Specifications - Sharp CD-XP300 - Compact Stereo System Service Manual

FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER
TO THE OPERATION MANUAL.
CD-XP300 (Except for Canada)/CD-XP3300
General
Power source AC 120 V, 60 Hz
Power consumption 107 W
Dimensions Width: 10-5/8" (270 mm)
Height: 13" (330 mm)
Depth: 13-15/16" (355 mm)
Weight 17.4 lbs. (7.9 kg)
Amplifier
Output power 100 watts minimum RMS per channel into 6 ohms from
60 Hz to 20 kHz, 10% total harmonic distortion
Output terminals Speakers: 6 ohms
Headphones: 16 - 50 ohms (recommended: 32 ohms)
Input terminals Video/Auxiliary (audio signal): 500 mV/47 kohms
CD player
Type 3-disc multi-play compact disc player
Signal readout Non-contact, 3-beam semiconductor laser pickup
D/A converter 1-bit D/A converter
Frequency response 20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)
Tuner
Frequency range FM: 87.5 - 108 MHz
AM: 530 - 1,720 kHz
CD-XP300 (For Canada)
General
Power source AC 120 V, 60 Hz
Power consumption 107 W
Dimensions Width: 270 mm (10-5/8")
Height: 330 mm (13")
Depth: 355 mm (13-15/16")
Weight 7.9 kg (17.4 lbs.)
Amplifier
Output power RMS: 200 W (100 W + 100 W) (10 % T.H.D.)
Output terminals Speakers: 6 ohms
Headphones: 16 - 50 ohms (recommended: 32 ohms)
Input terminals Video/Auxiliary (audio signal): 500 mV/47 kohms
CD player
Type 3-disc multi-play compact disc player
Signal readout Non-contact, 3-beam semiconductor laser pickup
D/A converter 1-bit D/A converter
Frequency response 20 - 20,000 Hz
Dynamic range 90 dB (1 kHz)

SPECIFICATIONS

Cassette deck
Frequency response
Signal/noise ratio
Wow and flutter
CP-XP300 (Except for Canada)
Type
Maximum input power
Rated input power
Impedance
Dimensions
Weight
CP-XP3300
Type
Maximum input power
Rated input power
Impedance
Dimensions
Weight
Tuner
Frequency range
Cassette deck
Frequency response
Signal/noise ratio
Wow and flutter
CP-XP300 (For Canada)
Type
Maximum input power
Rated input power
Impedance
Dimensions
Weight
Specifications for this model are subject to change without
prior notice.
– 3 –
CD-XP300/CD-XP3300
50 - 14,000 Hz (Normal tape)
55 dB (TAPE 1, playback)
50 dB (TAPE 2, recording/playback)
0.3 % (WRMS)
2-way type speaker system
2" (5 cm) Tweeter
6-1/2" (16 cm) Woofer
200 W
100 W
6 ohms
Width: 8-11/16" (220 mm)
Height: 13" (330 mm)
Depth: 9-1/8" (232 mm)
7.3 lbs. (3.3 kg)/each
2-way type speaker system
2" (5 cm) Tweeter
6-1/2" (16 cm) Woofer
200 W
100 W
6 ohms
Width: 8-11/16" (220 mm)
Height: 13" (330 mm)
Depth: 9-3/8" (238 mm)
7.0 lbs. (3.2 kg)/each
FM: 87.5 - 108 MHz
AM: 530 - 1,720 kHz
50 - 14,000 Hz (Normal tape)
55 dB (TAPE 1, playback)
50 dB (TAPE 2, recording/playback)
0.3 % (WRMS)
2-way type speaker system
5 cm (2") Tweeter
16 cm (6-1/2") Woofer
200 W
100 W
6 ohms
Width: 220 mm (8-11/16")
Height: 330 mm (13")
Depth: 232 mm (9-1/8")
3.3 kg (7.3 lbs.)/each
