Attach the TV to
Connect video
the Stand
devices
Step
Step
1
Warning: Screens can be damaged
from direct pressure when handled
incorrectly. We recommend lifting the
TV by the edges, as shown.
Step 1
Attach the TV to the Stand
1
REQUIRED TOOLS: a Phillips head screwdriver and a soft, flat surface larger than the TV
(such as the box).
2
Base
3
L
R
x4 (M4 X L12)
4

QUICK START

GUIDE
BN68-05037A-01
Insert the
Power on and
batteries into the
start the initial
remote control
setup
Step
Step
2
3
Open the package, and take the cushioning out
of it.
Put a base, legs and screws off to assemble the
stand out of the box.
x 2
x 8
Leg
Screws
Fit the base and legs together, making sure that
the legs are firmly aligned with the base. See the
diagram below.
Insert 2 screws through the base into each leg as
shown, and then secure the legs to the base with
a screwdriver.
Welcome to your new Smart TV!
The following instructions cover assembling, connecting, and setting up your new TV. Make
sure you have the accessories listed below.
Included in this box
Remote Control
Smart Touch Control
4
Batteries (AAA x 2)
Wall mount adapter
RCA Adapter x 2
Also included: User manual, regulatory guide, 3D Active Glasses
5
6
7
x4 (M4 X L12)
8
Stand Parts and Cables
x 2
Screw Cover
Power inlet cover
x 2
TV holder kit
Component adapter
Lay the TV on a soft surface, screen side down.
Use the packing material to protect the screen.
Holding the stand parallel to the screen, slide the
stand legs into the notches on the back of the TV.
Insert 4 screws and secure the stand to the TV.
When placing the product on a console or shelf,
make sure that the stand does not protrude
out of the console or shelf. This may cause the
product to fall off and result in a malfunction or
injury.
Cable clip
Power cord
IR extender
