Tascam DV-RA1000HD Technical Documentation

PRODUCT OVERVIEW
The TASCAM DV-RA1000HD
features the world's most
advanced method of recording
high-resolution stereo audio on
optical disk or internal 60GB
hard drive. The DV-
RA1000HD is fitted with digital
I/O in all common formats,
including S/DIF3 (Direct Stream Digital), as well as high quality AD and DA conversion. The DV-
RA1000HD can be connected to a personal computer, through USB 2.0, where files can be transferred for
further processing, editing, and mastering. Edit titles and add project notes with PS/2 keyboard connected
to the front panel. The DV-RA1000HD contains an A/C independent clock/calendar which timestamps all
files recorded on a DVD/HD that can be viewed when connected to a computer.
The DV-RA1000HD includes DSP for EQ and dynamics processing that can be inserted on recording or
playback. The DV-RA1000HD can provide more than 60 hours of recording to hard drive and burn these
files to CD or DVD, making it ideal for event recording, archival, and extended playback applications.
High-quality stereo recording at up to 192kHz/24-
bit or DSD format
Records to Built-in 60GB hard drive, DVD+RW,
CD-R/RW media
Archives to DVD-R, DVD-RW, DVD+R and
DVD+RW discs
Multi-band compression and 3-band EQ mixdown
effects
USB 2.0 connection to PC for use as DVD data
drive
Balanced AES/EBU inputs and outputs, running at
normal, double-speed and double-wire formats
Records to standard CD-DA, Broadcast Wave and
DSDIFF formats
Various play and record modes such as auto track
increment, auto cue, auto ready, single/continuous
play, program A/B play and synchronized
recording.
TASCAM 7733 Telegraph Road Montebello, CA 90640 (323) 726-0303
All features and specifications are subject to change without notice. Contact your local TASCAM representative for the latest information.
DV-RA1000HD
Technical Documentation
MSRP $ 2,499.00
User-definable function keys
Large, backlit LCD display
Word Sync In, Out, Thru
RS-232C serial control
±6% pitch control
Fade in/out
Jog playback
Power on play feature
Wired remote control (RC-
RA1000) included
Headphone output
PS/2 keyboard connector for title
editing
http://www.tascamcontractor.com
RS-232
1
TASCAM DV-RA1000HD
