Patch Release Note
Patch 54266-02
For AR440S and AR441S ADSL Routers
Introduction
This patch release note lists the issues addressed and enhancements made in
patch 54266-02 for Software Release 2.6.6 on existing models of AR440S and
AR441S ADSL routers. Patch file details are listed in
Table 1: Patch file details for Patch 54266-02.
Base Software Release File
Patch Release Date
Compressed Patch File Name
Compressed Patch File Size
This release note should be read in conjunction with the following documents:
Release Note: Software Release 2.6.6 for AR440S ADSL Routers (Document
Number C613-10412-00) available from
documentation/documentation.html.
AR400 Series router Documentation Set for Software Release 2.6.6 available
on the Documentation and Tools CD-ROM packaged with your router, or
from www.alliedtelesyn.co.nz/documentation/documentation.html.
Errata to the Documentation: Software Release 2.6.6 for AR440S ADSL
Routers (Document Number C613-06011-00) available from
www.alliedtelesyn.co.nz/documentation/documentation.html.
WARNING: Using a patch for a different model or software release may cause
unpredictable results, including disruption to the network. Information in this
release note is subject to change without notice and does not represent a
commitment on the part of Allied Telesyn International. While every effort has
been made to ensure that the information contained within this document and
the features and changes described are accurate, Allied Telesyn International
can not accept any type of liability for errors in, or omissions arising from the
use of this information.
Table
1.
54-266.rez
9-Dec-2004
54266-02.paz
246872 bytes
www.alliedtelesyn.co.nz/
Simply connecting the world

Advertisement

loading

Summary of Contents for Allied Telesis Patch 54266-02

  • Page 1 Introduction This patch release note lists the issues addressed and enhancements made in patch 54266-02 for Software Release 2.6.6 on existing models of AR440S and AR441S ADSL routers. Patch file details are listed in Table 1: Patch file details for Patch 54266-02.
  • Page 2 Level 2 Level 3 Level 4 From Patch 54266-02 onwards, issues for each patch are listed in severity order as per the levels above. Enhancement PCRs are listed after Level 4 issues. Features in 54266-02 Patch 54266-02 includes the following enhancements and resolved issues:...
  • Page 3 Patch 54266-02 PCR: 40419 If OSPF was configured using the command set ospf dyninterface=stub, to advertise dynamic interfaces such as PPPoE interfaces as stub links, the links were not being advertised as expected. This issue has been resolved. PCR: 40442...
  • Page 4 This issue has been resolved. Module: ISAKMP Module: BGP Module: OSPF Module: DHCP Module: DHCP Module: DVMRP Module: IPG Patch Release Note Level: 2 Level: 2 Level: 2 Level: 2 Level: 2 Level: 2 Level: 2 Patch 54266-02 C613-10417-00 Rev B...
  • Page 5 Patch 54266-02 PCR: 40537 When the status of an interface changed, the BGP revaluation of IP routes for redistribution (via the add bgp import or add bgp network commands) was incorrect. This gave inconsistent BGP route tables depending on the order of events.
  • Page 6 ECHO request packet using a broadcast MAC address. These issues have been resolved. Module: PING Module: OSPF, IPG Module: L2TP Module: FFILE Module: IPNAT Module: IPG Patch Release Note Level: 2 Level: 2 Level: 2 Level: 2 Level: 2 Level: 3 Patch 54266-02 C613-10417-00 Rev B...
  • Page 7 Patch 54266-02 PCR: 40417 When LS Acks (Link State Advert acks) were received, they were compared against the transmitted LSA (Link State Advert). If it was the same, the LSA was removed from the re-transmission list. The algorithm used in this check has been changed to be compliant with the algorithm specified in section 13.1 of RFC2328, to determine if the LS Ack received is the instance as the...
  • Page 8 AT-AR024 ASYN4 PIC, four Asynchronous ports with RJ-45 connectors. AT-AR026 4ETH PIC, four 10BASE-T/100 BASE-TX auto-negotiating ports with RJ-45 connectors. AT-AR027 VoIP-FXS PIC, two Foreign Exchange Subscriber (FXS) ports with RJ-11 connectors. Patch Release Note Level: 4 Patch 54266-02 C613-10417-00 Rev B...
  • Page 9: Main System

    Patch 54266-02 Main system Main features of the AR440S routers are: ■ 300 MHz RISC processor. ■ 64 MBytes of SDRAM. ■ 16 MBytes of flash memory (1 MByte reserved for boot block code). ■ 5 x 10/100 Mbps full duplex, Layer 2 switched Ethernet LAN ports. All LAN ports have Auto-MDI, however if Auto-MDI is turned off, then all ports are hardwired as MDI-X.
  • Page 10 Error (3005271): Internal Error: Failed to start interface Patch Release Note 54-266.rez d440Se14.rsc (AR440S) d441Se14.rsc (AR441S) 21-Oct-2004 54266-01.paz 161304 bytes (“AR441S ADSL Router Hardware Level: 3 Level: 3 Level: 2 Level: 2 Level: 2 Level: 2 Patch 54266-02 C613-10417-00 Rev B...
  • Page 11 Patch 54266-02 This issue has been resolved. It is now possible to add an IP address to a VCMux encapsulated ATM interface with inversearp set to off. This is known as RFC 1483 routing. RFC 1577, classical IP and ARP over ATM, still requires the ATM interface to be LLCSNAP encapsulated.
  • Page 12 The onlink parameter displayed the default value yes. The autonomous parameter displayed the default value on. Module: SWK Module: Firewall Module: ENCO Module: Firewall Patch Release Note Level: 3 Level: 3 Level: 2 Level: 2 Level: 2 Level: 2 Level: 2 Patch 54266-02 C613-10417-00 Rev B...
  • Page 13 Patch 54266-02 PCR: 40647 When a virtual Eth interface was created over ATM, for example, using the command: and a VPN configuration was applied directly to that Eth interface, the router ran out off buffers and caused a fatal exception under heavy reception load.
  • Page 14 Features in 54266-01 Patch Release Note Patch 54266-02 C613-10417-00 Rev B...
