ViewSonic CDP6530T Datasheet page 2

65" (64.5" Viewable) Touch Commercial LCD Display
Input D-Sub DVI
D-Sub — Yes
DVI Yes —
HDMI Yes —
YPbPr — No
CVBS-1 — No
S-Video — No
P.S. Position and size of PIP window is fixed, can not change.
Expand Your Options with Plug-and-Play Connectivity
Versatile inputs include – HDMI, DVI, VGA, YPbPr, CVBS (BNC) S-video and
composite video. RS232 daisy-chain capable
Line IN
Audio Out
Specifications
LCD PANEL Type
Display Area
Optimum Resolution
Contrast Ratio
Dynamic Contrast Ratio
Viewing Angles
Response Time
Light Source
Brightness
Aspect Ratio
Panel Surface
TOUCH Type
Capability
Support OS
Touch Resolution
Accuracy
Response Time
Touch Method
Connection
Glass
OPS
INPUT Video Input
Video Output
Control Input/Output
AUDIO OUTPUT Speakers
Amplifier
INPUT SIGNAL TV/Video Comp.
CONNECTOR Analog
Digital
Power
POWER Voltage
Consumption
*Power savings may vary based on acutal usage and other factors. Specifications and availability are subject to change without notice. Selection, offers and programs may vary by country; see your ViewSonic representative for
complete details.Corporate names, trademarks stated herein are the property of their respective companies. Copyright © 2012 ViewSonic Corporation. All rights reserved. [16150-00B-05/12] CDP6530T
Sales: (888) 881-8781 or SalesInfo@ViewSonic.com • More product information: www.ViewSonic.com
PIP matrix
HDMI YPbPr CVBS-1
Yes — —
— Yes No
— Yes No
No — —
No — —
No — —
Speakers HDMI
Audio In DVI-D
(L/R)
65" (64.5" viewable) color TFT active matrix, wide LCD
56.2" horizontal x 31.6" vertical; 64.5" diagonal
1920x1080, 600mm dot pitch
5000:1 (typ)
20,000:1
178º horizontal, 178º vertical
8ms
Long life, 50,000 hrs. (typ)
500 cd/m2 (typ)
16:9
Anti-glare, hard coating (3H)
Optical Imaging
2 simultaneous touches
Windows 2000, XP, Vista , Windows 7 (multi-touch requires
® ®
driver), Max OS X, and Linux (requires evtouch)
32,767 x 32,767
+/- 3.5 mm over 95% of touchable area
9 ms to 22 ms depending on configuration; 14 ms (typ)
Toush with any object, Finger, Pen or Brush
USB
5mm tempered glass
Open Pluggable Specification slot (OPS) ready
HDMI, DVI, component, VGA, S-video, CVBS (BNC)
VGA, component
RS-232
Internal 12-watt (x2)
12-watt / 8 ohm
480i, 480p, 720p, 1080i, 1080p
15-pin mini D-sub (VGA)
HDMI, DVI, S-video YPbPr, CVBS
3-pin plug
AC 100–240V (universal), 50–60Hz
520W (typ)
S-Video
—
No
No
—
—
—
VGA Component
In/Out
RS-232
S-Video
In/Out
CONTROLS
OPERATING Temperature (landscape)
CONDITIONS Temperature (portrait)
DIMENSIONS Physical With Stand
(W x H x D) Physical Without Stand
WEIGHT
WALL MOUNT
REGULATIONS
RECYCLE/DISPOSAL
WARRANTY
COUNTRY OF ORIGIN
What's in the box?
CDP6530T LCD Display, power cable, remote control with batteries, User Guide, Quick Start Guide
Wall Mount-Ready
Video AC In/Out
In/Out
Main Power
Switch
Panel Power, Exit, +, –, Menu/Enter
Picture Picture mode, contrast, brightness, color temperature,
temperature adjust, sharpness
VGA Setting Auto adjustment, clock, phase, sharpness,
H. position, V. position
OSD Setting Languages, OSD H. position, OSD V. position, OSD timer
Input VGA, DVI, HDMI, YPbPr
Audio Volume, mute, audio source
Special Aspect ratio, over scan, power save, image retention,
auto adjustment, monitor ID, reset
Diagnostic Thermal, back light, ambient, 5V detect, 12 detect
32–104ºF (0–40ºC)
41–95ºF (5–35ºC)
Humidity 20–90% (non-condensing)
59.9" x 40.4" x 16.4" / 1522 x 1026 x 417 mm
59.9" x 35.5" x 5.4" / 1522 x 903 x 138 mm
Packaging 64.8" x 41.2" x 11.7" / 1647 x 1046 x 298 mm
Net 156.5 lb. / 71 kg
Gross 189.6 lb. / 86.0 kg
VESA 200mm x 400mm, 400mm x 400mm
®
FCC, ICES003, UL, cUL, CE, CB, ENERGY STAR
The lamp in this product contains mercury. Please dispose
of in accordance with local, state or federal laws.
Three-year limited warranty on parts, labor and backlight
Taiwan
CDP6530T
, RoHS
®
ViewSonic Corporation's QMS & EMS
have been registered to ISO 9001 & ISO
14001, respectively, by TUV NORD.
