Patch release note 86261-04

Advertisement

Quick Links

Patch Release Note
Patch 86261-04
For Rapier and AT-8800 Series Switches
Simply connecting the world
Introduction
This patch release note lists the issues addressed and enhancements made in
patch 86261-04 for Software Release 2.6.1 on existing models of Rapier and
AT-8800 Series switches. Patch file details are listed in Table 1.
Table 1: Patch file details for Patch 86261-04.
Base Software Release File
Patch Release Date
Compressed Patch File Name
Compressed Patch File Size
This release note should be read in conjunction with the following documents:
Release Note: Software Release 2.6.1 for Rapier and AT-8800 Series
Switches (Document Number C613-10383-00 Rev A) available from
www.alliedtelesyn.co.nz/documentation/documentation.html.
Rapier Series Switch or AT-8800 Series Switch Documentation Set for
Software Release 2.6.1 available on the Documentation and Tools CD-ROM
packaged with your switch, or from
documentation.html.
WARNING: Using a patch for a different model or software release may cause
unpredictable results, including disruption to the network. Information in this
release note is subject to change without notice and does not represent a
commitment on the part of Allied Telesyn International. While every effort has
been made to ensure that the information contained within this document and
the features and changes described are accurate, Allied Telesyn International
can not accept any type of liability for errors in, or omissions arising from the
use of this information.
86-261.rez
19-Nov-2003
86261-04.paz
261628 bytes
www.alliedtelesyn.co.nz/documentation/

Advertisement

loading
Need help?

Need help?

Do you have a question about the Patch 86261-04 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Allied Telesis Patch 86261-04

  • Page 1 Introduction This patch release note lists the issues addressed and enhancements made in patch 86261-04 for Software Release 2.6.1 on existing models of Rapier and AT-8800 Series switches. Patch file details are listed in Table 1. This release note should be read in conjunction with the following documents: ■...
  • Page 2 Level 3 Level 4 Features in 86261-04 Patch 86261-04 includes all issues resolved and enhancements released in previous patches for Software Release 2.6.1, and the following enhancements: PCR: 03910 When RIP demand mode was enabled, and one interface changed to a...
  • Page 3 Patch 86261-04 For Rapier and AT-8800 Series Switches PCR: 31009 The server string was not copied correctly into an HTTP file request when loading information from the configuration script. This issue has been resolved. PCR: 31064 When 10/100 copper ports were disabled with the DISABLE SWITCH PORT command, their link state was still UP.
  • Page 4 DVMRP Routers: 224.0.0.4 OSPFIGP all routers: 224.0.0.5 OSPFIGP designated routers: 224.0.0.6 RIP2 routers: 224.0.0.9 All PIM routers: 224.0.0.13 All CBT routers: 224.0.0.15 DVMRP Routers: 224.0.0.4 All PIM routers: 224.0.0.13 Patch Release Note Patch 86261-04 for Software Release 2.6.1 C613-10386-00 REV D...
  • Page 5 Patch 86261-04 For Rapier and AT-8800 Series Switches DELETE IGMPSNOOPING ROUTERADDRESS Syntax DELETE IGMPSNOOPING ROUTERADDRESS=ipaddr[,...] where • Description This command deletes reserved IP multicast addresses from the list of router multicast addresses. The IP address specified must be within the range 224.0.0.1 to 224.0.0.255.
  • Page 6 Module: SWI Dot1dStpPriority Dot1dStpBridgeMaxAge Dot1dStpBridgeHelloTime Dot1dStpBridgeForwardDelay Module: DHCP Module: PIM, PIM6 Module: DHCP Module: IPG Patch Release Note Level: 4 Level: 3 Level: 3 Level: 3 Level: 2 Level: 2 Level: 4 Patch 86261-04 for Software Release 2.6.1 C613-10386-00 REV D...
  • Page 7 Patch 86261-04 For Rapier and AT-8800 Series Switches PCR: 31154 The current implementation of RSTP conforms to the IEEE standard 802.1w-2001. However, several minor deviations from the standard are possible without having a functional impact on the behaviour of RSTP.
  • Page 8 PURGE USER ENABLE USER DISABLE USER RESET USER Module: SW56 Module: SWI Module: SWI, SW56 Patch Release Note Level: 2 Level: 2 Level: 3 Level: 2 Level: 2 Level: 2 Level: 2 Patch 86261-04 for Software Release 2.6.1 C613-10386-00 REV D...
  • Page 9 Patch 86261-04 For Rapier and AT-8800 Series Switches PCR: 31191 A device in a supplicant role failed to authenticate if it used EAP-MD5 encryption with Windows 2000 or 2003 Server as the RADIUS server. Also, a fatal error occurred if the device received EAPOL packets containing a very large value in the packet length field.
  • Page 10 Software Release 2.6.1, and the following enhancements: Module: SNMP Module: SW56 Module: CORE 86-261.rez 7-Nov-2003 86261-03.paz 176500 bytes Module: SWI 86-261.rez 3-Nov-2003 86261-02.paz 384839 bytes Patch Release Note Level: 4 Level: 1 Level: 3 Level: 2 Patch 86261-04 for Software Release 2.6.1 C613-10386-00 REV D...
  • Page 11 Patch 86261-04 For Rapier and AT-8800 Series Switches PCR: 03726 The time recorded when a user logged in was overwritten when the same user logged in a second time while the original connection was still active. This meant the SHOW USER command displayed the same time for both connections.
  • Page 12 Module: IPG Module: IPG Module: FIREWALL Module: BGP, IPG Patch Release Note Level: 2 Level: 1 Level: 2 Level: 2 Level: 2 Level: 3 Level: 3 Level: 3 Level: 3 Level: 2 Patch 86261-04 for Software Release 2.6.1 C613-10386-00 REV D...
  • Page 13 Patch 86261-04 For Rapier and AT-8800 Series Switches PCR: 03993 The AUTHENTICATION parameter has been removed from the “?” CLI help for firewall commands. This was not a valid parameter. PCR: 03994 Port speed and duplex values set with the SET SWITCH PORT SPEED command were sometimes not applied correctly.
  • Page 14 -------------------------------------------- 86261-02.paz flash -------------------------------------------- Module: BGP Module: CORE Time 08:32:23 Date 06-Nov-2003. FLASH : 32768 kB Size Version 170996 2.6.1-2 Patch Release Note Level: 2 Level: 4 Serial number P3-7 58476578 Patch 86261-04 for Software Release 2.6.1 C613-10386-00 REV D...
  • Page 15 Patch 86261-04 For Rapier and AT-8800 Series Switches Table 4: New parameters displayed in the output of the SHOW SYSTEM command for AT-8800 series switches. Parameter Current Temperature Fan Status PCR: 31040 When two devices are BSR candidates, and have the same preference set with the SET PIM BSRCANDIDATE PREFERENCE command, the device with the higher IP address was not elected as the candidate.
  • Page 16 Module: PPP Module: SW56 Module: IPv6 Module: STP Module: LDAP Patch Release Note Level: 3 Level: 2 Level: 2 Level: 4 Level: 2 Level: 2 Level: 2 Level: 2 Level: 3 Patch 86261-04 for Software Release 2.6.1 C613-10386-00 REV D...
  • Page 17 Patch 86261-04 For Rapier and AT-8800 Series Switches PCR: 31094 Files with lines over 132 characters in length could not be transferred using TFTP. This limit has now been raised to 1000 characters to match the maximum command line length.
  • Page 18 94120 bytes Module: SWI Module: OSPF, IPG Module: IKMP Module: BGP Module: IPV6 Module: OSPF Patch Release Note Level: 4 Level: 1 Level: 2 Level: 3 Level: 2 Level: 2 Level: 2 Patch 86261-04 for Software Release 2.6.1 C613-10386-00 REV D...
  • Page 19 Patch 86261-04 For Rapier and AT-8800 Series Switches PCR: 03861 When a connector was plugged into one physical interface, the RIPng request packet was erroneously transmitted from all interfaces on the switch. This issue has been resolved. PCR: 03864 BGP sent Update packets when the local host route table changed but did not affect BGP.
  • Page 20 Module: ETH Module: FIREWALL Module: SWI Module: SWI Module: SWITCH Patch Release Note Level: 3 Level: 2 Level: 2 Level: 3 Level: 3 Level: 3 Level: 2 Level: 3 Level: 2 Patch 86261-04 for Software Release 2.6.1 C613-10386-00 REV D...
  • Page 21 Patch 86261-04 For Rapier and AT-8800 Series Switches PCR: 03907 The CREATE CONFIG command did not generate the TYPE parameter for ADD IPV6 INTERFACE commands. This issue has been resolved. PCR: 03909 A fatal error sometimes occurred when encryption is enabled with Frame Relay over a synchronous link.
  • Page 22 Module: IPV6 Module: SW56 Module: IPSEC Module: IPSEC Patch Release Note Level: 2 Level: 3 Level: 2 Level: 2 Level: 3 Level: 3 Level: 2 Level: 2 Level: 3 Level: 3 Patch 86261-04 for Software Release 2.6.1 C613-10386-00 REV D...
  • Page 23 Patch 86261-04 For Rapier and AT-8800 Series Switches PCR: 03952 MAC address are now deleted from the all the internal tables for ports where the learn limit has been exceeded. PCR: 03953 On AT-8800 series switches, strict QoS scheduling is now enforced for ports where egress rate limiting is applied.
  • Page 24 SHOW IGMPSNOOPING ROUTERADDRESS Patch Release Note Patch 86261-04 for Software Release 2.6.1 C613-10386-00 REV D...
