- Page 1 AT-8800 Series Switch Quick Install Guide AT-8824 AT-8848...
- Page 2 Telesis be liable for any incidental, special, indirect, or consequential damages whatsoever, including but not limited to lost profits, arising out of or related to this manual or the information contained herein, even if Allied Telesis has been advised of, known, or should have known, the possibility of such damages.
-
Page 3: Documentation Roadmap
■ AT-8848 Quick Install Guide updates can be downloaded from support/software. Package Contents The following items are included with each AT-8800 Series switch. Contact your sales representative if any items are damaged or missing. ■ One AT-8800 Series switch. ■... -
Page 4: Selecting A Site
Selecting a Site The switch can be installed in a standard 19-inch rack or on a level surface such as a desktop or bench. When installing the switch, choose a site that: ■ Allows adequate airflow around the switch and its vents. ■... - Page 5 Slide the GBICs into the GBIC slots. Press each GBIC firmly into place. A range of GBICs have been tested and approved for use with AT-8800 Series switches. See the AT-8800 Series Hardware Reference or contact your authorised Allied Telesis distributor or reseller for more information, or visit www.alliedtelesis.com/support/...
-
Page 6: Configuring The Switch
RX and TX terminal locations on SC fibre GBIC ports are the reverse of RX and TX terminal locations on fixed SC fibre ports. When looking at an SC fibre GBIC from the front, the RX terminal is on the left and the TX terminal is on the right. 11. - Page 7 Alternatively, type a question mark (?) at the end of a partially completed command to see a list of valid options. See the AT-8800 Series Software Reference for more information on configuring the switch. Using the GUI to configure a switch: This section describes how to establish a connection to the switch through the GUI, so you can configure the switch before installing it in your LAN.
-
Page 8: System Leds
Switch Port LEDs. Documentation and Tools CD-ROM The Documentation and Tools CD-ROM bundled with each switch contains the complete Documentation Set for AT-8800 Series switches and their expansion options, as well as tools for managing the switch. This includes: ■...
