Panasonic AG-HCK10G Brochure page 10

S up erb Ful l- HD I m a g e Qu a l it y
High-Quality, Multi-Angle Shooting
A 3MOS System with Full-HD Sampling
Camera Head
for AG-HMR10 (optional)
AG-HCK10G
Allows Operation from a Distance
Teams with AG-HMR10 Recorder
Zoom, focus, iris, shutter speed and white balance adjustments, as well
as camera setup, can all be made from the AG-HMR10. Its built-in stereo
microphone also lets you adjust the audio levels. The camera head
option cable (optional) comes in 3 m (9.84 ft) (AG-C20003G) and 20 m
(65.62 ft) (AG-C20020G) lengths to match your application.
Highly Detailed Image Capture
A Progressive 3MOS Sensor with Approx. 2.51 Megapixels
The progressive 3MOS image sensors record full-HD images with a total,
3.05-megapixel (approx.) resolution [effective motion-image resolution of
2.51 megapixels (approx.)]. This produces full-raster HD images with high
resolution and superb image quality. Because each of the three separate
image sensors receives one of the three primary colors of light (red, green and
blue), they render more precise images and more faithful colors than the single
light-receiving 1MOS sensor.
What's the 3MOS System?
3MOS
(MOS= Metal Oxide Semiconductor)
Image Sensors Process the three primary colors of light (red, green and blue).
1MOS
Light
RGB filter
Image sensor
Light of any color other than
the filter color is absorbed.
HD multi-format recording
Recording Format When set to 59.94 Hz
1080/59.94i
1080
1080/29.97p,
1080
1080/23.98p (Native*
(only PH mode)
720/59.94p, 720/29.97p,
720
720/23.98p (Native*
(only PH mode)
* When the system frequency has been changed, turn the unit's power off
and then back on so that the setting takes effect.
*1: In the Native mode, AG-HMR10 record only active frames.
10
3MOS
Light
Prism
sensor
The 3MOS system offers three times
the light utilization of a 1MOS system.
When set to 50 Hz
1080/50i
1080/25p
1
)
720/50p,
1
)
720/25p
Up to 120x Zoom Power
HD Lens Unit
Even at the 490 mm zoom setting (35 mm lens equivalent), this advanced 12x
optical zoom lens is free of image degradation. And the AG-HMR10 is
equipped with a digital zoom that instantly magnifies the image by any of
three fixed values. 2x, 5x or 10x. Use it together with the 12x optical zoom
lens, and you get super magnification equivalent to a 120x zoom, without the
drop in light intensity that happens when using a lens extender. This advanced
lens also lets you capture 40.8 mm wide-angle shots (35 mm lens equivalent)
— unusual for such a compact unit.
* The image quality decreases as the digital zoom magnification increases.
Image with Wide-angle Image with 12x optical zoom Image with 12x optical zoom x
Take Clear Shots While Walking or Zooming
Optical Image Stabilizer (OIS)
Because hand-shake correction is done by actually driving the lens, there's
none of the image degradation that occurs with electronic stabilization. You
can capture beautiful, high-quality shots even in situations where
hand-shake is typically a big problem — such as when zooming, shooting
indoors in dim lighting, or shooting outdoors at night.
* Hand-shake from strong vibrations may remain.
Also, visible differences may be slight under some conditions.
Image with OIS OFF
* The image is simulated.
10x digital zoom (120x)
Image with OIS ON
