Panasonic AG-HCK10G Brochure page 12

Suppresses Blocked Shadows and Blown Highlights
Dynamic Range Stretch (DRS)
A gamma curve and knee slope are estimated to match the contrast of each
pixel, and applied in real time. When dark, bright, and intermediate shades
are all contained in the same scene, this produces excellent gradation for
each shade and minimizes blocked shadows and blown highlights. The
images that result are enhanced by a visually wider dynamic range.
Images with the Dynamic Range Stretch (DRS) Effect
Image with DRS OFF
Blown highlights
are suppressed.
Highly Detailed Image Composition
Advanced Pro-tuning Functions
•
Matrix settings
Lets you choose basic color hues that convey the desired overall image mood.
NORM1 For colors suited to shooting outdoors or under halogen lights.
NORM2 For colors more vivid than NORM1.
FLUO For colors suited to shooting indoors under fluorescent lights.
CINE-LIKE To reproduce colors similar to those in movies.
•
Knee point settings
Controls the highlights within the frame. (AUTO/LOW/MID/HIGH)
•
Adjustable detail level, V detail level, detail coring and skin tone detail
Corrects edges, removes image noise, smoothes skin's texture.
•
Adjustable chroma level, chroma phase, color temp and master pedestal
Sets the basic levels for brightness and other signals.
•
White balance
1-value memory, 2-value preset (3200 K, 5600 K) and Auto Tracking White (ATW).
•
Zebra
Select any two levels from among 50 % to 105 %, in 5 % steps.
Options
VW-W4307H
Wide-conversion lens
* These options are not available in some areas.
Image with DRS ON
Blocked shadows
are suppressed.
Cine-like Gamma Curves
7-mode Gamma for Richer Gradation
Drawing on technologies developed for the VariCam HD camera recorders
for digital cinema, Panasonic has equipped the AG-HCK10G with
advanced gamma functions that address seven different shooting
scenarios and enhance your creative abilities. This includes the cine-like
gamma, which produces the characteristic warm tone of film recordings.
AG-HCK10G Gamma Modes
HD NORM Suitable for HD recording
LOW Works to flatten out a high contrast scene
SD NORM Normal setting for SD (This was available in the DVX100 series.)
HIGH Expands the tone of dark parts and make a brighter image. The contrast softens
B.PRESS Makes the contrast sharper than LOW
CINE-LIKE-D The Cine-like mode shifted to prioritize dynamic range
CINE-LIKE-V The Cine-like mode shifted to prioritize contrast
Quick, Easy Focusing
HD Focus Assist Function
In addition to the center zoom function, which enlarges the center area of
the image for easier focusing, a focus bar can be displayed to indicate the
focus level by the length of the bar. A peak hold function in the focus bar
makes it easy to find the optimal focus position. The One-Push Auto Focus
mode also lets you temporarily switch to AF mode during manual focusing.
Image before center zoom
Wide Range of Settings
Slow Shutter and Synchro Scan Functions
The slow shutter function uses image accumulation to allow shutter
speeds with frame rates reduced by half or more. The accumulation
method provides bright-color images with less noise than those captured
using conventional gain-up, so you get the higher sensitivity needed for
nighttime shooting without illumination.
VW-T4314H
Tele-conversion lens
Image with center zoom
* This function
cannot be
used for digital
zooming.
Focus Bar
As of March 2011
AG-C20003G 3 m (9.84 ft)
AG-C20020G 20 m (65.62 ft)
Camera Head Option Cable
12
