beneath the floor level), and under the floor panels, as shown in the following illustration: Air Plenum In some data processing environments, the underflow area is used as an air plenum, with cool, controlled air flowing under the raised floor and distributed to the heat loads out in the data processing area.
Page 42: Safety Hazards
Specify Raised Floor Requirements • Air flow impedance and misrouting • Electromagnetic interference from parallel runs in close proximity to one another • Liquid spills beneath the floor may go unnoticed for long periods. • Where cable breaches raised floor, abrasion may cause severe shock hazards. In general, cables should be routed parallel to the air flow, and not horizontal to it.
Page 43 Specify Hard Floor Requirements A cable trough may be required when an rp7400 system is installed in a computer room that does not have a raised floor. The power drops and interface cables from the SPU are routed down through the cable guides and into the cable trough.
Page 44 Specify Hard Floor Requirements...
Page 45 20A modular PDU, HP product number E7674A. This PDU has seven C13 outlets and one C19 outlet. Note that if this PDU is used to power the rp7400 SPU, any other peripherals must have their power supplied by additional PDUs in the cabinet. The PDU power cord (HP part number 8120-6903) has an...
Page 46 Specify Power Connections • 30A modular PDU, HP product number E7681A (North America) or E7682A (International). This PDU has eight C13 outlets and two C19 outlets, split across two 20A branch circuits (max. 30A available). The PDU power cord has an L6-30 plug.
Page 47: Grounding Systems
Power distribution systems consist of several parts. Hewlett-Packard recommends that these parts be solidly interconnected to provide an equal-potential ground to all points.
Page 48 (to provide low resistance and attachment points for connection to service entrance ground and HP rp7400 server equipment). The use of conductive floor tiles with this style of grid further enhances ground performance.
Page 49 #6 AWG (16mm2) wire ground conductor. See the figure following for details. Equipment grounding implementation details If it has been determined to be necessary, connect all Hewlett-Packard equipment cabinets to the site ground grid as follows: •...
Page 50 Specify Grounding Requirements • Check that the braid contact connection points are free of paint or other insulating material and treated with a contact enhancement compound (similar to Burndy Penetrox). Cable trough top Cable trough top and cable trough is used as grounding system Ground connection of panel ground wire...
Page 51 Specify the System Requirements Specify the System Requirements System Electrical Specifications Table 4 Description Specification 200 to 240 VAC AC Input Voltage Range AC Input Line frequency 50 to 60 Hz AC Input Current 18 A (max load at 200 VAC) 12 A (max load at 240 VAC) AC Inrush Current AC Input Power...
Page 52 Specify the System Requirements...
Page 53 At the SPU level, enhanced power availability is achieved through the n+1 hot-swappable power supplies. Two power supplies are required for normal rp7400 system operation and in order to allow the system to boot. The third power supply is a redundant power supply that provides the n+1 capability.
Page 54 Site-level Power High Availability Some customer sites with critical applications may require high availability power beyond the scope of the equipment provided by Hewlett-Packard. Computer room high-availability can be achieved by: • multiple substation power feeds off a single power substation •...
Page 55: Effect Of Humidity On Esd Charge Levels
Determine the ESD Requirements Determine the ESD Requirements Static charges (voltage levels) occur when objects are separated or rubbed together. The voltage level of a static charge is determined by the following factors: • Types of materials • Relative humidity •...
Page 56 Determine the ESD Requirements...
Page 57 Determine the Acoustic Requirements Determine the Acoustic Requirements The acoustic specifications for rp7400 servers are as follows: Sound power 7.5 Bels LwA maximum at >31 Sound pressure 61 dB maximum at > 31 C in operator position. 58 dB maximum at >31 C in standby position.
Page 58 Determine the Acoustic Requirements...
Page 59 Determine RFI Requirements Determine RFI Requirements Table 6 Description Specification Radiated Field Immunity 10 Volts/Meter (14KHz to 1 GHz) Magnetic Field Immunity 1 Gauss (47.5 Hz to 198 Hz) Electrostatic Discharge Immunity 15 kV (Maximum, with no loss of function) 25 kV (Maximum, with no component damage) Electrostatic Contact Discharge...
Page 60 Determine RFI Requirements...
Page 61 The Hewlett-Packard Site Preparation Specialist can assist in determining your local regulations.
Page 62 Review Local Codes...
Page 63 4500 meters above sea level Effects of Altitude Some old models of tape drives, including those supplied by Hewlett-Packard, have vacuum column transport mechanisms that are affected by atmospheric pressure. Adjustments to these mechanisms may be required to compensate for the lower atmospheric pressure at higher altitudes.
Page 64 Determine Altitude Requirements...
Page 65 40 C nonrepetitive (repetitive maximums not tested) Operating Humidity 15% - 80%, non-condensing 30% RH/hour at 65 a. These are recommended values. For operation outside these ranges, contact your Hewlett-Packard site preparation specialist. b. At altitudes up to 3,000 meters.
Page 66 Determine Temperature/Humidity Requirements Operating ranges refer to the ambient air temperature and humidity measured at the cabinet NOTE cooling air intake vents.
Page 67 Identify Sources of Electrical Interference Identify Sources of Electrical Interference The following are some of the sources of electrical interference that may affect rp7400 servers. Convenience Wall Outlets Power outlets for building maintenance equipment (i.e., vacuum cleaners, floor buffers, etc.) must be wired from circuit breakers on a power panel separate from the computer system panel.
Page 68 Identify Sources of Electrical Interference...
Page 69: Flammable Materials
Identify Other Environmental Influences Identify Other Environmental Influences The following are some of the other environmental influences that may affect rp7400 servers. Vibration Continuous vibration can cause a slow degradation of mechanical parts and, when severe, can cause data errors in disc drives. Mechanical connections such as printed circuit assembly (PCA) connectors, cable connectors, and processor backplane wiring can also be affected by vibration.
Page 70 Identify Other Environmental Influences...
Page 71 Identify Telephone Requirements and Define Remote Access At least two communication lines are required for rp7400 servers: one for the remote console facility, and another for UUCP. rp7400 servers provide remote console access via a modem for the secure console LAN, which is separate from the site or computer room’s campus LAN.
Page 72 Identify Telephone Requirements and Define Remote Access...
Page 73 Identify Special Network Requirements Identify Special Network Requirements rp7400 servers may require as many as three unique IP addresses. • The rp7400 server requires it own IP address. • The Guardian Service Processor, as a separate network device, has to have its own IP address, gateway, and subnet mask configured at the site in order to be separately addressed.
Page 74 Identify Special Network Requirements...
Page 75 SPU cabinet. • Service area — The HP recommended service area for the front and rear of the rp7400 SPU should not take precedence over local codes and regulations. However, HP does require a minimum of 0.91 meter (3 ft.) of clearance on the front or back along with 1.22 meter (4 ft.) on the opposite side (front preferred) to...
Page 76 Determine Service Access Needs...
Page 77 If a new site is to be built or an existing structure modified, consult local building codes for fire prevention and protection. Also, consult with the Hewlett-Packard Site Preparation Specialist and local fire inspector for additional information.
Page 78 Determine Fire Protection Requirements...
Page 79 Define E-Stop Requirements Define E-Stop Requirements The computer system power panel should include a shunt-trip wired to an emergency shut-off switch and a thermostat device. Electrical codes commonly stipulate that this button will remove both power AND airflow from the computer room. This is for deactivating all equipment power in case of an emergency or in case room temperature exceeds safe operating conditions.
Page 80 Define E-Stop Requirements...
Page 81: Special Tools
Determine Other Needs Determine Other Needs Special Tools If an rp7400 server is being added or installed in the top of a cabinet, a step ladder and a Genie® Load Lifter will be required. Telephone You should plan to install a telephone with a long cord near your computer system to expedite consultations with Hewlett-Packard Sales Representatives, CEs, AEs, and Response Center personnel.
Page 82 Determine Other Needs...
Page 83 Computer room space planning can also be performed using scaled templates and cutouts. In order to complete the computer room layout, the Hewlett-Packard site preparation specialist will need to do the following: •...
Page 84 Generate the Plan...
Page 85 Review the Plan With the Customer Review the Plan With the Customer 30 days prior to solution delivery date, the Hewlett-Packard Site Preparation Specialist will verify that the site meets or exceeds the system requirements and specifications. At this time, the Site Preparation...
Page 86 Review the Plan With the Customer...
Page 87 All major facility changes and primary power and air conditioning installation should be completed 30 days prior to the scheduled installation date. The Hewlett-Packard site preparation specialist may assist in arranging for the necessary contractors if requested by the customer.
Page 88 Execute the Site Plan...
Page 89 Installing a Factory Integrated rp7400 System A factory integrated system is one in which the SPU and other components have been shipped from the factory pre-installed in a cabinet. This reduces the amount of on-site time required to place a system into service.
Page 90 Medium flat blade screw driver (with 6 - 8 inch shaft) Factory Integrated Cabinet Installation procedure To install an rp7400 server, which has been received from the factory integrated in a deep cabinet, perform each of the following procedures. 1. Unpack Racked System 2.
Page 91 Server Unpacking 1. Carefully remove the carton and anti-static bag from the pallet. 2. Remove the front two (2) L-brackets. Retain the 1/2-inch bolts for later use. Rear 1. Shipping L-Bracket 2. Shipping Pallet Front As viewed from the front, one bracket is located on each side at the base of the cabinet near NOTE the front.
Page 92 Use extreme care when rolling the racked system down the ramps. A rack WARNING containing one rp7400 can weight up to 418 lbs. Do not stand in front of the ramps when rolling the cabinet off the pallet or injury may occur. All but the smallest configurations require two persons to safely remove the rack from the pallet.
Page 93: Console Connections
Console Cable Connections The links below direct you to instructions covering how to install console connections on the rp7400 system. Console Connections HP 700 series system console connections. Secure Web Console connections LAN Console connections. Direct Connect PC as a Console...
Page 94 Console Cable Connections...
Page 95 The following describes the steps required to configure the HP 700 series terminal for VT-100 mode for operation with the rp7400 server. Although any terminal capable of operating in VT-100 mode can be used, the HP700 series terminal is used here as an example because it is fairly common and it’s configuration is typical of many terminals currently in...
Page 96 HP 700 Series System Console Configuration...
Page 97 Core I/O Connections and Indicators The following paragraphs describe the operator indicators and Core I/O connections at the rear of the rp7400. 1. (Green) Core I/O board Power LED - When lit indicates that the Core I/O board has DC power available.
Page 98: Console Connection And Configuration
RS-232 Local System Console Installation The following describes how to install a system console on an rp7400 system. The HP-700 series terminal is used as an example. Other terminals may be used as a system console as long as they are configured for VT100 terminal emulation mode.
Page 99 Core I/O Connections and Indicators Although any terminal capable of operating in VT-100 mode can be used, the HP700 series terminal is used here as an example because it is fairly common and it’s configuration is typical of many terminals currently in use.
Page 100 Core I/O Connections and Indicators...
Page 101: Secure Web Console Installation
Secure Web Console Installation Secure Web Console Installation The following section describes installation of the HP Secure Web Console on an rp7400 server. For technical data, installation and configuration instructions for the Secure Web Console, see the following web site: http://www.hp.com/go/hp9000_servers-docs...
Page 102 Secure Web Console Installation To install the HP Secure Web Console on an rp7400 server, refer to the previous figure, the documentation that came with it and proceed as follows. 1. Install the wire mounting bracket by carefully inserting the two top prongs (without the plastic caps) into the vent grill at the rear of the server chassis.
Page 103 6. Connect one end (RJ-45) of the LAN cable, provided, to the LAN port on the secure web console unit. 7. Connect one end of the data/LAN cable to the port labeled Local Console Serial Port on the rp7400 server Core I/O panel.
Page 104 Secure Web Console Installation...
Page 105: Lan Console
1. Connect a cable between your PC’s network adapter and the 10BaseT LAN Console port on the rear of the rp7400 server. 2. Launch your terminal emulator software and set emulation to VT100. 3. Connect to the rp7400 server by entering the IP address for its Guardian Service Processor (GSP) and press <ENTER>...
Page 106 LAN Console...
Page 107 VT100 terminal. 1. Connect a serial port adapter cable between your PC’s serial port and the Local Console Serial Port on the rear of the rp7400 server. 2. You should have the HP-UX prompt at this point.
Page 108 PC Direct Connect as System Console...
Page 109: Scsi Devices
The HP Smart Rackmount Enclosure (C4318SZ) provides the ability to rack mount and connect two HD 50-pin SCSI external media devices to the rp7400. The Smart Rackmount Enclosure is connected to the rp7400 by a 68-pin, VHDCI connector on the Core I/O connector panel.
Page 110: Supported Scsi Cables
7 or 15 Device # Terminator Device Number order doesn’t Supported SCSI Cables The following section outlines the SCSI cables supported for use with the rp7400 server. Model Description Number C2361A 1.0 Meter VHDCI to 68P HD cable (Part# 5183-2651) C2362A 2.5 Meter VHDCI to 68P HD cable (Part# 5183-2653)
Page 111 SCSI Devices Click Here to review supported SCSI devices for the HP e3000 server. NOTE SCSI Bus Speed Selection This section describes the procedure for setting the speed of the external SCSI bus using the Boot Console Handler (BCH) commands. The HP-UX SCSI driver works with Prelude firmware to achieve correct SCSI speeds.
Page 112 SCSI Devices Default ID = 7 2. Press <Return> Example 1 Display SCSI transfer rate for a controller at 0/0/2/0 (Internal drive path) Command: SCSI RATE <0/0/2/0> Response: Path (dec) Initiator ID SCSI Rate ---------- ------------ --------- 0/0/2/0 No Limit Example 2 Set the SCSI transfer rate for a controller at 0/0/2/0 to Ultra II Command:...
Page 113: Pci Device Information
SCSI Devices SCSI BCH Commands - Summary Boot Console Handler (BCH) SCSI commands displays or sets SCSI controller parameters. These parameters are used by the operating system SCSI driver. SCSI Display all SCSI controller parameters SCSI INITiator Display SCSI controller initiator IDs SCSI INITiator <path>...
Page 114 SCSI Devices...
Page 115: Cable Management
SPU. Attention to cable management is important in multiple SPU cabinets, or SPUs and other peripheral type enclosures in the same cabinet. The rp7400 SPUs extend out the front and the rear of the cabinet for service access, so it is critical that cables be neat and dressed to allow movement without the need for re-cabling the SPUs.
Page 116 Cable Management The plastic tie-wraps are used to hold the various cables to the cable guides to provide strain relief. They can also be used to group like cable types together into one bundle, as shown: Core I/O, console Cable and LAN Guide cables...
Page 117 Cable with plastic The pictures in this section show a single rp7400 SPU with cables. For a cabinet with multiple SPUs or an SPU with peripheral component bays installed, you would want to cable from the bottom up. Be sure to leave an adequate service loop in the cables so the SPU can be extended out the front or back of the cabinet.
Page 118 Cable Management...
Page 119 Cabinet Extension Kit This section lists the contents of the rp7400 Cabinet Extension Kit(s) and the procedures for installing the components. There are three kits for the different sizes of cabinet (1.3m, 1.6m and 2.0m). Cabinet Extension Kits: • A5541A (Kit for a 1.2 meter cabinet) •...
Page 120 Cabinet Extension Kit Table 7 Cabinet Expansion Kit Contents (Continued) Part Quanti Locator Description Number A5543-0000 Door support bracket 5183-1866 Cabinet forehead, plastic Note 1: Depending on which kit is ordered is which size of side panel would be contained in the kit. Note 2: Quantities are;...
Page 121 Cabinet Extension Kit Once the cabinet has been fitted with the extension kit the original shipping material will no CAUTION longer work. All new shipping material is needed, pallet, ramps, box, and top cap. DO NOT try to use the original shipping material with the new cabinet. The cabinet must either be packaged with the new material or shipped via padded van.
Page 122 Cabinet Extension Kit Before installing the cabinet extension kit parts, you must first remove parts from the existing cabinet. Some of the parts (see note) removed are not usable with the cabinet extension kit or the rp7400 system. Preparing the Cabinet 1.
Page 123 6. Insert four bolts and washers (two each side) through the anti-tip foot into the cabinet frame. 7. Press down on the anti-tip foot until it touches the floor, then tighten the bolts. The cabinet is now ready for one or more rp7400 SPUs, or other computer components to be installed.
Page 124 Cabinet Extension Kit...
Page 125 Server Boot up rp7400 Server Boot up When booting up your system, for the first time, the first thing you should to is configure the Guardian Service processor (GSP). Failure to configure the GSP will leave the system vulnerable to unauthorized.
Page 126 Server Boot up Adding Users The GSP can only have a maximum of 20 users (one administrator and 19 operators). By design, the first user added to the GSP becomes the GSP administrator. Only the GSP administrator can add or remove users or change the GSP configuration.
Page 127 Server Boot up An example of an added users information would be: . User’s Name: Joe Smith . Organization’s Name: IT Support . Dial-back configuration: Disabled . Access Level: Operator . Mode: multiple . User’s state: enabled For the number 1 user, the Access level is administrator. The Mode entry of single only allows entry for that user one time, then access will be denied.
Page 128 Server Boot up Changing the Default GSP Configuration This section describes the process of changing GSP default configurations. To change the GSP default configuration, perform the following steps: 1. Go into the GSP with the ctrl+b entry. 2. At the GSP prompt, enter the Default Configuration (dc) command: GSP>...
Page 129: Booting The System
Server Boot up Booting the System The length of time an rp7400 will require to boot up depends on the number of processors and the amount of RAM memory installed. Average configurations can take up to 20 minutes or more.
Page 130: Initial Power-Up
Initial Power-up The following section will describe the process of applying power to the rp7400 server and booting the system up to the UNIX Login prompt. The amount of time it takes to go through self-test and boot the system will vary widely depending on hardware configuration.
Page 131 Server Boot up 2. Apply power to the rp7400 server by turning the front panel switch to ON. Power Switch (Under Cover)
Page 132 ***************************************** *************EARLY BOOT VFP ************* End of early boot detected ***************************************** Firmware Version XX.XX Duplex Console IO Dependent Code (IODC) revision 1 -------------------------------------------------------------------------- (c) Copyright 1995-1998, Hewlett-Packard Company, All rights reserved -------------------------------------------------------------------------- Processor Speed State CoProcessor State Cache Size Number...
Page 133 Server Boot up 4. When the initial power-up boot process completes, approximately one to five minutes, the BCH main menu will be displayed. ----Main Menu ---------------------------------------------------- Command Description ------------ -------------- BOot [PRI|ALT|<path>] Boot from specified path PAth [PRI|ALT] [<path>] Display or modify a path SEArch [DIsplay|IPL] [<path>]...
Page 134 Server Boot up...
Page 135 Accessing Guardian Service Processor Internal Port Accessing Guardian Service Processor Internal Port The Guardian Service Processor (GSP) internal port can be used as a “back door” to reset security options in case the GSP administrator password is forgotten, for example. It can also be used in order to upgrade the GSP firmware from an HP-UX session.
Page 136 Accessing Guardian Service Processor Internal Port...
Page 137: Service Processor Commands
Service Processor Commands These are the Service Processor commands effective January 21, 1999. Table 8 Service Processor (SP) Commands Sorted by Alphabetical Order Function Command Definition Config Configure the Automatic System Restart Config Configure Asynchronous and Modem parameters Chassis Log a chassis code in the GSP chassis code history buffer Codes Console Display the history of the Console...
Page 138 Service Processor Commands Table 8 Service Processor (SP) Commands Sorted by Alphabetical Order Function Command Definition Admin Sends a message to other terminals Session Start a Telnet session on local or remote port Remote Unlock remote support modem access Config Configure the Virtual Front Panel display Chassis Activates the immediate display of the Virtual Front Panel...
Page 139 Service Processor Commands Table 11 SP Configuration Commands (Continued) Function Command Definition Config Default configuration Config Configure LAN connected and PPP console Config Configure the Virtual Front Panel display Table 12 SP Console Commands Function Command Definition Console Display the history of the Console Console Return to Console Mode Console...
Page 140 Service Processor Commands Table 16 SP Reset Commands Function Command Definition Reset System reset through RST signal Reset Display the status of the system processors Table 17 SP Session Commands Function Command Definition Session Activate a system session on local or remote port (1 session/remote and local console) Session System reset through INIT signal...
Page 141 Shutting Down the SPU Shut down and power off the rp7400 computer system as follows: Check with the System Administrator to ensure that a system backup has recently been NOTE performed prior to shutting down the system. Step 1. Stop all active applications Step 2.
Page 142 Shutting Down the SPU Shutting Down the SPU Chapter...
Page 143 Guardian Service Processor Firmware Update Guardian Service Processor Firmware Update This section details the procedures to update the Guardian Service Processor (GSP) firmware. Before starting the update procedures, there are some pre-update activities to check or perform. • The update files exist on an FTP server accessible to the GSP LAN. •...
Page 144 Guardian Service Processor Firmware Update If you are returned to the GSP prompt (GSP>) instead of the reset message, the update was NOTE not successful. This may be caused by incorrect information, or the LAN was not configured properly. Check the LAN parameters (using the LS command) and try again. 4.
Page 145 Adding a Disk Drive to an HP-UX System Adding a Disk Drive to an HP-UX System The internal disk drives (A upper and B lower) are located in the back of the SPU. The internal disk drives are hot swapable when the proper software and hardware procedures are followed. To add a disk drive in the SPU, perform the following hardware steps: 1.
Page 146 Adding a Disk Drive to an HP-UX System # pvcreate -B /dev/rdsk/cXtXdX Step 3. Create a directory for the volume group using mkdir. Step 4. Create a device file named group in the above directory with the mknod command. Step 5. Create the root volume group specifying each physical volume to be included using vgcreate. For example: vgcreate /dev/vgroot /dev/dsk/cXtXdX Step 6.
Page 147 Adding a Disk Drive to an HP-UX System Step 2. Create a physical volume using pvcreate with the -B option. -B creates an area on the disk for a LIF volume, boot utilities, and a BDRA (Boot Data Reserved Area). For example: # pvcreate -B /dev/rdsk/cXtXdX Step 3.
Page 148 Adding a Disk Drive to an HP-UX System...
Page 149: Adding A Power Supply
Adding a Power Supply Adding a Power Supply Before unpacking the new power supply, inspect the shipping carton for obvious damage. If damage to the shipping carton is observed, report it to the carrier immediately. Carefully unpack the new power supply. Check it for damage. If no damage is observed, proceed with the instructions that follow.
Page 150 Adding a Power Supply Power Supply Power Switch 12. Replace the EMI shield by inserting the tabs on the top of the EMI shield into the slots chassis just below the front panel. Then push the EMI shield into the chassis and tighten the two mounting screws on the bottom.
Page 151: Add-On Memory
Memory Configuration Rules rp7400 systems support up to 4 memory carriers (numbered 0, 1, 2, and 3), each with slots for 4 memory DIMM pairs (numbered 0a/b, 1a/b, 2a/b, and 3a/b). For the DIMMs to work, both DIMMs in a slot pair must be the same type (i.e., the same part number).
Page 152 Before starting any shut down type procedures, be sure to check with the System Administrator or customer to ensure a system backup has been performed recently. To shut down and power off the rp7400 computer system, perform the following steps. a. Stop all active applications.
Page 153 CAUTION Operating the system without the back air baffle will create air flow problems and possibly shorten the life of the internal components. Hewlett-Packard does not recommend the system be powered on with the air baffles removed. Also, operation of the system without the top cover and air baffle in place can make the system susceptible to EMI problems.
Page 154 CAUTION Operating the SPU without the back air baffle will create air flow problems and possibly shorten the life of the internal components. Hewlett-Packard does not recommend the SPU be powered on with the air baffles removed. Also, operation of the SPU without the top cover and air baffle in place can make the SPU susceptible to EMI problems.
Page 155 Add-On Memory c. Tighten the two captive screws at the support bridge. Step 10. Replace the Back Top Cover To replace the back top cover in the SPU: a. Angle the back edge of the top cover into the support bridge. Be sure the tabs at the back edge of the top cover insert into the slots on the support bridge.
Page 156 Press the front bezel onto the cabinet until it snaps into place. Step 13. Power the System On Before applying A.C. power to an rp7400 computer, be sure all covers and cooling CAUTION fans are properly installed. Failure to perform this check could result in decreased computer component life and reliability.
Page 157 Add I/O Cards Add I/O Cards The rp7400 server has 12 expansion I/O slots accessible through side panels on the rear of the SPU chassis. Six slots are located on each of the two sides. Slots 3 through 12 are “TwinTurbo” slots supporting 66MHz, 64-bit I/O cards. Slots 1 and 2 are “Turbo” slots supporting cards with lower speed and bandwidth.
Page 158 Add I/O Cards Step 1. Remove Power from the System. CAUTION Before starting any shut down type procedures, be sure to check with the System Administrator or customer to ensure a system backup has been performed recently. To shut down and power off the N Class computer system, perform the following steps. a.
Page 159 Add I/O Cards The SPU should now be fully extended out the back of the cabinet. WARNING Only extend one SPU at a time. Never attempt to extend more that one SPU for any reason. Step 4. Remove the PCI Cover Plate NOTE Steps 4 through 8 apply to the six PCI card slots on either side of the SPU.
Page 160 Press the front bezel onto the cabinet until it snaps into place. Step 9. Power the System On Before applying A.C. power to an rp7400 computer, be sure all covers and cooling CAUTION fans are properly installed. Failure to perform this check could result in decreased computer component life and reliability.
Page 161 Add I/O Cards I/O Scan-to-Slot Matrix Slot Number Hardware Path Slot Type 0/5/0 2xPCI 0/5/0 2xPCI 0/4/0 4xPCI 0/8/0 4xPCI 0/10/0 4xPCI 0/2/0 4xPCI 1/12/0 4xPCI 1/10/0 4xPCI 1/4/0 4xPCI 1/2/0 4xPCI 1/8/0 4xPCI 1/0/0 4xPCI Core I/O 10/100 base T 0/0/0/0 Core I/O ext SCSI 0/0/1/0...
Page 162 Add I/O Cards...
