Computer Setup-Power - HP Compaq MultiSeat ms6000 Manual

Table 4 Computer Setup—Security (continued)
Option
Master Boot Record
Security
Setup Security Level
Computer Setup—Power
NOTE: Support for specific Computer Setup options may vary depending on the hardware
configuration.
Table 5 Computer Setup—Power
Option
OS Power
Management
ENWW
Description
Allows you to disable/enable Master Boot Record Security.
●
Save Master Boot Record – This option will appear if Master Boot Record Security is enabled.
It allows you to save a copy of the Master Boot Record into non-volatile storage.
● Restore Master Boot Record – This option will appear on the next boot once the Master Boot
Record has been saved. It allows you to restore the saved copy back to the hard drive's Master
Boot Record.
Provides a method to allow end-users limited access to change specified setup options, without
having to know the Setup Password.
This feature allows the administrator the flexibility to protect changes to essential setup options,
while allowing the user to view system settings and configure nonessential options. The administrator
specifies access rights to individual setup options on a case-by-case basis via the Setup Security
Level menu. By default, all setup options are assigned Setup Password, indicating the user must
enter the correct Setup Password during POST to make changes to any of the options. The
administrator may set individual items to None, indicating the user can make changes to the specified
options when setup has been accessed with invalid passwords. The choice, None, is replaced by
Power-On Password if a Power-On Password is enabled.
NOTE: Setup Browse Mode must be set to Enable in order for the user to enter Setup without
knowing the setup password.
Description
●
S5 Maximum Power Savings—Enable/Disable. Enabling this feature reduces the power of this
system as much as possible in the S5 state. Power is removed from the wake up circuitry, the
expansion slots, and any management features while in S5.
● Runtime Power Management— Enable/Disable. Allows certain operating systems to reduce
processor voltage and frequency when the current software load does not require the full
capabilities of the processor.
● Idle Power Savings—Extended/Normal. Allows certain operating systems to decrease the
processors power consumption when the processor is idle.
●
ACPI S3 Hard Disk Reset—Enabling this causes the BIOS to ensure hard disks are ready to
accept commands after resuming from S3 before returning control to the operating system.
● ACPI S3 PS2 Mouse Wakeup—Enables or disables waking from S3 due to PS2 mouse activity.
●
USB Wake on Device Insertion (some models)—Allows system to wake from Standby on USB
device insertion.
● Unique Sleep State Blink Rates—Enable/Disable. This feature is designed to provide a visual
indication of what sleep state the system is in. Each sleep state has a unique blink pattern.
◦
S0 = Solid green LED.
◦
S3 = 3 blinks at 1Hz (50% duty cycle) followed by a pause of 2 seconds (green LED) —
repeated cycles of 3 blinks and a pause.
Computer Setup (F10) Utilities 9
